Set Up Your Power.
TriSensor will be powered by battery. These steps can be performed in any location within your home, and not
necessarily in your TriSensor's final installation location.
For a battery powered installation:
1. Remove your sensor's rear cover by sliding the lock to the right.
2. Pull out the CR123A battery and remove the plastic tab.
3. Place the CR123A battery back into its original position.
As soon as TriSensor is powered on, it will flash its red LED 4 times to indicate that it is now powered and ready to be
paired.
Adding your TriSensor into a Z-Wave Network.
With it powered on, it's now time to add your TriSensor to a Z-Wave network. To pair TriSensor, you are not limited to
only the Z-Stick or Minimote. You may use any Z-Wave Gateway to pair TriSensor, but compatibility and how the
sensor shows ultimately depends on the gateway and software integration of products.
If you're using a Z-Stick from Aeotec:
1. If your Z-Stick is plugged into a gateway or a computer, unplug it.
2. Take your Z-Stick to your TriSensor.
3. Press the Action Button on your Z-Stick. The LED will begin to blink the Blue LED slowly.
4. Press the Action Button on your TriSensor. The LED on TriSensor will blink white, then become a solid yellow LED,
followed by a 2 flashes of white then green LED to indicate a successful inclusion. If the pairing process has failed, the
LED will deactivate without flashing white or green.
