Aerco Modulex MLX Series - Dimensions and Weights

MC2: 10/03/12 Page 13 of 90
AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526-0288
GF-115-H
OMM-0083_0B
Modulex MLX Series Gas Fired Boiler System
Operation and Maintenance Manual
Chap 2: General
Description
2.4 Dimensions and Weights
The dimensions and weights for each Modulex Model are shown in Diagram 1 and 2 of Figure 2-1 and
Table 2-2.
4.33” (110 mm)
12.40”
(315 mm)
4.33” (110 mm)
16.73”
(425 mm)
8.78”
(223 mm)
13.39”
(340 mm)
L
8.78”
(223 mm)
13.39”
(340 mm)
FRONT VIEW
S
10.55” (268 mm)
Ø
13.78”
(350 mm)
13.58
(345 mm)
B
C
TOP VIEW
H
D
B
A
Figure 2-1: Modulex Dimensions and Weights (Diagram 1 of 2)
