COOLING CAPACITY OUTPUT - FCLI42
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21
3111 2647 2486 2288 1796 2652 1339 1339 1041 1041
23
3092 2984 2471 2624 1917 1917 1626 1626 1334 1334
25
3079 3079 2463 2958 2197 2197 1908 1908 1619 1619
27
3034 3034 2756 3341 2471 2471 2186 2186 1900 1900
29
3310 3310 3026 3668 2743 2743 2460 2460 2176 2176
31
3574 3574 3293 3991 3011 3011 2730 2730 2448 2448
17
21
3916 2649 3300 2294 2633 1935 1893 1566 988 988
23
3937 2984 3327 2633 2664 2276 1929 1910 1334 1334
25
3908 3316 3300 2965 2643 2613 1912 1912 1619 1619
27
3895 3645 3293 3297 2637 2637 2186 2186 1900 1900
29
3846 3846 3247 3623 2743 2743 2460 2460 2176 2176
31
3825 3825 3293 3991 3011 3011 2730 2730 2448 2448
19
21
4868 2636 4260 2288 3602 1935 2888 1569 2095 1202
23
4842 2981 4235 2633 3584 2283 2873 1930 2084 1555
25
4819 3313 4216 2968 3568 2620 2862 2267 2078 1903
27
4793 3643 4192 3297 3548 2952 2845 2597 2065 2065
29
4806 3994 4167 3625 3527 3281 2830 2830 2176 2176
31
4785 4312 4152 3948 3516 3516 2822 2822 2448 2448
21
21
5790 2613 5184 2265 4534 1917 3829 1566 3060 1211
23
5860 2993 5214 2622 4568 2276 3869 1919 3106 1566
25
5828 3334 5187 2965 4543 2622 3848 2274 3090 1914
27
5790 3661 5151 3295 4513 2954 3822 2608 3068 2260
29
5816 3987 5184 3623 4549 3281 3863 2940 3115 2592
31
5707 4307 5078 3945 4447 3607 3763 3265 3019 2920
23
23
6853 2965 6211 2599 5567 2256 4874 1910 4122 1564
25
6882 3316 6243 2952 5603 2610 4915 2258 4169 1912
27
6534 3657 5899 3293 5263 2952 4577 2610 3833 2265
29
6795 3955 6206 3618 5575 3279 4893 2940 4156 2599
31
6699 4275 6113 3941 5484 3604 4808 3268 4075 2926
5
15
21
2839 2487 2131 2093 1528 1528 1222 1222 899 899
23
2824 2824 2120 2432 1823 1823 1524 1524 1218 1218
25
2815 2815 2401 2910 2110 2110 1817 1817 1521 1521
27
2966 2966 2679 3247 2392 2392 2103 2103 1810 1810
29
3236 3236 2953 3579 2667 2667 2382 2382 2093 2093
31
3504 3504 3221 3904 2939 2939 2656 2656 2371 2371
17
21
3678 2507 3011 2136 2250 1740 1247 1247 899 899
23
3703 2846 3041 2478 2290 2086 1524 1524 1218 1218
25
3676 3181 3019 2812 2271 2271 1817 1817 1521 1521
27
3667 3510 3013 3144 2392 2392 2103 2103 1810 1810
29
3619 3619 2970 3469 2667 2667 2382 2382 2093 2093
31
3601 3601 3221 3904 2939 2939 2656 2656 2371 2371
19
21
4655 2510 4009 2150 3298 1770 2486 1381 1445 921
23
4630 2858 3988 2498 3281 2130 2477 1743 1439 1275
25
4609 3192 3973 2835 3270 2468 2469 2081 1439 1439
27
4585 3520 3950 3160 3251 2791 2456 2395 1810 1810
29
4560 3847 3929 3494 3234 3130 2443 2443 2093 2093
31
4541 4170 3916 3817 3226 3226 2656 2656 2371 2371
21
21
5592 2496 4957 2141 4265 1782 3500 1413 2611 1005
23
5620 2853 4991 2501 4305 2134 3548 1765 2681 1378
25
5592 3194 4966 2844 4284 2489 3531 2116 2669 1729
27
5556 3524 4934 3176 4256 2823 3506 2459 2650 2077
29
5588 3852 4970 3503 4298 3153 3555 2794 2707 2414
31
5480 4174 4864 3829 4196 3478 3455 3119 2607 2607
23
23
6627 2833 6003 2484 5329 2134 4592 1777 3776 1401
25
6659 3185 6039 2839 5369 2482 4640 2127 3831 1763
27
6311 3524 5694 3181 5025 2830 4294 2475 3480 2102
29
6619 3852 6007 3508 5346 3162 4624 2814 3827 2452
31
6523 4172 5915 3833 5257 3490 4539 3139 3744 2782
7
15
21
2424 2251 1449 1740 1385 1385 1011 1011 427 427
23
2410 2410 2006 2414 1700 1700 1385 1385 1022 1022
25
2594 2594 2299 2787 2001 2001 1696 1696 1381 1381
27
2875 2875 2584 3133 2291 2291 1995 1995 1693 1693
29
3151 3151 2864 3471 2575 2575 2284 2284 1989 1989
31
3423 3423 3138 3803 2852 2852 2565 2565 2276 2276
17
21
3344 2317 2563 1901 1504 1383 1011 1011 427 427
23
3374 2659 2603 2246 1566 1566 1385 1385 1022 1022
25
3351 2995 2582 2581 2001 2001 1696 1696 1381 1381
27
3344 3325 2582 2915 2291 2291 1995 1995 1693 1693
29
3298 3298 2864 3471 2575 2575 2284 2284 1989 1989
31
3281 3281 3138 3803 2852 2852 2565 2565 2276 2276
19
21
4369 2349 3657 1962 2826 1539 1708 1033 427 427
23
4349 2697 3640 2313 2815 1901 1702 1388 1022 1022
25
4332 3032 3625 2649 2807 2239 1702 1702 1381 1381
27
4309 3355 3606 2968 2792 2542 1995 1995 1693 1693
29
4286 3691 3589 3311 2779 2779 2284 2284 1989 1989
31
4273 4014 3580 3639 2775 2775 2565 2565 2276 2276
21
21
5335 2349 4653 1978 3886 1594 2988 1170 1751 650
23
5371 2709 4692 2340 3933 1949 3047 1539 1849 1026
25
5344 3052 4670 2688 3914 2306 3036 1889 1844 1388
27
5310 3384 4641 3020 3890 2642 3015 2235 1827 1733
29
5348 3714 4683 3350 3939 2977 3073 2574 1919 1919
31
5240 4035 4577 3675 3835 3300 2968 2897 2276 2276
23
23
6396 2702 5735 2343 5008 1976 4192 1594 3234 1172
25
6432 3057 5777 2700 5055 2326 4247 1946 3300 1532
27
6083 3394 5425 3036 4702 2670 3884 2288 2900 1857
29
6398 3723 5750 3371 5040 3011 4241 2638 3310 2235
31
6304 4048 5660 3696 4951 3336 4156 2963 3225 2562
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 42 Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0,82 0,75
Speed V2 360 0,64 0,58
Speed V1 260 0,50 0,44
