COOLING CAPACITY OUTPUT - FCLI32
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 32 / FCLI34 Qv [m
3
/h] k (Pc) k (Ps)
Speed V3 600 1 1
Speed V2 410 0.77 0.82
Speed V1 300 0.61 0.65
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21
1497 829 1196 717 864 831 644 509 501 395
23
1487 935 1189 822 922 728 782 618 642 506
25
1481 1039 1185 927 1057 834 918 725 779 615
27
1459 1141 1326 1047 1189 938 1051 830 914 722
29
1592 1257 1456 1149 1319 1042 1183 934 1047 826
31
1719 1357 1584 1250 1448 1144 1313 1037 1178 930
17
21
1884 830 1587 719 1267 606 910 491 475 357
23
1894 935 1600 825 1281 713 928 598 642 506
25
1880 1039 1587 929 1271 819 920 704 779 615
27
1874 1142 1584 1033 1268 923 1051 830 914 722
29
1850 1243 1562 1135 1319 1042 1183 934 1047 826
31
1840 1344 1584 1250 1448 1144 1313 1037 1178 930
19
21
2342 826 2049 717 1733 606 1389 491 1008 377
23
2329 934 2037 825 1724 715 1382 605 1002 487
25
2318 1038 2028 930 1716 821 1377 710 1000 596
27
2305 1141 2016 1033 1706 925 1368 814 993 722
29
2312 1251 2004 1136 1696 1028 1361 918 1047 826
31
2302 1351 1997 1237 1691 1129 1358 1021 1178 930
21
21
2785 819 2493 710 2181 600 1842 491 1472 380
23
2819 938 2508 821 2197 713 1861 601 1494 491
25
2803 1045 2495 929 2185 821 1851 712 1487 600
27
2785 1147 2478 1032 2171 925 1838 817 1476 708
29
2798 1249 2493 1135 2188 1028 1858 921 1498 812
31
2745 1349 2442 1236 2139 1130 1810 1023 1452 915
23
23
3297 929 2988 814 2678 707 2344 598 1983 490
25
3310 1039 3003 925 2695 818 2364 707 2005 599
27
3143 1146 2838 1032 2532 925 2202 818 1844 710
29
3268 1239 2985 1133 2681 1027 2353 921 1999 814
31
3222 1339 2940 1235 2638 1129 2313 1024 1960 917
5
15
21
1366 779 1025 656 735 567 588 464 433 341
23
1358 885 1020 762 877 692 733 579 586 463
25
1354 989 1155 912 1015 801 874 690 731 578
27
1427 1126 1288 1017 1150 908 1011 798 870 687
29
1557 1229 1420 1121 1283 1013 1146 905 1007 795
31
1686 1331 1549 1223 1414 1116 1278 1009 1140 900
17
21
1769 786 1448 669 1082 545 600 396 433 341
23
1781 892 1463 776 1101 654 733 545 586 463
25
1768 996 1452 881 1092 759 874 690 731 578
27
1764 1100 1449 985 1150 900 1011 798 870 687
29
1741 1202 1428 1087 1283 1013 1146 905 1007 795
31
1732 1302 1549 1223 1414 1116 1278 1009 1140 900
19
21
2239 786 1928 674 1587 555 1196 433 695 288
23
2227 895 1918 783 1578 667 1191 546 692 400
25
2217 1000 1911 888 1573 773 1188 652 692 509
27
2205 1103 1900 990 1564 875 1181 750 870 687
29
2193 1205 1890 1095 1556 981 1175 861 1007 795
31
2184 1306 1884 1196 1552 1083 1278 1009 1140 900
21
21
2690 782 2384 671 2052 558 1684 443 1256 315
23
2703 894 2401 783 2071 669 1706 553 1289 432
25
2690 1001 2389 891 2061 780 1698 663 1284 542
27
2672 1104 2373 995 2047 885 1686 770 1275 651
29
2688 1207 2391 1098 2067 988 1710 875 1302 756
31
2636 1308 2340 1199 2018 1090 1662 977 1254 858
23
23
3188 887 2888 778 2563 669 2209 557 1816 439
25
3203 998 2905 890 2582 778 2232 666 1843 552
27
3036 1104 2739 996 2417 887 2065 776 1674 659
29
3184 1207 2890 1099 2571 991 2224 882 1841 768
31
3138 1307 2845 1201 2529 1093 2184 984 1801 872
7
15
21
1166 705 697 545 666 526 486 384 205 162
23
1159 811 965 756 818 646 666 526 492 388
25
1248 968 1106 873 962 760 816 644 664 524
27
1383 1092 1243 981 1102 870 960 758 814 643
29
1516 1197 1378 1088 1238 978 1099 867 957 755
31
1646 1300 1509 1192 1372 1083 1234 974 1095 864
17
21
1608 726 1233 595 723 433 486 364 205 162
23
1623 833 1252 704 753 545 666 526 492 388
25
1612 938 1242 809 962 729 816 644 664 524
27
1608 1042 1242 913 1102 870 960 758 814 643
29
1587 1144 1378 1088 1238 978 1099 867 957 755
31
1578 1246 1509 1192 1372 1083 1234 974 1095 864
19
21
2102 736 1759 615 1359 482 821 324 205 159
23
2092 845 1751 725 1354 595 819 435 492 348
25
2084 950 1744 830 1350 702 819 545 664 508
27
2073 1051 1735 930 1343 796 960 743 814 643
29
2062 1156 1726 1037 1337 910 1099 854 957 755
31
2055 1258 1722 1140 1335 1014 1234 974 1095 864
21
21
2566 736 2238 620 1869 499 1437 367 842 204
23
2583 849 2257 733 1892 611 1466 482 890 321
25
2571 956 2246 842 1883 722 1460 592 887 435
27
2554 1060 2233 946 1871 828 1450 700 879 543
29
2572 1164 2253 1050 1895 933 1478 806 923 654
31
2521 1264 2202 1151 1845 1034 1427 908 1095 829
23
23
3077 847 2759 734 2409 619 2016 499 1556 367
25
3094 958 2779 846 2432 729 2043 610 1587 480
27
2926 1063 2610 951 2262 836 1868 717 1395 582
29
3078 1166 2766 1056 2424 943 2040 826 1592 700
31
3032 1268 2722 1158 2382 1045 1999 928 1551 803
