AERMEC NRA-H - Page 15

15
CARATTERISTICHE
•
FEATURES
Performances refer to following conditions:
❄ - temperature of processed water = 7 °C; ∆ t = 5 °C
- ambient air temperature = 35 °C.
❊ - temperature of processed water = 50 °C; ∆ t = 5 °C
- ambient air temperature = 7 °C b. s. / 6 °C b. u.
 - Sound pressure measured at 10 mt.s in free field
conditions Q = 2.
(1) - M = male connection
F = female connection.
N.B.: All data refers to unit in standard version.
Power supply = 400 V - 3+N - 50 Hz (±10%).
302 302 H 352 352 H 402 402 H 502 502 H
58,5 57,5 71 71 83,2 79 93 87
21,3 22,35 26,1 25,1 29,3 29,35 35,15 36,5
37 37 49 48,5 51 50,6 62,3 67,2
2,74 2,57 2,72 2,83 2,84 2,69 2,64 2,38
10060 9890 12220 12210 14320 13590 16000 14960
35 34 30,5 30,5 32,8 29,6 33,2 29
- 65,7 - 82 - 87 - 100
- 22,05 - 28,2 - 26,5 - 34
- 39 - 52,5 - 47 - 63,6
- 2,98 - 2,91 - 3,28 - 2,94
- 11300 - 14100 - 14960 - 17200
- 39 - 33,2 - 29,3 - 31,2
15 15 18,3 18,1 21,2 20,4 24,1 23,3
2580 2580 3150 3110 3650 3510 4150 4010
8,7 8,7 13,0 12,7 17,4 16 9,0 8,4
1” M 1” M 1” M 1” M 1” M 1” M 1” M 1” M
2 x 2,77 2 x 2,77 2 x 2,97 2 x 2,97 2 x 2,97 2 x 2,97 2 x 2,97 2 x 2,97
22222333
15,6 16,7 18 26,3 20,4 30,9 25,2 38
21000 21000 28000 28000 28000 28000 28000 28000
46 47 48 48 48 50 48 50
2 x 2,64 2 x 2,64 1 x 8,5 1 x 6,3 1 x 11 1 x 11 1 x 12,5 1 x 8
2 x 1” M 2 x 1” M 2” F 2” F 2” F 2” F 2” F 2” F
Alternativo Alternativo
Scroll Scroll
Alternativo Alternativo Alternativo Alternativo
Reciprocating Reciprocating Reciprocating Reciprocating Reciprocating Reciprocating
2 / 2 2 / 2 2 / 2 2 / 2 2 / 2 2 / 2 2 / 2 2 / 2
0/50/100 0/50/100 0/50/100 0/50/100 0/50/100 0/50/100 0/50/100 0/50/100
6 x 130 6 x 130 8 x 130 8 x 130 8 x 130 8 x 134 8 x 140 8 x 140
870 870 870 870 870 870 870 870
56,2 56,2 59,5 59,5 73,5 73,5 92 92
135 135 168 168 178 178 225 225
1650 1650 1650 1650 1650 1650 1650 1650
1100 1100 1100 1100 1100 1100 1100 1100
2150 2150 2950 2950 2950 2950 2950 2950
500 511 835 832 800 811 845 980
