26
14 SOUND DATA
Sound Power
Aermec determines the value of sound
power on the basis of measurements per-
formed in compliance with regulation 9614,
in respect with that requested by Eurovent
certification.
(1) Sound Pressure
Sound pressure in free field on a reflective
surface (factor of directionality Q=2), at 10
metres from the external surface of the
unit, using the parallel expansion method
(box-method, ISO 3744)
KEY
Operating conditions:
Evaporator water (in/out) 12/7 °C
Condenser water 35 °C
NOTE
H and HL version sound data are refer-
red to in cooling mode operation. For
the heating mode operation refer to H
version sound data
(°)
Total sound levels Octave band[Hz]
Pot.
dB(A)
Press. 125 250 500 1000 2000 4000 8000
dB(A)
10 m
dB
1 m
Acoustic power by central band frequency [dB]
0800
0900
1000
1250
1400
1500
1650
1800
88.5 56.5 73 92 88,5 85 83,6 81,1 72,8 63,3
88.5 56.5 73 92 88,5 85 83,6 81,1 72,8 63,3
88.5 56.5 73 92 88,5 85 83,6 81,1 72,8 63,3
91.5 59.5 74 95,5 88,2 88 85,9 82,4 73,5 64,1
91.0 59 74 95,5 88,2 88 85,9 82,4 73,5 64,1
90.5 58.5 74 95,5 88,2 88 85,9 82,4 73,5 64,1
92 60 76 96,7 90,6 89,4 86,4 84,6 83,1 80,4
94 62 78 96,7 90,6 89,4 88,2 86,9 88,0 85,9
A
Total sound levels Octave band[Hz]
Pot.
dB(A)
Press. 125 250 500 1000 2000 4000 8000
dB(A)
10 m
dB
1 m
Acoustic power by central band frequency [dB]
0800
0900
1000
1250
1400
1500
1650
1800
88 56 73 89,8 87,3 84,3 83,4 81,0 72,4 62,8
88 56 73 89,8 87,3 84,3 83,4 81,0 72,4 62,8
88 56 73 89,8 87,3 84,3 83,4 81,0 72,4 62,8
91 59 74 93,2 87,0 87,3 85,8 82,3 73,1 63,6
90.5 58.5 74 93,2 87,0 87,3 85,8 82,3 73,1 63,6
90 58 74 93,2 87,0 87,3 85,8 82,3 73,1 63,6
91.5 59.5 75 95,0 90,0 88,9 86,3 84,6 83,1 80,4
93.5 61.5 78 95,1 90,0 88,9 88,1 86,9 88,0 85,9
L
Total sound levels Octave band[Hz]
Pot.
dB(A)
Press. 125 250 500 1000 2000 4000 8000
dB(A)
10 m
dB
1 m
Acoustic power by central band frequency [dB]
0800
0900
1000
1250
1400
1500
1650
1800
83 51 68 89,3 84,7 80,2 77,3 73,7 65,2 55,9
83 51 68 89,3 84,7 80,2 77,3 73,7 65,2 55,9
83 51 68 89,3 84,7 80,2 77,3 73,7 65,2 55,9
86 54 69 92,7 84,4 83,1 79,7 74,9 65,9 56,6
85.5 53.5 69 92,7 84,4 83,1 79,7 74,9 65,9 56,6
85 53 69 92,7 84,4 83,1 79,7 74,9 65,9 56,6
86.5 54.5 71,0 92,6 86,7 84,3 78,2 79,7 80,7 78,4
88.5 56.5 73,0 91,4 85,5 83,1 82,2 82,0 84,4 82,0
H
Total sound levels Octave band[Hz]
Pot.
dB(A)
Press. 125 250 500 1000 2000 4000 8000
dB(A)
10 m
dB
1 m
Acoustic power by central band frequency [dB]
0800
0900
1000
1250
1400
1500
1650
1800
88,5 56.5 73 92 88,5 85,0 83,6 81,1 72,8 63,3
88,5 56.5 73 92 88,5 85,0 83,6 81,1 72,8 63,3
88,5 56.5 73 92 88,5 85,0 83,6 81,1 72,8 63,3
91,5 59.5 74 95,5 88,2 88,0 85,9 82,4 73,5 64,1
91 59 74 95,5 88,2 88,0 85,9 82,4 73,5 64,1
90,5 58.5 74 95,5 88,2 88,0 85,9 82,4 73,5 64,1
92 60 76 96,7 90,6 89,4 86,4 84,6 83,1 80,4
94 62 78 96,7 90,6 89,4 88,2 86,9 88,0 85,9
HL
Total sound levels Octave band[Hz]
Pot.
dB(A)
Press. 125 250 500 1000 2000 4000 8000
dB(A)
10 m
dB
1 m
Acoustic power by central band frequency [dB]
0800
0900
1000
1250
1400
1500
1650
1800
83 51 68 89,3 84,7 80,2 77,3 73,7 65,2 55,9
83 51 68 89,3 84,7 80,2 77,3 73,7 65,2 55,9
83 51 68 89,3 84,7 80,2 77,3 73,7 65,2 55,9
86 54 69 92,7 84,4 83,1 79,7 74,9 65,9 56,6
85.5 53.5 69 92,7 84,4 83,1 79,7 74,9 65,9 56,6
85 53 69 92,7 84,4 83,1 79,7 74,9 65,9 56,6
86.5 54.5 73 94,7 88,8 86,5 81,3 81,7 82,7 80,3
88.5 56.5 76 94,8 88,9 86,5 85,6 85,4 87,8 85,9
