11
TECHNICAL DATA
Sound pressure level (weighted A) measured in environment with
volume V=100m
3
, reverberation time t=05s directivity factor Q=2,
distance r=2.5m
Cooling:
• Room air temperature 27°C D.B.; 19°C W.B.
• Water inlet temperature 7°C; water Dt 5°K
Heating 50°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
Heating 70°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
The earth leakage current of several devices
placed under the same circuit breaker is
summed, therefore we recommend paying
attention to the calibration value of the
circuit breaker and, if necessary, consider
splitting the installation in more circuits, each
of which protected by its own circuit breaker.
The performance refers to the following conditions:
FCL_I 82 122 124
Fan speed H M L H M L H M L
Performance in heating mode
2-pipe systems:
Heating capacity (70°C) (1) kW 11.88 8.12 5.88 21.75 14.73 10.53 / / /
Water ow rate (1) l/h 1039 710 514 1903 1289 921 / / /
Pressure drops (1) kPa 26 13 7 42 21 11 / / /
Heating capacity (45°C) (3) kW 5.91 4.04 2.92 10.82 7.33 5.24 / / /
Water ow rate (3) l/h 1025 701 507 1877 1271 909 / / /
Pressure drops (3) kPa 25 13 7 41 20 11 / / /
4-pipe systems with additional heat exchanger
Heating capacity (65°C) (4) kW / / / / / / 11.17 8.31 6.30
Water ow rate (4) l/h / / / / / / 977 727 551
Pressure drops (4) kPa / / / / / / 25 14 9
Performance in cooling mode
Total cooling capacity (5) kW 6.00 4.04 2.80 11.00 7.51 5.36 8.80 6.21 4.57
Sensitive cooling capacity (5) kW 4.20 2.76 1.90 8.47 5.74 4.04 6.77 4.67 3.37
Water ow rate (5) l/h 1032 695 482 1893 1292 921 1513 1068 786
Pressure drops (5) kPa 34.7 17 8.8 60.1 30.2 16.4 52.3 28 16.1
Fan
Fan - Centrifugal no. 1
Air ow rate m/h 1100 680 460 1750 1100 750 1750 1100 750
Sound levels
Sound power level (6) dB(A) 50 43 39 60 50 44 60 50 44
Sound pressure level dB(A) 41 34 30 51 41 35 51 41 35
Fittings diameter
Standard coil Ø 3/4" 3/4" 3/4"
Additional coil Ø / / 1/2"
Larger coil Ø / / /
Electric functioning
Input power W 33 14 9 135 33 16 135 33 16
Input current A 0.71 0.80 0.80
0-10V signal % 90 54 38 90 58 38 90 58 38
Power supply 230V~50/60Hz
Kvs (standard version 3-way valve) 4 4 4
Kvs (V2 version 2-way valve) 2.5 2.5 2.5
H maximum speed; M medium speed; L minimum speed
(1) Room air 20°C d.b.; Water (in/out) 70°C/60°C;
(2) Ambient air 20°C d.b.; Water (in/out) 45°C/40°C (EUROVENT)
(3) Ambient air 20°C d.b.; Water (in/out) 65°C/55°C; (EUROVENT)
(4) Ambient air 27°C d.b./19°C w.b.; Water (in/out) 7°C/12°C (EUROVENT)
(5) Sound power based on the measurements carried out in accordance with Eurovent 8/2 standard
Sound pressure (weighted A) measured in environment with volume V=100 m reverberation time t=05s, directivity factor Q=2, distance r=2.5m
