22.05 4037360_01 31
Size 0280 0300 0330 0350 0550 0600 0650 0675 0750 0800 0900 1000 1100 1250
6 A % - - - - - - - - 14% 14% 17% 15% 16% 16%
7 A % - - - - - - - - - 11% 11% 11% 10% 10%
8 A % - - - - - - - - - 11% 11% 10% 10% 10%
9 A % - - - - - - - - - - - - - -
10 A % - - - - - - - - - - - - - -
WEIGHT DISTRIBUTION AND CENTRES OF GRAVITY DURING OPERATION
Size 0280 0300 0330 0350 0550 0600 0650 0675 0750 0800 0900 1000 1100 1250
INTEGRATED HYDRONIC KIT: 00
Centre of gravity (during operation)
X A in 33.5 32.9 32.8 32.8 54.9 52.6 52.2 50.9 87.1 116.0 118.9 114.5 114.1 112.9
Y A in 22.3 21.9 22.4 22.3 20.7 20.6 20.4 19.6 21.6 22.0 21.9 21.8 21.9 21.7
Weight distribution in % on the supports (during operation)
1 A % 27% 27% 28% 28% 28% 29% 29% 28% 12% 14% 13% 14% 14% 15%
2 A % 25% 26% 26% 26% 30% 32% 32% 34% 12% 13% 13% 14% 14% 15%
3 A % 25% 24% 24% 24% 20% 19% 19% 17% 27% 12% 10% 11% 11% 10%
4 A % 23% 23% 22% 22% 22% 21% 21% 21% 27% 12% 10% 11% 10% 10%
5 A % - - - - - - - - 11% 15% 18% 16% 17% 17%
6 A % - - - - - - - - 11% 15% 17% 16% 16% 17%
7 A % - - - - - - - - - 10% 10% 9% 9% 9%
8 A % - - - - - - - - - 9% 9% 9% 9% 9%
9 A % - - - - - - - - - - - - - -
10 A % - - - - - - - - - - - - - -
INTEGRATED HYDRONIC KIT: 01, 03
Centre of gravity (during operation)
X A in 71.7 70.1 69.5 69.3 90.6 86.5 85.6 84.2 125.5 155.9 156.1 150.9 149.3 147.5
Y A in 20.8 20.4 20.6 20.6 21.5 21.4 21.3 26.0 21.8 22.0 21.9 21.8 21.9 21.8
Weight distribution in % on the supports (during operation)
1 A % 14% 15% 15% 15% 15% 17% 17% 17% 10% 11% 10% 11% 12% 12%
2 A % 9% 9% 9% 10% 15% 17% 17% 18% 10% 11% 10% 11% 11% 12%
3 A % 24% 23% 24% 24% 18% 18% 18% 18% 15% 8% 7% 7% 7% 7%
4 A % 15% 15% 15% 15% 18% 19% 19% 19% 15% 7% 7% 7% 7% 7%
5 A % 24% 23% 23% 22% 17% 15% 14% 14% 12% 10% 12% 11% 11% 11%
6 A % 15% 15% 14% 14% 17% 15% 14% 14% 12% 10% 12% 11% 11% 11%
7 A % - - - - - - - - 13% 12% 12% 12% 12% 11%
8 A %
- - - - - - - - 13% 12% 12% 12% 11% 11%
9 A % - - - - - - - - - 10% 10% 9% 9% 8%
10 A % - - - - - - - - - 10% 9% 9% 8% 8%
INTEGRATED HYDRONIC KIT: 02, 04
Centre of gravity (during operation)
X A in 72.2 70.7 70.1 69.9 91.1 87.1 86.3 84.9 126.6 157.2 157.3 152.2 150.5 148.7
Y A in 21.1 20.7 20.9 20.9 21.5 21.4 21.2 26.0 21.8 22.0 21.9 21.8 21.9 21.7
Weight distribution in % on the supports (during operation)
1 A % 13% 14% 14% 14% 15% 16% 16% 17% 10% 11% 10% 11% 11% 12%
2 A % 8% 9% 9% 9% 15% 17% 17% 18% 10% 10% 10% 11% 11% 12%
3 A % 25% 24% 25% 25% 18% 19% 19% 18% 15% 8% 7% 7% 7% 7%
4 A % 15% 15% 15% 15% 19% 19% 20% 19% 15% 7% 6% 7% 7% 7%
5 A % 24% 23% 23% 23% 16% 15% 14% 14% 13% 10% 12% 11% 11% 11%
6 A % 15% 14% 14% 14% 17% 15% 14% 14% 13% 9% 11% 11% 11% 11%
7 A % - - - - - - - - 13% 12% 13% 12% 12% 12%
8 A % - - - - - - - - 13% 12% 12% 12% 12% 12%
9 A % - - - - - - - - - 10% 10% 9% 9% 8%
10 A % - - - - - - - - - 10% 9% 9% 8% 8%
INTEGRATED HYDRONIC KIT: P1, P3
Centre of gravity (during operation)
X A in 43.9 42.9 42.6 42.6 57.4 55.0 54.9 53.6 90.4 119.5 122.0 117.6 117.0 115.8
Y A in 17.2 16.9 17.2 17.2 20.6 20.6 20.4 19.6 21.5 22.0 21.9 21.7 21.8 21.7
Weight distribution in % on the supports (during operation)
1 A % 31% 31% 32% 32% 26% 27% 27% 27% 12% 14% 13% 14% 14% 14%
2 A % 27% 28% 27% 28% 29% 30% 31% 32% 12% 13% 12% 14% 14% 14%
3 A % 23% 22% 22% 22% 21% 20% 20% 19% 26% 11% 10% 10% 10% 10%
4 A % 20% 20% 19% 19% 24% 22% 22% 22% 26% 11% 10% 10% 10% 10%
5 A % - - - - - - - - 12% 15% 17% 16% 16% 16%
6 A % - - - - - - - - 12% 15% 17% 16% 16% 16%
7 A
% - - - - - - - - - 11% 11% 10% 10% 10%
8 A % - - - - - - - - - 11% 10% 10% 10% 10%
9 A % - - - - - - - - - - - - - -
10 A % - - - - - - - - - - - - - -
INTEGRATED HYDRONIC KIT: P2, P4
Centre of gravity (during operation)
X A in 45.9 44.8 44.6 44.5 59.2 56.7 56.9 55.6 92.7 121.9 124.3 119.8 119.1 117.9
Y A in 17.9 17.5 17.8 17.8 20.6 20.6 20.4 19.6 21.5 22.0 21.8 21.7 21.8 21.7
Weight distribution in % on the supports (during operation)
1 A % 30% 30% 31% 31% 25% 26% 26% 26% 12% 13% 12% 14% 14% 14%
