AERMEC NLC - Max Static Useful Pressure of the Fans

6 - EN
EN
NLC_A cod: 1606.4037360_00
6. MAX STATIC USEFUL PRESSURE OF THE FANS
NLC A Total air ow rate
Total air ow rate
cfm
ESP [Pa]
0 100 200 300 400 Max ESP [Pa]
Parameter fans max Volts [V]
0750 69000 40611,866 6,6/8,3 7,5/8,7 8,3/9,2 9,2/9,6 10,0/10,0 400
WARNING
The weight of the piping must
not be borne by the appliance
WARNING
Remove the safety protecons
before carrying out the
connecon to the air exhaust
ducts.
Example of ductwork
WARNING
The weight of the piping must
not be borne by the appliance
WARNING
Remove the safety protecons
before carrying out the
connecon to the air exhaust
ducts.
Example of ductwork
