AERMEC NRA Series User Manual

35
NRA MOD. VERS.
WEI-
GHT
kg.
CENTRE OF
MASS
DISTRIBUTION WEIGHTS PERCENTAGE ON RESTS
KIT
AVX
Gx Gy A B C D E F H I J K
1800 ° 00 3740 2472 905 6,7% 9,6% 27,1% 38,8% 7,3% 10,5% 604
1800 ° 01 4070 2500 928 6,5% 8,9% 28,0% 38,4% 7,7% 10,5% 602
1800 ° 02 4180 2529 952 6,3% 8,2% 28,9% 37,9% 8,1% 10,6% 602
1800 ° 03 4100 2508 934 6,4% 8,7% 28,2% 38,3% 7,8% 10,5% 602
1800 ° 04 4240 2544 964 6,2% 7,9% 29,4% 37,7% 8,3% 10,6% 602
1800 ° P1 3852 2500 928 6,5% 8,9% 28,0% 38,4% 7,7% 10,5% 604
1800 ° P2 3962 2529 952 6,3% 8,2% 28,9% 37,9% 8,1% 10,6% 605
1800 ° P3 3882 2508 934 6,4% 8,7% 28,2% 38,3% 7,8% 10,5% 604
1800 ° P4 4022 2544 964 6,2% 7,9% 29,4% 37,7% 8,3% 10,6% 605
1800 A 00 3950 2483 915 6,4% 8,9% 28,0% 39,2% 7,3% 10,2% 604
1800 A 01 4280 2509 937 6,2% 8,3% 28,8% 38,8% 7,6% 10,3% 602
1800 A 02 4390 2536 959 6,0% 7,7% 29,6% 38,3% 8,0% 10,3% 602
1800 A 03 4310 2517 943 6,1% 8,2% 29,0% 38,7% 7,7% 10,3% 602
1800 A 04 4450 2550 971 5,9% 7,4% 30,1% 38,1% 8,2% 10,4% 602
1800 A P1 4062 2509 937 6,2% 8,3% 28,8% 38,8% 7,6% 10,3% 605
1800 A P2 4172 2536 959 6,0% 7,7% 29,6% 38,3% 8,0% 10,3% 606
1800 A P3 4092 2517 943 6,1% 8,2% 29,0% 38,7% 7,7% 10,3% 605
1800 A P4 4232 2550 971 5,9% 7,4% 30,1% 38,1% 8,2% 10,4% 606
1800 L 00 3950 2483 915 6,4% 8,9% 28,0% 39,2% 7,3% 10,2% 604
1800 L 01 4280 2509 937 6,2% 8,3% 28,8% 38,8% 7,6% 10,3% 602
1800 L 02 4390 2536 959 6,0% 7,7% 29,6% 38,3% 8,0% 10,3% 602
1800 L 03 4310 2517 943 6,1% 8,2% 29,0% 38,7% 7,7% 10,3% 602
1800 L 04 4450 2550 971 5,9% 7,4% 30,1% 38,1% 8,2% 10,4% 602
1800 L P1 4062 2509 937 6,2% 8,3% 28,8% 38,8% 7,6% 10,3% 605
1800 L P2 4172 2536 959 6,0% 7,7% 29,6% 38,3% 8,0% 10,3% 606
1800 L P3 4092 2517 943 6,1% 8,2% 29,0% 38,7% 7,7% 10,3% 605
1800 L P4 4232 2550 971 5,9% 7,4% 30,1% 38,1% 8,2% 10,4% 606
1800 H 00 3960 2483 915 6,4% 8,9% 28,0% 39,2% 7,3% 10,2% 604
1800 H 01 4280 2509 937 6,2% 8,3% 28,8% 38,8% 7,6% 10,3% 602
1800 H 02 4390 2536 959 6,0% 7,7% 29,6% 38,3% 8,0% 10,3% 602
1800 H 03 4310 2517 943 6,1% 8,2% 29,0% 38,7% 7,7% 10,3% 602
1800 H 04 4450 2550 971 5,9% 7,4% 30,1% 38,1% 8,2% 10,4%
602
1800 H P1 4062 2509 937 6,2% 8,3% 28,8% 38,8% 7,6% 10,3% 605
1800 H P2 4172 2536 959 6,0% 7,7% 29,6% 38,3% 8,0% 10,3% 606
1800 H P3 4092 2517 943 6,1% 8,2% 29,0% 38,7% 7,7% 10,3% 605
1800 H P4 4232 2550 971 5,9% 7,4% 30,1% 38,1% 8,2% 10,4% 606
KEY
° Standard
A High temperature
L Silenced
H Heat pump
HL
1
Silenced heat pump
00 Without hydronic kit
01 Accumulation with low
pressure pump
02 Accumulation with low
pressure pump and reserve
pump
03 Accumulation with high
pressure pump
04 Accumulation with high
pressure pump and reserve
pump
P1 Only low pressure pump
P2 Low pressure pump and
reserve pump
P3 High pressure pump
P4 High pressure pump and
reserve pump
NOTE
1 The versions HL, compared with
the versions H, have a different
weight and therefore a slightly
different centre of mass and weight
distribution on the rests; refer
therefore to the corresponding
versions H.
DESUPERHEATER TOTAL RECOVERY
0800 50 125
0900 53 138
1000 56 145
1250 60 145
1400 63 187
1500 66 200
1650 70 200
1800 73 200
18.2.1 ADDITIONAL WEIGHT VERSIONS FOR VERIONS WITH
DESUPERHEATER AND TOTAL RECOVERY
