20
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 124 Qv [m
3
/h] k (Pc) k (Ps)
Speed V4
1750 1 1
Speed V3
1350 0,83 0,82
Speed V2
1100 0,71 0,69
Speed V1
750 0,52 0,50
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 6931 3384 5538 2925 4002 3391 2984 2076 2319 1613
23 6889 3815 5505 3355 4272 2971 3624 2521 2971 2067
25 6860 4239 5488 3782 4895 3405 4251 2957 3607 2509
27 6759 4658 6140 4271 5505 3829 4869 3387 4234 2945
29 7373 5129 6742 4690 6111 4251 5479 3812 4848 3373
31 7963 5539 7335 5103 6708 4666 6081 4230 5454 3794
17
21 8724 3387 7352 2933 5867 2474 4217 2002 2201 1458
23 8771 3815 7411 3367 5934 2910 4297 2442 2971 2067
25 8707 4239 7352 3791 5888 3340 4259 2872 3607 2509
27 8678 4661 7335 4216 5875 3765 4869 3387 4234 2945
29 8569 5073 7234 4631 6111 4251 5479 3812 4848 3373
31 8522 5483 7335 5103 6708 4666 6081 4230 5454 3794
19
21 10845 3370 9490 2925 8026 2474 6435 2005 4667 1537
23 10786 3812 9435 3367 7984 2919 6401 2468 4642 1988
25 10736 4236 9393 3794 7950 3349 6376 2898 4629 2433
27 10677 4658 9339 4216 7904 3774 6338 3320 4600 2945
29 10706 5106 9284 4634 7857 4195 6304 3747 4848 3373
31 10660 5513 9250 5047 7832 4608 6288 4166 5454 3794
21
21 12899 3340 11548 2895 10100 2450 8531 2002 6818 1549
23 13055 3826 11615 3352 10176 2910 8619 2453 6919 2002
25 12983 4262 11557 3791 10121 3352 8573 2907 6885 2447
27 12899 4681 11477 4213 10054 3777 8514 3334 6835 2889
29 12958 5097 11548 4631 10134 4195 8606 3759 6940 3314
31 12714 5507 11312 5044 9907 4611 8383 4175 6725 3733
23
23 15268 3791 13838 3323 12402 2884 10858 2442 9183 2000
25 15332 4239 13909 3774 12482 3337 10951 2887 9288 2444
27 14557 4675 13143 4210 11725 3774 10197 3337 8539 2895
29 15138 5056 13825 4626 12419 4192 10900 3759 9259 3323
31 14923 5466 13619 5038 12217 4608 10711 4178 9078 3741
5
15
21 6325 3179 4747 2676 3405 2313 2723 1894 2003 1394
23 6292 3613 4722 3109 4061 2825 3396 2363 2714 1888
25 6271 4037 5349 3721 4701 3270 4049 2816 3388 2357
27 6607 4596 5968 4151 5328 3706 4684 3258 4032 2805
29 7209 5015 6578 4576 5942 4134 5307 3692 4663 3244
31 7807 5431 7176 4991 6548 4555 5917 4116 5282 3674
17
21 8194 3206 6708 2731 5012 2225 2778 1616 2003 1394
23 8249 3639 6776 3168 5101 2667 3396 2222 2714 1888
25 8190 4066 6725 3595 5059 3097 4049 2816 3388 2357
27 8169 4488 6713 4020 5328 3671 4684 3258 4032 2805
29 8064 4904 6616 4435 5942 4134 5307 3692 4663 3244
31 8021 5313 7176 4991 6548 4555 5917 4116 5282 3674
19
21 10370 3209 8930 2749 7348 2263 5538 1765 3220 1177
23 10315 3654 8884 3194 7310 2723 5517 2228 3207 1631
25 10269 4081 8851 3624 7285 3156 5501 2661 3207 2079
27 10214 4500 8800 4040 7243 3569 5471 3062 4032 2805
29 10159 4918 8754 4467 7205 4002 5442 3513 4663 3244
31 10117 5331 8724 4880 7188 4421 5917 4116 5282 3674
21
21 12457 3191 11043 2737 9503 2278 7798 1806 5816 1285
23 12520 3648 11119 3197 9591 2728 7904 2257 5972 1762
25 12457 4084 11064 3636 9545 3182 7866 2705 5947 2210
27 12377 4505 10993 4060 9482 3610 7811 3144 5905 2655
29 12449 4924 11073 4479 9574 4031 7920 3572 6031 3086
31 12209 5337 10837 4895 9347 4447 7697 3987 5808 3501
23
23 14763 3621 13375 3176 11872 2728 10231 2272 8413 1792
25 14835 4072 13455 3630 11961 3173 10336 2720 8535 2254
27 14061 4505 12684 4066 11195 3618 9566 3165 7752 2687
29 14747 4924 13383 4485 11910 4043 10302 3598 8526 3135
31 14532 5334 13177 4901 11712 4462 10113 4014 8341 3557
7
15
21 5400 2878 3228 2225 3085 2146 2252 1566 951 662
23 5370 3311 4469 3086 3788 2635 3085 2146 2277 1584
25 5778 3949 5122 3563 4457 3100 3779 2629 3076 2140
27 6405 4456 5757 4005 5105 3551 4444 3091 3771 2623
29 7020 4883 6380 4438 5736 3990 5088 3539 4432 3083
31 7626 5305 6990 4863 6355 4421 5715 3976 5071 3528
17
21 7449 2963 5711 2430 3350 1768 2252 1484 951 662
23 7516 3399 5799 2872 3489 2222 3085 2146 2277 1584
25 7466 3829 5753 3299 4457 2974 3779 2629 3076 2140
27 7449 4251 5753 3727 5105 3551 4444 3091 3771 2623
29 7348 4669 6380 4438 5736 3990 5088 3539 4432 3083
31 7310 5085 6990 4863 6355 4421 5715 3976 5071 3528
19
21 9734 3004 8148 2509 6296 1967 3804 1320 951 650
23 9688 3449 8110 2957 6271 2430 3792 1774 2277 1420
25 9650 3876 8076 3387 6254 2863 3792 2222 3076 2073
27 9600 4289 8034 3794 6220 3250 4444 3033 3771 2623
29 9549 4719 7996 4233 6191 3715 5088 3484 4432 3083
31 9520 5132 7975 4652 6182 4137 5715 3976 5071 3528
21
21 11885 3004 10366 2529 8657 2038 6658 1496 3901 831
23 11965 3463 10454 2992 8762 2491 6788 1967 4120 1312
25 11906 3902 10403 3437 8720 2948 6763 2415 4108 1774
27 11830 4327 10340 3861 8665 3378 6717 2857 4070 2216
29 11914 4748 10433 4283 8775 3806 6847 3291 4276 2667
31 11674 5158 10197 4699 8543 4219 6612 3703 5071 3381
23
23 14250 3454 12777 2995 11157 2526 9339 2038 7205 1499
25 14330 3908 12870 3452 11262 2974 9461 2488 7352 1959
27 13551 4339 12087 3882 10475 3414 8653 2925 6460 2374
29 14254 4760 12811 4309 11228 3850 9448 3373 7373 2857
31 14044 5176 12609 4725 11031 4265 9259 3788 7184 3276
COOLING CAPACITY OUTPUT - FCLI 124
