10 WEIGHT DISTRIBUTION AND CENTRES OF GRAVITY
WEIGHT DISTRIBUTION AND CENTRES OF GRAVITY WHEN EMPTY
Size 0280 0300 0330 0350 0550 0600 0650 0675 0750 0800 0900 1000 1100 1250
INTEGRATED HYDRONIC KIT: 00
Centre of gravity (empty)
X A in 33.3 32.6 32.6 32.5 54.6 52.3 51.9 50.5 89.6 115.1 117.9 113.5 113.1 111.9
Y A in 22.4 22.0 22.5 22.4 20.7 20.7 20.5 19.7 21.0 22.1 22.0 21.9 22.0 21.8
Weight distribution in % on the supports (empty)
1 A % 27% 28% 28% 28% 28% 29% 29% 28% 10% 14% 13% 14% 15% 15%
2 A % 25% 27% 26% 26% 30% 32% 32% 34% 11% 14% 13% 14% 14% 15%
3 A % 25% 23% 24% 24% 20% 19% 19% 17% 28% 12% 11% 11% 11% 11%
4 A % 23% 23% 22% 22% 22% 21% 21% 21% 29% 12% 10% 11% 11% 10%
5 A % - - - - - - - - 11% 15% 18% 16% 16% 17%
6 A % - - - - - - - - 11% 14% 17% 16% 16% 16%
7 A % - - - - - - - - - 10% 9% 9% 9% 8%
8 A % - - - - - - - - - 9% 9% 9% 8% 8%
9 A % - - - - - - - - - - - - - -
10 A % - - - - - - - - - - - - - -
INTEGRATED HYDRONIC KIT: 01, 03
Centre of gravity (empty)
X A in 57.6 56.1 55.6 55.5 71.8 68.3 67.7 66.4 104.5 133.5 135.0 130.0 129.0 127.5
Y A in 18.1 17.8 18.1 18.1 21.3 21.2 21.0 20.9 21.7 22.0 21.9 21.8 21.9 21.8
Weight distribution in % on the supports (empty)
1 A % 16% 17% 17% 18% 20% 22% 22% 22% 11% 13% 12% 13% 13% 13%
2 A % 13% 14% 14% 14% 21% 22% 23% 24% 11% 12% 11% 13% 13% 13%
3 A % 27% 26% 27% 27% 27% 26% 26% 26% 20% 11% 10% 11% 10% 10%
4 A % 22% 22% 22% 21% 28% 27% 28% 27% 20% 11% 10% 10% 10% 10%
5 A % 12% 11% 11% 11% 2% 1% 1% 1% 14% 11% 13% 12% 12% 12%
6 A % 10% 9% 9% 9% 2% 1% 1% 1% 14% 10% 13% 12% 12% 12%
7 A % - - - - - - - - 4% 14% 14% 13% 13% 13%
8 A %
- - - - - - - - 4% 13% 14% 13% 13% 13%
9 A % - - - - - - - - - 2% 2% 2% 2% 1%
10 A % - - - - - - - - - 2% 2% 2% 1% 1%
INTEGRATED HYDRONIC KIT: 02, 04
Centre of gravity (empty)
X A in 58.8 57.3 56.9 56.7 72.9 69.4 69.1 67.7 106.3 135.6 136.9 131.9 130.8 129.3
Y A in 18.7 18.3 18.6 18.5 21.3 21.2 21.0 20.9 21.7 22.0 21.9 21.8 21.9 21.7
Weight distribution in % on the supports (empty)
1 A % 16% 16% 17% 17% 20% 21% 21% 21% 11% 12% 12% 13% 13% 13%
2 A % 12% 13% 13% 13% 20% 22% 22% 23% 11% 12% 11% 13% 13% 13%
3 A % 28% 27% 28% 28% 27% 27% 27% 26% 20% 11% 10% 10% 10% 10%
4 A % 22% 22% 21% 21% 28% 28% 28% 28% 20% 11% 10% 10% 10% 10%
5 A % 13% 12% 12% 12% 2% 1% 1% 1% 15% 10% 13% 11% 12% 12%
6 A % 10% 9% 9% 9% 2% 1% 1% 1% 15% 10% 12% 11% 12% 12%
7 A % - - - - - - - - 4% 14% 14% 14% 14% 13%
8 A % - - - - - - - - 4% 14% 14% 14% 14% 13%
9 A % - - - - - - - - - 3% 2% 2% 2% 2%
10 A % - - - - - - - - - 2% 2% 2% 2% 2%
INTEGRATED HYDRONIC KIT: P1, P3
Centre of gravity (empty)
X A in 43.1 42.0 41.8 41.7 56.7 54.3 54.2 52.9 94.9 118.0 120.5 116.0 115.5 114.3
Y A in 17.2 16.9 17.2 17.2 20.7 20.7 20.5 19.7 20.6 22.1 22.0 21.9 21.9 21.8
Weight distribution in % on the supports (empty)
1 A % 31% 31% 32% 32% 27% 28% 28% 27% 8% 14% 13% 14% 14% 15%
2 A % 27% 28% 28% 28% 29% 31% 31% 33% 9% 13% 13% 14% 14% 14%
3 A % 22% 21% 21% 21% 21% 20% 20% 18% 28% 12% 10% 11% 10% 10%
4 A % 19% 19% 19% 19% 23% 22% 22% 22% 30% 11% 10% 10% 10% 10%
5 A % - - - - - - - - 12% 15% 17% 16% 16% 16%
6 A % - - - - - - - - 13% 14% 17% 16% 16% 16%
7 A
% - - - - - - - - - 11% 10% 10% 10% 9%
8 A % - - - - - - - - - 10% 10% 10% 9% 9%
9 A % - - - - - - - - - - - - - -
10 A % - - - - - - - - - - - - - -
INTEGRATED HYDRONIC KIT: P2, P4
Centre of gravity (empty)
X A in 45.2 44.1 43.8 43.8 58.5 55.9 56.2 54.9 97.2 120.5 122.8 118.3 117.7 116.5
Y A in 17.9 17.5 17.9 17.8 20.7 20.7 20.5 19.7 20.6 22.1 21.9 21.9 21.9 21.8
Weight distribution in % on the supports (empty)
1 A % 31% 31% 31% 31% 26% 27% 27% 26% 8% 14% 13% 14% 14% 14%
2 A % 25% 26% 26% 26% 28% 30% 30% 31% 9% 13% 12% 14% 14% 14%
3 A % 24% 23% 23% 23% 22% 21% 21% 19% 27% 11% 10% 10% 10% 10%
4 A % 20% 20% 19% 19% 24% 23% 23% 23% 29% 11% 9% 10% 10% 10%
5 A % - - - - - - - - 13% 15% 17% 16% 16% 16%
