Aerco Benchmark Series User Manual

APPENDIX E
xiv
BOILER DEFAULT SETTINGS
CONSTANT SET POINT MODE
MENU LEVEL
& CODE
DESCRIPTION OF CODE FACTORY
DEFAULT
PRIMARY MENU
tout
OUTLET TEMPERATURE
ACTUAL
pct
PERCENTAGE OF FIRING RATE
ACTUAL
setp
UNIT’S SETPOINT TEMPERATURE
120
airt
OUTSIDE AIR TEMPERATURE
ACTUAL
auto
AUTOMATIC\MANUAL MODE
AUTO ON
SECONDARY MENU
func
MODE OF OPERATION
CONT
OAST
OUTSIDE AIR SENSOR FEATURE
OFF
OAT
OUTSIDE AIR TEMP
0
LLT
LOW LIMIT TEMPERATURE
40
HLT
HIGH LIMIT TEMPERATURE
220
pb1
PROPORTIONAL GAIN
70
int
INTEGRAL
1
drt
DERIVATIVE
0 (off)
addr
ADDRESS
32
lore
LOCAL/REMOTE MODE
LOC
SECURE
secr
SECURITY LEVEL
3
func
MODE OF OPERATION
CONT
gain
GAIN
1
pb3
PROPORTIONAL BAND
5000
lofi
LOW FIRE
29
lfti
LOW FIRE TIMER
0
purg
PURGE
100
O2-O
STOP LEVEL
20%
O2-C
START LEVEL
25%
FLTI
FAULT TIMER
40 SEC.
DFIL
DISPLAY FILTER
5
ARUP
ANTI RESET WINDUP
ON
PEA
PEAK(Highest Temp. Unit Has Seen Since Reset)
ACTUAL
VAL
VALLEY(Lowest Temp. Has Seen Since Reset)
ACTUAL
INPC
INPUT CORRECTION
0
INPT
INPUT TIMER
0.2
FILT
SENSOR FILTER
2
UNIT
UNIT OF DISPLAY
F
ADDR
ADDRESS
32
BAUD
BAUD RATE
9600
INP
INPUT
CAL

Aerco Benchmark Series Specifications

General

Model	Benchmark Series
Category	Boiler
Manufacturer	Aerco
Vent Material	Stainless Steel
Fuel Type	Natural Gas
Operating Pressure	160 psig
Control System	Aerco Control System
Heat Exchanger Material	Stainless Steel
