TECHNICAL DATA
 Sound pressure level (weighted A) measured in environment with
volume V=100m
3
, reverberation time t=05s directivity factor Q=2,
distance r=2.5m
Cooling:
• Room air temperature 27°C D.B.; 19°C W.B.
• Water inlet temperature 7°C; water Dt 5°K
Heating 50°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
Heating 70°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
The earth leakage current of several devices
placed under the same circuit breaker is
summed, therefore we recommend paying
attention to the calibration value of the
circuit breaker and, if necessary, consider
splitting the installation in more circuits, each
of which protected by its own circuit breaker.
The performance refers to the following conditions:
FCL_I 32 34 42 44 62 64
Fan speed H M L H M L H M L H M L H M L H M L
Performance in heating mode
2-pipe systems:
Heating capacity (70°C) (1) kW 4.00 2.95 2.22 / / / 7.34 4.47 3.32 / / / 10.49 6.37 5.19 / / /
Water ow rate (1) l/h 350 258 194 / / / 642 391 290 / / / 918 558 454 / / /
Pressure drops (1) kPa 10 6 4 / / / 24 10 6 / / / 42 17 12 / / /
Heating capacity (45°C) (2) kW 1.99 1.47 1.10 / / / 3.65 2.23 1.65 / / / 5.22 3.17 2.58 / / /
Water ow rate (2) l/h 345 254 192 / / / 633 386 287 / / / 905 550 448 / / /
Pressure drops (2) kPa 10 6 4 / / / 23 10 6 / / / 41 17 11 / / /
4-pipe systems with additional heat exchanger
Heating capacity (65°C) (3) kW / / / 2.32 1.96 1.74 / / / 2.74 2.04 1.75 / / / 3.19 2.51 2.21
Water ow rate (3) l/h / / / 203 171 152 / / / 240 178 153 / / / 279 219 194
Pressure drops (3) kPa / / / 9 7 5 / / / 12 7 5 / / / 19 12 10
Performance in cooling mode
Total cooling capacity (4) kW 1.90 1.47 1.16 1.90 1.47 1.16 3.95 2.54 1.96 3.64 2.30 1.83 4.98 3.21 2.66 4.61 2.96 2.46
Sensitive cooling
capacity
(4) kW 0.99 1.25 1.52 1.52 1.25 0.99 3.16 1.82 1.38 2.91 1.62 1.30 3.81 2.24 1.87 3.53 2.08 1.73
Water ow rate (4) l/h 327 253 200 327 253 200 679 437 337 626 396 314 856 551 458 793 510 424
Pressure drops (4) kPa 11.7 7.4 4.8 12.7 8 5.2 32.4 14.7 9.2 31.7 13.9 9.2 47.8 21.6 15.5 50.3 22.7 16.3
Fan
Fan - Centrifugal no. 1
Air ow rate m/h 600 410 300 600 410 300 700 360 260 700 360 260 880 500 380 880 500 380
Sound levels
Sound power level (5) dB(A) 46 38 35 46 38 35 53 39 35 53 39 35 61 47 41 61 47 41
Sound pressure level dB(A) 37 29 26 37 29 26 44 30 26 44 30 26 52 38 32 52 38 32
Fittings diameter
Standard coil Ø 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Additional coil Ø / 1/2" / 1/2" / 1/2"
Larger coil Ø / / / / / /
Electric functioning
Input power W 18 13 10 18 13 10 55 16 12 55 16 12 61 20 14 61 20 14
Input current A 0.28 0.28 0.43 0.43 0.47 0.47
0-10V signal % 90 62 42 90 62 42 90 46 34 90 46 34 90 52 40 90 52 40
Power supply 230V~50Hz
Kvs (standard version 3-way valve) 2.5 2.5 2.5 2.5 2.5 2.5
Kvs (V2 version 2-way valve) 2.5 2.5 2.5 2.5 2.5 2.5
H maximum speed; M medium speed; L minimum speed
(1) Room air 20°C d.b.; Water (in/out) 70°C/60°C;
(2) Ambient air 20°C d.b.; Water (in/out) 45°C/40°C (EUROVENT)
(3) Ambient air 20°C d.b.; Water (in/out) 65°C/55°C; (EUROVENT)
(4) Ambient air 27°C d.b./19°C w.b.; Water (in/out) 7°C/12°C (EUROVENT)
(5) Sound power based on the measurements carried out in accordance with Eurovent 8/2 standard
Sound pressure (weighted A) measured in environment with volume V=100 m reverberation time t=05s, directivity factor Q=2, distance r=2.5m
