AM Series Piping
Application Guide
Figure 1: AM 399/500 Relief Valve Point of Discharge Example
CAUTION!
Each relief valve must have its own discharge piping all the way to the
point of discharge, and must never be manifolded, attached to, or
combined with any other piping.
RELIEF VALVE #1
SEPARATE PIPES
LEADING TO POINT
OF DISCARGE
RELIEF VALVE #1
DISCHARGE PIPING
RELIEF VALVE #2
RELIEF VALVE #2
DISCHARGE PIPING
