COOLING CAPACITY OUTPUT - FCLI 62
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 3923 3192 3134 2758 2265 3198 1689 1689 1312 1162
23 3899 3597 3115 3164 2417 2417 2051 2051 1681 1489
25 3882 3882 3106 3567 2770 2770 2405 2405 2041 1807
27 3825 3825 3475 4028 3115 3115 2756 2756 2396 2121
29 4173 4173 3815 4423 3458 3458 3101 3101 2744 2429
31 4506 4506 4151 4812 3796 3796 3441 3441 3087 2733
17
21 4937 3194 4161 2766 3320 2333 2386 1888 1246 1050
23 4963 3597 4194 3175 3358 2744 2432 2303 1681 1489
25 4928 3998 4161 3575 3332 3150 2410 2410 2041 1807
27 4911 4395 4151 3976 3325 3325 2756 2756 2396 2121
29 4849 4785 4094 4368 3458 3458 3101 3101 2744 2429
31 4823 4823 4151 4812 3796 3796 3441 3441 3087 2733
19
21 6137 3178 5371 2758 4542 2333 3642 1891 2641 1107
23 6104 3595 5340 3175 4518 2753 3622 2327 2627 1432
25 6076 3995 5316 3578 4499 3158 3608 2733 2620 1752
27 6042 4393 5285 3976 4473 3559 3587 3131 2603 2121
29 6059 4815 5254 4370 4447 3956 3568 3534 2744 2429
31 6033 5199 5235 4760 4432 4346 3558 3558 3087 2733
21
21 7300 3150 6535 2731 5716 2311 4828 1888 3858 1116
23 7388 3608 6573 3161 5759 2744 4878 2314 3915 1442
25 7347 4020 6540 3575 5728 3161 4851 2742 3896 1763
27 7300 4415 6495 3973 5690 3562 4818 3145 3868 2081
29 7333 4807 6535 4368 5735 3956 4870 3545 3927 2387
31 7195 5193 6402 4757 5606 4348 4744 3937 3806 2689
23
23 8641 3575 7831 3134 7019 2719 6145 2303 5197 1440
25 8676 3998 7871 3559 7064 3147 6197 2722 5256 1761
27 8238 4409 7438 3970 6635 3559 5771 3147 4832 2086
29 8567 4768 7824 4362 7028 3954 6168 3545 5240 2393
31 8445 5155 7707 4751 6914 4346 6061 3940 5137 2695
5
15
21 3580 2998 2686 2523 1927 1927 1541 1541 1134 1004
23 3561 3407 2672 2932 2298 2298 1922 1922 1536 1360
25 3549 3549 3027 3509 2660 2660 2291 2291 1917 1698
27 3739 3739 3377 3915 3015 3015 2651 2651 2282 2020
29 4080 4080 3722 4315 3363 3363 3003 3003 2639 2336
31 4418 4418 4061 4707 3706 3706 3349 3349 2989 2646
17
21 4637 3023 3796 2576 2837 2098 1572 1524 1134 1004
23 4668 3432 3834 2987 2887 2515 1922 1922 1536 1360
25 4635 3835 3806 3390 2863 2863 2291 2291 1917 1698
27 4623 4232 3799 3791 3015 3015 2651 2651 2282 2020
29 4563 4563 3744 4183 3363 3363 3003 3003 2639 2336
31 4539 4539 4061 4707 3706 3706 3349 3349 2989 2646
19
21 5868 3026 5054 2592 4158 2134 3134 1665 1822 848
23 5837 3446 5028 3012 4137 2568 3122 2101 1815 1175
25 5811 3849 5009 3418 4123 2976 3113 2510 1815 1497
27 5780 4243 4980 3810 4099 3366 3096 2888 2282 2020
29 5749 4638 4954 4213 4077 3774 3079 3079 2639 2336
31 5725 5028 4937 4602 4068 4068 3349 3349 2989 2646
21
21 7050 3009 6249 2581 5378 2148 4413 1703 3291 926
23 7085 3440 6292 3015 5428 2573 4473 2129 3380 1269
25 7050 3851 6261 3429 5402 3001 4451 2551 3365 1592
27 7004 4249 6221 3829 5366 3404 4420 2965 3341 1913
29 7045 4644 6266 4224 5418 3802 4482 3368 3413 2223
31 6909 5033 6133 4616 5290 4194 4356 3760 3287 2522
23
23 8355 3415 7569 2996 6719 2573 5790 2142 4761 1291
25 8395 3840 7614 3423 6769 2993 5849 2565 4830 1624
27 7957 4249 7178 3835 6335 3412 5413 2985 4387 1936
29 8345 4644 7574 4230 6740 3813 5830 3393 4825 2258
31 8224 5030 7457 4622 6628 4208 5723 3785 4720 2562
7
15
21 3056 2714 1827 2098 1746 1746 1274 1274 538 477
23 3039 3039 2529 2910 2143 2143 1746 1746 1288 1141
25 3270 3270 2898 3360 2522 2522 2139 2139 1741 1541
27 3625 3625 3258 3777 2889 2889 2515 2515 2134 1889
29 3973 3973 3611 4185 3246 3246 2879 2879 2508 2220
31 4316 4316 3956 4586 3596 3596 3234 3234 2870 2541
17
21 4215 2794 3232 2292 1896 1668 1274 1274 538 477
23 4254 3205 3282 2708 1974 1974 1746 1746 1288 1141
25 4225 3611 3256 3112 2522 2522 2139 2139 1741 1541
27 4215 4009 3256 3515 2889 2889 2515 2515 2134 1889
29 4158 4158 3611 4185 3246 3246 2879 2879 2508 2220
31 4137 4137 3956 4586 3596 3596 3234 3234 2870 2541
19
21 5509 2833 4611 2366 3563 1855 2153 1245 538 468
23 5483 3252 4589 2788 3549 2292 2146 1673 1288 1023
25 5461 3655 4570 3194 3539 2700 2146 2096 1741 1493
27 5433 4045 4547 3578 3520 3065 2515 2515 2134 1889
29 5404 4451 4525 3992 3503 3503 2879 2879 2508 2220
31 5387 4840 4513 4387 3499 3499 3234 3234 2870 2541
21
21 6726 2833 5866 2385 4899 1922 3768 1411 2208 599
23 6771 3266 5916 2822 4959 2350 3842 1855 2332 945
25 6738 3680 5887 3241 4935 2780 3827 2278 2324 1278
27 6695 4081 5852 3642 4904 3186 3801 2695 2303 1596
29 6742 4478 5904 4039 4966 3589 3875 3103 2420 1921
31 6607 4865 5771 4431 4835 3978 3742 3493 2870 2436
23
23 8064 3258 7231 2824 6314 2383 5285 1922 4077 1080
25 8109 3686 7283 3255 6373 2805 5354 2347 4161 1411
27 7669 4092 6840 3661 5928 3219 4897 2758 3656 1710
29 8067 4489 7250 4064 6354 3631 5347 3181 4173 2058
31 7948 4881 7135 4456 6242 4023 5240 3573 4065 2360
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 62
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 880 1 1
Speed V3 660 0,79 0,74
Speed V2 500 0,64 0,60
Speed V1 380 0,53 0,49
