AERMEC FCLI 64 User Manual

13
COOLING CAPACITY OUTPUT - FCLI34
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 32 / FCLI34 Qv [m
3
/h] k (Pc) k (Ps)
Speed V3 600 1 1
Speed V2 410 0.77 0.82
Speed V1 300 0.61 0.65
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 1497 1273 1196 1100 864 1276 644 644 501 501
23 1487 1435 1189 1262 922 922 782 782 642 642
25 1481 1481 1185 1423 1057 1057 918 918 779 779
27 1459 1459 1326 1607 1189 1189 1051 1051 914 914
29 1592 1592 1456 1765 1319 1319 1183 1183 1047 1047
31 1719 1719 1584 1920 1448 1448 1313 1313 1178 1178
17
21 1884 1274 1587 1104 1267 931 910 753 475 475
23 1894 1435 1600 1267 1281 1095 928 919 642 642
25 1880 1595 1587 1426 1271 1257 920 920 779 779
27 1874 1754 1584 1586 1268 1268 1051 1051 914 914
29 1850 1850 1562 1742 1319 1319 1183 1183 1047 1047
31 1840 1840 1584 1920 1448 1448 1313 1313 1178 1178
19
21 2342 1268 2049 1100 1733 931 1389 754 1008 578
23 2329 1434 2037 1267 1724 1098 1382 929 1002 748
25 2318 1594 2028 1427 1716 1260 1377 1090 1000 915
27 2305 1752 2016 1586 1706 1420 1368 1249 993 993
29 2312 1921 2004 1744 1696 1578 1361 1361 1047 1047
31 2302 2074 1997 1899 1691 1691 1358 1358 1178 1178
21
21 2785 1257 2493 1089 2181 922 1842 753 1472 583
23 2819 1440 2508 1261 2197 1095 1861 923 1494 753
25 2803 1604 2495 1426 2185 1261 1851 1094 1487 921
27 2785 1761 2478 1585 2171 1421 1838 1255 1476 1087
29 2798 1918 2493 1742 2188 1578 1858 1414 1498 1247
31 2745 2072 2442 1898 2139 1735 1810 1571 1452 1404
23
23 3297 1426 2988 1250 2678 1085 2344 919 1983 752
25 3310 1595 3003 1420 2695 1256 2364 1086 2005 920
27 3143 1759 2838 1584 2532 1420 2202 1256 1844 1089
29 3268 1902 2985 1740 2681 1577 2353 1414 1999 1250
31 3222 2056 2940 1896 2638 1734 2313 1572 1960 1408
5
15
21 1366 1196 1025 1007 735 735 588 588 433 433
23 1358 1358 1020 1170 877 877 733 733 586 586
25 1354 1354 1155 1400 1015 1015 874 874 731 731
27 1427 1427 1288 1562 1150 1150 1011 1011 870 870
29 1557 1557 1420 1722 1283 1283 1146 1146 1007 1007
31 1686 1686 1549 1878 1414 1414 1278 1278 1140 1140
17
21 1769 1206 1448 1028 1082 837 600 600 433 433
23 1781 1369 1463 1192 1101 1003 733 733 586 586
25 1768 1530 1452 1353 1092 1092 874 874 731 731
27 1764 1689 1449 1512 1150 1150 1011 1011 870 870
29 1741 1741 1428 1669 1283 1283 1146 1146 1007 1007
31 1732 1732 1549 1878 1414 1414 1278 1278 1140 1140
19
21 2239 1207 1928 1034 1587 851 1196 664 695 443
23 2227 1375 1918 1202 1578 1024 1191 838 692 614
25 2217 1535 1911 1364 1573 1187 1188 1001 692 692
27 2205 1693 1900 1520 1564 1343 1181 1152 870 870
29 2193 1850 1890 1681 1556 1506 1175 1175 1007 1007
31 2184 2006 1884 1836 1552 1552 1278 1278 1140 1140
21
21 2690 1201 2384 1030 2052 857 1684 680 1256 484
23 2703 1372 2401 1203 2071 1027 1706 849 1289 663
25 2690 1537 2389 1368 2061 1197 1698 1018 1284 832
27 2672 1695 2373 1528 2047 1358 1686 1183 1275 999
29 2688 1853 2391 1685 2067 1517 1710 1344 1302 1161
31 2636 2008 2340 1842 2018 1673 1662 1500 1254 1254
23
23 3188 1362 2888 1195 2563 1027 2209 855 1816 674
25 3203 1532 2905 1366 2582 1194 2232 1023 1843 848
27 3036 1695 2739 1530 2417 1361 2065 1191 1674 1011
29 3184 1853 2890 1687 2571 1521 2224 1354 1841 1180
31 3138 2007 2845 1844 2529 1679 2184 1510 1801 1338
7
15
21 1166 1083 697 837 666 666 486 486 205 205
23 1159 1159 965 1161 818 818 666 666 492 492
25 1248 1248 1106 1340 962 962 816 816 664 664
27 1383 1383 1243 1507 1102 1102 960 960 814 814
29 1516 1516 1378 1670 1238 1238 1099 1099 957 957
31 1646 1646 1509 1830 1372 1372 1234 1234 1095 1095
17
21 1608 1115 1233 914 723 665 486 486 205 205
23 1623 1279 1252 1081 753 753 666 666 492 492
25 1612 1441 1242 1241 962 962 816 816 664 664
27 1608 1599 1242 1402 1102 1102 960 960 814 814
29 1587 1587 1378 1670 1238 1238 1099 1099 957 957
31 1578 1578 1509 1830 1372 1372 1234 1234 1095 1095
19
21 2102 1130 1759 944 1359 740 821 497 205 205
23 2092 1298 1751 1112 1354 914 819 667 492 492
25 2084 1458 1744 1274 1350 1077 819 819 664 664
27 2073 1614 1735 1427 1343 1223 960 960 814 814
29 2062 1776 1726 1593 1337 1337 1099 1099 957 957
31 2055 1931 1722 1750 1335 1335 1234 1234 1095 1095
21
21 2566 1130 2238 952 1869 767 1437 563 842 313
23 2583 1303 2257 1126 1892 937 1466 740 890 493
25 2571 1468 2246 1293 1883 1109 1460 909 887 667
27 2554 1628 2233 1453 1871 1271 1450 1075 879 834
29 2572 1787 2253 1611 1895 1432 1478 1238 923 923
31 2521 1941 2202 1768 1845 1587 1427 1393 1095 1095
23
23 3077 1300 2759 1127 2409 951 2016 767 1556 564
25 3094 1470 2779 1299 2432 1119 2043 936 1587 737
27 2926 1632 2610 1461 2262 1284 1868 1100 1395 893
29 3078 1791 2766 1621 2424 1448 2040 1269 1592 1075
31 3032 1947 2722 1778 2382 1605 1999 1425 1551 1233
