COOLING CAPACITY OUTPUT - FCLI 64
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 3631 2957 2901 2555 2097 2963 1563 1563 1215 1215
23 3609 3333 2884 2931 2238 2238 1898 1898 1557 1557
25 3594 3594 2875 3305 2564 2564 2227 2227 1889 1889
27 3541 3541 3217 3732 2884 2884 2551 2551 2218 2218
29 3863 3863 3532 4098 3201 3201 2871 2871 2540 2540
31 4171 4171 3843 4459 3514 3514 3186 3186 2857 2857
17
21 4570 2960 3852 2563 3073 2161 2209 1750 1153 1153
23 4595 3333 3882 2942 3109 2543 2251 2133 1557 1557
25 4561 3704 3852 3313 3084 2919 2231 2231 1889 1889
27 4546 4072 3843 3683 3078 3078 2551 2551 2218 2218
29 4489 4433 3790 4047 3201 3201 2871 2871 2540 2540
31 4464 4464 3843 4459 3514 3514 3186 3186 2857 2857
19
21 5681 2944 4972 2555 4204 2161 3371 1752 2445 1343
23 5651 3330 4943 2942 4182 2550 3353 2156 2432 1737
25 5624 3701 4921 3315 4165 2926 3340 2532 2425 2126
27 5593 4070 4892 3683 4140 3297 3320 2901 2410 2410
29 5609 4461 4864 4049 4116 3666 3303 3274 2540 2540
31 5584 4817 4846 4410 4103 4026 3294 3294 2857 2857
21
21 6757 2919 6050 2530 5291 2141 4469 1750 3572 1353
23 6839 3343 6085 2929 5331 2543 4515 2144 3625 1750
25 6801 3724 6054 3313 5302 2929 4491 2540 3607 2138
27 6757 4090 6012 3681 5267 3300 4460 2914 3580 2525
29 6788 4453 6050 4047 5309 3666 4509 3284 3636 2896
31 6660 4812 5926 4407 5190 4029 4392 3648 3523 3261
23
23 7999 3313 7249 2903 6497 2520 5688 2133 4811 1747
25 8032 3704 7286 3297 6539 2916 5737 2522 4866 2136
27 7626 4085 6885 3678 6142 3297 5342 2916 4473 2530
29 7930 4418 7242 4042 6506 3663 5710 3284 4850 2903
31 7818 4776 7134 4402 6400 4026 5611 3650 4756 3269
5
15
21 3314 2778 2487 2338 1784 1784 1426 1426 1049 1049
23 3296 3157 2474 2717 2128 2128 1779 1779 1422 1422
25 3285 3285 2802 3251 2463 2463 2121 2121 1775 1775
27 3461 3461 3126 3627 2791 2791 2454 2454 2112 2112
29 3777 3777 3446 3998 3113 3113 2780 2780 2443 2443
31 4090 4090 3759 4361 3430 3430 3100 3100 2767 2767
17
21 4293 2801 3514 2387 2626 1944 1455 1412 1049 1049
23 4321 3180 3550 2768 2672 2330 1779 1779 1422 1422
25 4290 3553 3523 3141 2650 2650 2121 2121 1775 1775
27 4279 3921 3516 3512 2791 2791 2454 2454 2112 2112
29 4224 4224 3466 3875 3113 3113 2780 2780 2443 2443
31 4202 4202 3759 4361 3430 3430 3100 3100 2767 2767
19
21 5432 2804 4678 2402 3849 1977 2901 1542 1687 1028
23 5404 3192 4654 2791 3830 2379 2890 1947 1680 1425
25 5379 3566 4636 3167 3816 2757 2882 2325 1680 1680
27 5351 3932 4610 3530 3794 3118 2866 2676 2112 2112
29 5322 4297 4586 3903 3774 3497 2851 2851 2443 2443
31 5300 4658 4570 4264 3766 3766 3100 3100 2767 2767
21
21 6526 2788 5785 2392 4978 1990 4085 1578 3047 1123
23 6559 3187 5825 2793 5024 2384 4140 1972 3128 1540
25 6526 3568 5796 3177 5000 2781 4121 2364 3115 1931
27 6484 3937 5759 3548 4967 3154 4092 2747 3093 2320
29 6521 4303 5801 3914 5016 3522 4149 3121 3159 2696
31 6396 4663 5677 4277 4897 3886 4032 3484 3042 3042
23
23 7734 3164 7006 2775 6219 2384 5360 1985 4407 1565
25 7772 3558 7048 3172 6266 2773 5415 2376 4471 1970
27 7366 3937 6645 3553 5864 3162 5011 2765 4061 2348
29 7725 4303 7011 3919 6239 3533 5397 3144 4467 2740
31 7613 4661 6903 4282 6136 3898 5298 3507 4370 3108
7
15
21 2829 2514 1691 1944 1616 1616 1180 1180 498 498
23 2813 2813 2341 2696 1984 1984 1616 1616 1193 1193
25 3027 3027 2683 3113 2335 2335 1980 1980 1612 1612
27 3356 3356 3016 3499 2674 2674 2328 2328 1975 1975
29 3677 3677 3342 3878 3005 3005 2665 2665 2322 2322
31 3995 3995 3662 4249 3329 3329 2994 2994 2657 2657
17
21 3902 2589 2992 2123 1755 1545 1180 1180 498 498
23 3938 2970 3038 2509 1828 1828 1616 1616 1193 1193
25 3911 3346 3014 2883 2335 2335 1980 1980 1612 1612
27 3902 3714 3014 3256 2674 2674 2328 2328 1975 1975
29 3849 3849 3342 3878 3005 3005 2665 2665 2322 2322
31 3830 3830 3662 4249 3329 3329 2994 2994 2657 2657
19
21 5099 2624 4268 2192 3298 1719 1993 1154 498 498
23 5075 3013 4248 2584 3285 2123 1986 1550 1193 1193
25 5055 3387 4231 2960 3276 2502 1986 1942 1612 1612
27 5029 3747 4209 3315 3259 2839 2328 2328 1975 1975
29 5002 4123 4189 3699 3243 3243 2665 2665 2322 2322
31 4987 4484 4178 4065 3239 3239 2994 2994 2657 2657
21
21 6226 2624 5430 2210 4535 1780 3488 1307 2044 726
23 6268 3026 5476 2614 4590 2177 3556 1719 2158 1146
25 6237 3410 5450 3003 4568 2576 3543 2110 2152 1550
27 6197 3781 5417 3374 4539 2952 3519 2497 2132 1936
29 6241 4149 5465 3742 4597 3325 3587 2875 2240 2240
31 6116 4507 5342 4106 4476 3686 3464 3236 2657 2657
23
23 7465 3018 6693 2617 5845 2208 4892 1780 3774 1310
25 7507 3415 6742 3016 5900 2599 4956 2174 3852 1711
27 7099 3791 6332 3392 5487 2983 4533 2555 3384 2075
29 7467 4159 6711 3765 5882 3364 4950 2947 3863 2497
31 7357 4522 6605 4129 5778 3727 4850 3310 3763 2862
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 64 Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0,82 0,75
Speed V2 360 0,64 0,58
Speed V1 260 0,50 0,43
