AERMEC NRA Series User Manual

8
MOD. ROMEO TP1 DRE AER485 PGS GP DCPX RIF AVX
NRA HL S.a C.a. P1/P2/P3/P4
0800 •
std.
25 (x4) • • 260
std.
64 151 15 2 151
0900 •
std.
25 (x2) - 30 (x2) • • 260
std.
74 151 15 2 151
1000 •
std.
30 (x4) • • 260
std.
84 151 15 2 151
1250 •
std.
38 (x4) • • 350
std.
84 153 154 15 3
1400 •
std.
38 (x2) - 31 (x3) • • 350
std.
8 5 153 154 15 3
1500 •
std.
30 (x6) • • 350
std.
8 6 153 154 15 3
1650 •
std.
38 (x3) - 31 (x3) • • 500
std.
86 604 602 P1-P3=605/P2-P4=606
1800 •
std.
38 (x6) • • 500
std.
86 604 602 P1-P3=605/P2-P4=606
NRA C
0800 • • (x2) 25 (x4) • • 260 29 64 151 152 151
0900 • • (x2) 25 (x2) - 30 (x2) • • 260 29 74 151 152 151
1000 • • (x2) 30 (x4) • • 260 29 84 151 152 151
1250 • • (x2) 38 (x4) • • 350 30 84 153 154 153
1400 • • (x2) 38 (x2) - 31 (x3) • • 350 30 85 153 154 153
1500 • • (x2) 30 (x6) • • 350 30 86 153 154 153
1650 • • (x2) 38 (x3) - 31 (x3) • • 500 30 86
1800 • • (x2) 38 (x6) • • 500 30 86
NRA LC
0800 • • (x2) 25 (x4) • • 260
std.
64 151 15 2 151
0900 • • (x2) 25 (x2) - 30 (x2) • • 260
std.
74 151 15 2 151
1000 • • (x2) 30 (x4) • • 260
std.
84 151 15 2 151
1250 • • (x2) 38 (x4) • • 350
std.
84 153 154 15 3
1400 • • (x2) 38 (x2) - 31 (x3) • • 350
std.
8 5 153 154 15 3
1500 • • (x2) 30 (x6) • • 350
std.
8 6 153 154 15 3
1650 • • (x2) 38 (x3) - 31 (x3) • • 500
std.
86
1800 • • (x2) 38 (x6) • • 500
std.
86
5 TECHNICAL DATA
5.1 NOMINAL REFERENCE
CONDITIONS
The technical data is calculated as follows
Cooling mode
- Temperature water inlet 12 °C
- Temperature of processed water 7 °C
- Ambient air temperature 35 °C
- ∆t 5°C
Heating mode
- Temperature of processed water 50 °C
- Ambient air temperature b.s. 7 °C
b.u. 6 °C
- ∆t 5°C
Sound Power
Aermec determines the value of sound
power on the basis of measurements per-
formed in compliance with regulation 9614,
in respect with that requested by Eurovent
certification.
(1) Sound Pressure
Sound pressure in free field on a reflective
surface (factor of directionality Q=2), at 10
metres from the external surface of the
unit, using the parallel expansion method
(box-method, ISO 3744)
NOTE
- The noise data refer to configuration without
pump.
- For heat pumps the data refers to functioning
in cooling mode
E.S.E.E.R.
There is a growing awareness in Europe
as well that attention needs to be paid
to the electricity consumed by air condi-
tioning machines. For many years now in
the United States talk has not just been
about efficiency in the plan conditions, but
an assessment index is used that takes
account of the marginal operation of the
unit under plan conditions and the greater
use with partial loads with external air that
is less than that planned and in conditions
of compressor capacity control. In Europe
the proposed EECCAC (Energy Efficiency
and Certification of Central Air Conditioner)
has been adopted, the ESEER (European
Seasonal Energy Efficiency Ratio), that has
the purpose of being able to compare the
chillers with each other.
After estimating the total energy required
by the system during summer manage-
ment (kW/h), the seasonal electrical ener-
gy consumption can be deduced with this
formula:
Input energy = Required energy
Efficiency index
The actual energy calculation can be obtai-
ned, more accurately, by considering:
1. The load profile with external tempera-
ture
2. The climatic profile
3. The total number of hours
With this data, every consultant or desi-
gner will be able to his or her evaluations.
KEY
DRE - RIF It must be factory-mounted
S.a = Without storage tank
C.a With storage tank
NOTE
The numbers in parenthesis indicate the
necessary quantity
ESEER = (3xEER100%+33xEER75%+41xEER50%+23xEER25%) / 100
Acqua uscita evaporatore 7 °C
∆T a pieno carico 5 °C
Carico 100% 75% 50% 25%
Temperatura aria esterna 35°C 30°C 25°C 20°C
