5.3 TECHNICAL DATA, SILENCED VERSIONS
NRA L 800 900 1000 1250 1400 1500 1650 1800
Cooling capacity:
kW 190,0 213,0 235,0 292,0 329,0 353,0 404 446
Total input power kW 89,0 98,5 107,5 136,5 148,0 160,0 180 199
Evaporator water flow rate l/h 32680 36640 40420 50220 56590 60720 69490 76710
Evaporator pressure drop kPa 27,8 23,827,6 28,924,828,532,734,7
ENERGY INDICES
EER W/W 2,13 2,16 2,19 2,14 2,22 2,21 2,24 2,24
ESSER W/W 2.72 2.76 2.79 2.88 3.05 3.02 3.07 3.07
ELECTRICAL DATA
Fuel feed V3
~
400 V 50Hz
Total input power A 151 166 180 229 250 270 301 330
Maximum current A 188 207 225 269 304 340 373 400
Peak current A 342 382 422 486 469 522 568 582
COMPRESSORS
Type scroll scroll scroll scroll scroll scroll scroll scroll
Number n° 44445666
Number per circuit
n°+n°+n°+n°
2+2 2+2 2+2 2+2 2+3 3+3 3+3 3+3
COMPRESSOR HEATER
Compressor carter heater n °x W 4 x 130 4 x 130 4 x 130 4 x13 0 5 x13 0 6 x13 0 6 x 130 6 x 130
FANS
Type Axail Axail Axail Axail Axail Axail Axail Axail
Number n° 44466688
Input current ventilation unit A
Input power ventilation unit kW 2,9 3,0 3,1 4,0 4,5 5,0 6 6,2
Air flow rate m3/h 44000 50000 56000 68000 76000 84000 100000 112000
EVAPORATORS
Type Plate Plate Plate Plate Plate Plate Plate Plate
Number n° 11111111
HYDRAULIC CIRCUIT
Water accumulation lt 700 700 700 700 700 700 700 700
Accumulation anti-freeze heater n°xW 2x300 2x300 2x300 2x300 2x300 2x300 2x300 2x300
PLUMBING CONNECTIONS STANDARD VERSIONS (hydraulic parallel not supplied)
Hydraulic connections Victaulic 3” 3” 3” 4” 4” 4” 4” 4”
LOW PRESSURE PUMPING UNIT
Input power 3,8 3,8 3,8 4,8 4,8 6,5 6,5 6,5
Input current 6,22 6,22 6,22 8,14 8,14 11 11 11
Useful pressure pumping 12 0 116 10 2 110 9 0 12 2 13 0 113
HIGH PRESSURE PUMPING UNIT
Input power 6,5 6,5 6,5 8,6 8,6 8,6 12,5 12,3
Input current 11 11 11 14,6 14,6 14,6 21,2 21,2
Useful pressure pumping 232 235 216 245 230 200 267 251
DATI SONORI
Sounud Power dB(A) 83.0 83.0 83.0 86.0 85.5 85.0 86.5 88.5
Sound pressure (1) dB(A) 51.0 51.0 51.0 54.0 53.5 53.0 54.5 56.5
DIMENSIONI per tutti gli allestimenti
Height mm 2450 2450 2450 2450 2450 2450 2450 2450
Width mm 2200 2200 2200 2200 2200 2200 2200 2200
Length mm 3400 3400 3400 4250 4250 4250 5750 5750
PESO a vuoto senza accumulo e pompe
kg 2530 2570 2580 3310 3350 3390 3850 3950
