9
Minimum average water temperature
If the fan coil is working in continuous
cooling mode in an environment where
the relative humidity is high, condensate
might form on the air delivery and
on the outside of the device. This
condensate might be deposited on any
objects underneath and on the floor.
To avoid condensate on the external struc-
ture of the apparatus with the fan in
operation, the average temperature of
the water must not be lower than the lim-
its shown in the table below, that depend
on the thermo-hygrometric condition of
the air in the environment.
The limits mentioned above refer to opera-
tion while the fan is set
to its minimum speed level.
TECHNICAL DATA AND OPERATING LIMITS
- at the maximum motor speed;
- the total input power is determined by adding the input power
for the unit to the input power for the accessories connected and
declared in the corresponding manuals.
Water temperature
In order to prevent air stratification in the
room, and therefore to achieve improved
mixing, it is advisable not to supply the fan coil
with water at a temperature over 65°C.
The use of water at high temperatures
could cause squeaking due to the different
thermal expansions of the elements (plastics
and metals), this does not however cause
damage to the unit if the maximum operating
temperature is not exceeded.
FCLI 32 34 42 44 62 64 82 122 124
Maximum recommended temperature 65°C
Maximum water inlet temperature 80°C
kPa 800 (8 bar)
kPa 100 (1 bar)
Room temperature limit R.T.
0°C<Ta<40 °C
Room temperature limit R.H.
R.H.< 85%
°C 100 50 100 50 150 50 250 350 50
°C 750 400 750 400 1050 400 1750 2450 400
Minimum delivery (cooling) °C 100 100 100 100 150 150 250 350 250
Maximum delivery (cooling) °C 750 750 750 750 1050 1050 1750 2450 1750
Maximum input current A
0.22 0.22 0.33 0.33 0.37 0.37 0.7
0.75
0.75
Power supply V / Hz
230V (±10%) 50 Hz
230V (±10%) 50/60 Hz
MINIMUM AVERAGE WATER TEMPERATURE [°C]
Ambient air temperature with dry bulb
21 23 25 27 29 31
Ambient air temperature
with wet bulb
15 3 3 3 3 3 3
17 3 3 3 3 3 3
19 3 3 3 3 3 3
21 6 5 4 3 3 3
23 - 8 7 6 5 5
