26
ACCESSORIES
Compulsory accessories GLFI and GLLI, are essential
for the operation of the units:
• GLFI10 (600x600)
White RAL 9010
.
Delivery grille with louvers manually adjustable
and air intake. Combined with wall-mounted
control panel.
Compatible with VMF = no;
Compatible with the electrical resistance = no
• GLFI10M (600x600)
White RAL 9010
.
Delivery grille with adjustable louvers by
means of a remote control and air intake, sup-
plied with an infrared receiver with emergency
operation switch.
Compatible with VMF= yes;
Compatible with the electrical resistance = yes
• GLFI10N (600x600)
White RAL 9010.
Delivery grille with Manually adjustable fins
and air intake, with "VMF System" advanced
electronic thermostat. Individual units, or net-
work master also requires a wired control panel
(VMF-E4 compulsory accessory).
Compatible with VMF = yes;
Compatible with the electrical resistance = yes
• GLFI10EH (600x600)
White RAL 9010
.
Outlet grille with manually adjustable fins and air
intake. Prepared for coupling with the RXLE elec-
trical resistance accessory, which can be controlled
by an external thermostat, also not supplied by
Aermec, provided that the minimum number of
revolutions required for correct resistance operation
is respected.
Compatible with VMF = no;
Compatible with the electrical resistance = yes
• GLLI100 (600x600)
Delivery grille with louvers manually adjustable
and air intake. Combined with wall-mounted
control panel. White RAL 9010.
• GLLI100N (600x600)
Delivery grille with Manually adjustable fins
and air intake, with "VMF System" advanced
electronic thermostat. Individual units, or net-
work master also requires a wired control panel
(VMF-E4 compulsory accessory). White RAL
9010.
• GLLI100EH (600x600)
Outlet grille with manually adjustable fins and air
intake. Prepared for coupling with the RXLE electrical
resistance accessory, which can be controlled by
an external thermostat, even if the Aermec is not
supplied, provided that the minimum number of
revolutions required for correct resistance operation
is respected. RAL 9010 white color.
•
GLLI20 (840x840)
Delivery grille with louvers manually adjustable
and air intake. Combined with wall-mounted
control panel. White RAL 9010.
•
GLLI20N (840x840)
Delivery grille with Manually adjustable fins
and air intake, with "VMF System" advanced
electronic thermostat. Individual units, or net-
work master also requires a wired control panel
(VMF-E4 compulsory accessory). White RAL
9010.
Control panel
A range of dedicated controllers, wall-mounted or on the
machine, is available but it is essential to choose between
these panels for simple and complete tuning, for more
details please refer to the dedicated sheet.
Probes and accessory for control panels
•
WMT21: Electronic thermostat with LCD display
(wall installation).
• SWAI: Water temperature for WMT21. Cable lenght
L=2m.
• SW4 : Water temperature probe for the control of
maximum / minimum temperature (2 pipe system)
or for the control of minimum temperature in the
heating coil (4-pipe system)
VMF system
- VMF-E4: Wall mounted user interface allowing con-
trol via a capacitive touch keyboard.
- VMF-SW1: Additional water sensor for 4 - pipe
ssytem with E1 thermostats offering maximum con-
trol in the cooling range
Electrical heater
• RXLE - RXLE20 : electric heater for heating, can be
installed on the single-fan FCL units.
Valve kit
• VHL1 - VHL20 : motor-driven three-way valve for
the heating battery in 4-pipe systems. Obligatory
accessory in 4-pipe systems.
• VHL2 - VHL22 : motor-driven two-way valve for
the heating battery in 4-pipe systems. Obligatory
accessory in 4-pipe systems with variable flow
rates.
Accessory for Installation
• FEL10 : kit n°5 electrostatically pre-charged air filter,
with fire resistance class 2 (UL 900).
• KFL: Delivery flange, allowing the air to be directed
to an adjacent room.
• KFL20: delivery flange, allowing the air to be
directed to an adjacent room. Up to three KFL20
can be assembled on a single unit.
• KFLD : suction flange, allows to introduce external
air directly into the room without mixing.
• KFLD20: suction flange, allows to introduce external
air directly into the room without mixing. Up to two
KFL20D can be assembled on a single unit.
• FCLMC10 / FCLMC20
is a perimeter case in galvanised and painted sheet
steel, which is used when the fan coil is installed out-
side the suspended ceiling. It is used for aesthetics
and protection, therefore the technical features
of the FCL remain unvaried.
For more details on the control panels and VMF system
refer to the dedicated sheet
(1) CLMC20 requires the combination with the FCLMC20IK accessory
FCLI
32 34 42 44 62 64 82 122 124
COMPULSARY GLL ACCESSORIES, ESSENTIAL FOR UNIT OPERATION: GLFI e GLLI and dedicated accessories
GLFI10 • • • • • • - - -
GLFI10EH • • • • • • - - -
RXLE • - • - • - - - -
GLFI10M e GLFI10N • • • • • • - - -
VMF-E4 • • • • • • - - -
VMF-SW1 • • • • • • - - -
TLF • • • • • • - - -
RXLE • • • • • • - - -
GLLI100 • • • • • • - - -
GLLI100N • • • • • • - - -
VMF-E4 • • • • • • - - -
VMF-SW1 • • • • • • - - -
RXLE • • • • • • - - -
GLLI100EH • • • • • • - - -
RXLE • - • - • - - - -
GLLI20 - - - - - - • • •
GLLI20N - - - - - - • • •
VMF-E4 - - - - - - • • •
VMF-SW1 - - - - - - • • •
RXLE20 - - - - - - • • •
Probes and accessories for control panels
WMT21 • • • • • • • • •
SWAI In combination with WMT21
SW4 • • • • • • • • •
Water valve
3 way valve kit for 4 pipe systems
VHL1 - •
-
•
-
•
- - -
VHL20 - - - - - - - - •
2 way valve kit for 4 pipe systems
VHL2 - •
-
•
-
•
- - -
VHL22 - - - - - - - - •
Installation accessories
FEL10 • • • • • • - - -
KFL • • • • • • - - -
KFL20 - - - - - - • • •
KFLD • • • • • • - - -
KFLD20 - - - - - - • • •
Perimeter case
FCLMC10 • • • • • • -
- -
FCLMC20
- - - - - -
• • •
FCLMC20IK (1)
- - - - - -
• • •
