COOLING CAPACITY OUTPUT - FCLI 44
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 2867 2438 2291 2107 1655 2442 1234 1234 959 959
23 2850 2748 2277 2417 1767 1767 1499 1499 1229 1229
25 2837 2837 2270 2724 2025 2025 1758 1758 1492 1492
27 2796 2796 2540 3077 2277 2277 2014 2014 1751 1751
29 3050 3050 2789 3378 2528 2528 2267 2267 2005 2005
31 3294 3294 3034 3675 2775 2775 2515 2515 2256 2256
17
21 3609 2440 3041 2113 2427 1782 1744 1442 910 910
23 3628 2748 3066 2425 2455 2096 1777 1759 1229 1229
25 3602 3053 3041 2731 2435 2406 1762 1762 1492 1492
27 3590 3357 3034 3037 2430 2430 2014 2014 1751 1751
29 3544 3544 2992 3336 2528 2528 2267 2267 2005 2005
31 3525 3525 3034 3675 2775 2775 2515 2515 2256 2256
19
21 4486 2427 3925 2107 3320 1782 2662 1444 1931 1107
23 4462 2746 3903 2425 3302 2102 2648 1778 1920 1432
25 4441 3051 3885 2733 3288 2412 2637 2088 1915 1752
27 4416 3355 3863 3037 3269 2718 2622 2391 1903 1903
29 4429 3678 3840 3338 3250 3022 2608 2608 2005 2005
31 4409 3971 3826 3635 3240 3240 2601 2601 2256 2256
21
21 5336 2406 4777 2086 4178 1765 3529 1442 2820 1116
23 5400 2756 4805 2414 4209 2096 3565 1767 2862 1442
25 5370 3070 4780 2731 4187 2414 3546 2094 2848 1763
27 5336 3372 4747 3034 4159 2720 3522 2402 2827 2081
29 5360 3671 4777 3336 4192 3022 3560 2708 2871 2387
31 5259 3966 4679 3633 4098 3321 3468 3007 2782 2689
23
23 6316 2731 5724 2393 5130 2077 4491 1759 3798 1440
25 6342 3053 5753 2718 5163 2404 4530 2079 3842 1761
27 6021 3368 5436 3032 4850 2718 4218 2404 3532 2086
29 6262 3642 5719 3332 5137 3020 4509 2708 3830 2393
31 6173 3937 5633 3629 5054 3319 4430 3009 3755 2695
5
15
21 2616 2290 1964 1927 1408 1408 1126 1126 829 829
23 2602 2602 1953 2239 1680 1680 1405 1405 1123 1123
25 2594 2594 2213 2680 1944 1944 1675 1675 1401 1401
27 2733 2733 2468 2990 2204 2204 1938 1938 1668 1668
29 2982 2982 2721 3296 2458 2458 2195 2195 1929 1929
31 3229 3229 2968 3595 2709 2709 2448 2448 2185 2185
17
21 3389 2309 2775 1967 2073 1603 1149 1149 829 829
23 3412 2621 2803 2282 2110 1921 1405 1405 1123 1123
25 3388 2929 2782 2589 2092 2092 1675 1675 1401 1401
27 3379 3233 2777 2895 2204 2204 1938 1938 1668 1668
29 3335 3335 2737 3195 2458 2458 2195 2195 1929 1929
31 3318 3318 2968 3595 2709 2709 2448 2448 2185 2185
19
21 4289 2311 3694 1980 3039 1630 2291 1272 1332 848
23 4267 2632 3675 2301 3024 1961 2282 1605 1326 1175
25 4248 2940 3661 2611 3013 2273 2275 1917 1326 1326
27 4225 3241 3640 2910 2996 2571 2263 2206 1668 1668
29 4202 3543 3621 3218 2980 2883 2251 2251 1929 1929
31 4185 3840 3609 3515 2973 2973 2448 2448 2185 2185
21
21 5153 2298 4568 1972 3931 1641 3226 1301 2406 926
23 5179 2627 4599 2303 3967 1965 3269 1626 2470 1269
25 5153 2942 4577 2619 3948 2292 3254 1948 2460 1592
27 5120 3245 4547 2925 3922 2600 3231 2265 2442 1913
29 5149 3547 4580 3226 3960 2904 3276 2573 2495 2223
31 5050 3844 4483 3526 3866 3203 3184 2872 2402 2402
23
23 6107 2608 5532 2288 4911 1965 4232 1636 3480 1291
25 6136 2933 5565 2615 4947 2286 4275 1959 3530 1624
27 5816 3245 5247 2929 4631 2606 3957 2280 3207 1936
29 6100 3547 5536 3231 4926 2912 4261 2592 3527 2258
31 6011 3842 5450 3530 4845 3214 4183 2891 3450 2562
7
15
21 2233 2073 1335 1603 1276 1276 931 931 393 393
23 2221 2221 1849 2223 1567 1567 1276 1276 942 942
25 2390 2390 2119 2566 1844 1844 1563 1563 1273 1273
27 2649 2649 2381 2885 2112 2112 1838 1838 1560 1560
29 2904 2904 2639 3197 2373 2373 2105 2105 1833 1833
31 3154 3154 2891 3503 2629 2629 2364 2364 2098 2098
17
21 3081 2134 2362 1750 1386 1274 931 931 393 393
23 3109 2448 2399 2069 1443 1443 1276 1276 942 942
25 3088 2758 2380 2377 1844 1844 1563 1563 1273 1273
27 3081 3062 2380 2684 2112 2112 1838 1838 1560 1560
29 3039 3039 2639 3197 2373 2373 2105 2105 1833 1833
31 3024 3024 2891 3503 2629 2629 2364 2364 2098 2098
19
21 4026 2164 3370 1807 2604 1417 1574 951 393 393
23 4007 2484 3355 2130 2594 1750 1568 1278 942 942
25 3992 2792 3341 2440 2587 2062 1568 1568 1273 1273
27 3971 3089 3323 2733 2573 2341 1838 1838 1560 1560
29 3950 3399 3308 3049 2561 2561 2105 2105 1833 1833
31 3938 3697 3299 3351 2557 2557 2364 2364 2098 2098
21
21 4916 2164 4288 1822 3581 1468 2754 1078 1614 599
23 4949 2495 4324 2155 3624 1795 2808 1417 1704 945
25 4925 2811 4303 2476 3607 2123 2797 1740 1699 1278
27 4893 3117 4277 2781 3584 2433 2778 2058 1683 1596
29 4928 3420 4315 3085 3630 2741 2832 2370 1769 1769
31 4829 3716 4218 3384 3534 3039 2735 2668 2098 2098
23
23 5894 2488 5285 2157 4615 1820 3863 1468 2980 1080
25 5927 2815 5323 2486 4658 2142 3913 1792 3041 1411
27 5605 3125 5000 2796 4333 2459 3579 2107 2672 1710
29 5896 3429 5299 3104 4644 2773 3908 2429 3050 2058
31 5809 3728 5215 3403 4563 3072 3830 2729 2972 2360
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 42 Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0,82 0,75
Speed V2 360 0,64 0,58
Speed V1 260 0,50 0,44
