AERMEC NRB 0282 Series User Manual

28
Size
NRB
Version Hydronic kit Weight Layout
*
Weight
Centre of mass Percentage distribution of weights on supports
VTX Y 1 2 3 4 5 6 7 8
Kg mm mm % % % % % % % %
0552 U/N 00 Operation weight Layout 3 1114 1565 540 20,2% 19,4% 14,1% 13,6% 16,6% 16,0% - - VT 11
0552 U/N
P1, P3 Operation weight Layout 3 1155 1625 511 20,7% 18,0% 12,5% 10,8% 20,4% 17,7% - - VT 11
0552 U/N
P2, P4 Operation weight Layout 3 1203 1664 510 19,9% 17,2% 12,0% 10,4% 21,7% 18,8% - - VT 11
0552 U/N
01, 03, 05, 07 Operation weight Layout 3 1566 1666 508 13,9% 11,9% 24,7% 21,2% 15,2% 13,1% - - VT 11
0552 U/N
02, 04, 06, 08 Operation weight Layout 3 1612 1679 508 13,4% 11,4% 25,0% 21,4% 15,5% 13,3% - - VT 11
0602 U/N
00 Empty weight + package Layout 4 1232 1835 578 26,2% 29,0% - - 21,3% 23,6% - - -
0602 U/N
P1, P3 Empty weight + package Layout 4 1273 1916 548 26,4% 26,2% - - 23,8% 23,6% - - -
0602 U/N
P2, P4 Empty weight + package Layout 4 1313 1955 547 25,8% 25,6% - - 24,4% 24,2% - - -
0602 U/N
01, 03, 05, 07 Empty weight + package Layout 4 1304 1897 547 26,7% 26,5% - - 23,5% 23,3% - - -
0602 U/N
02, 04, 06, 08 Empty weight + package Layout 4 1342 1923 546 26,4% 26,0% - - 24,0% 23,6% - - -
0602 U/N
00 Operation weight Layout 4 1234 1884 559 10,8% 11,1% 25,5% 26,3% 13,0% 13,4% - - VT 22
0602 U/N
P1, P3 Operation weight Layout 4 1275 1963 530 11,1% 10,4% 25,1% 23,3% 15,6% 14,5% - - VT 22
0602 U/N
P2, P4 Operation weight Layout 4 1323 2008 529 10,6% 9,8% 24,9% 23,1% 16,4% 15,2% - - VT 22
0602 U/N
01, 03, 05, 07 Operation weight Layout 4 1684 2060 523 5,8% 5,3% 31,7% 28,7% 14,9% 13,5% - - VT 22
0602 U/N
02, 04, 06, 08 Operation weight Layout 4 1730 2079 522 5,4% 4,9% 31,9% 28,8% 15,2% 13,7% - - VT 22
0652 U/N
00 Empty weight + package Layout 4 1243 1831 579 26,2% 29,1% - - 21,2% 23,5% - - -
0652 U/N
P1, P3 Empty weight + package Layout 4 1284 1911 550 26,4% 26,4% - - 23,6% 23,6% - - -
0652 U/N
P2, P4 Empty weight + package Layout 4 1324 1950 549 25,8% 25,7% - - 24,3% 24,2% - - -
0652 U/N
01, 03, 05, 07 Empty weight + package Layout 4 1316 1892 549 26,7% 26,6% - - 23,3% 23,3% - - -
0652 U/N
02, 04, 06, 08 Empty weight + package Layout 4 1354 1917 548 26,4% 26,2% - - 23,8% 23,6% - - -
0652 U/N
00 Operation weight Layout 4 1256 1884 556 10,7% 10,9% 25,9% 26,5% 12,9% 13,2% - - VT 22
0652 U/N
P1, P3 Operation weight Layout 4 1297 1962 528 11,0% 10,2% 25,5% 23,5% 15,5% 14,3% - - VT 22
0652 U/N
P2, P4 Operation weight Layout 4 1345 2006 527 10,5% 9,6% 25,3% 23,3% 16,3% 15,1% - - VT 22
0652 U/N
01, 03, 05, 07 Operation weight Layout 4 1705 2058 522 5,8% 5,2% 31,9% 28,8% 14,9% 13,4% - - VT 22
0652 U/N
02, 04, 06, 08 Operation weight Layout 4 1751 2076 521 5,4% 4,9% 32,1% 28,9% 15,1% 13,6% - - VT 22
0682 U/N
00 Empty weight + package Layout 4 1426 1754 562 28,2% 29,5% - - 20,7% 21,6% - - -
0682 U/N
P1, P3 Empty weight + package Layout 4 1506 1862 537 27,8% 26,5% - - 23,4% 22,3% - - -
0682 U/N
P2, P4 Empty weight + package Layout 4 1585 1928 535 26,8% 25,4% - - 24,5% 23,2% - - -
0682 U/N
01, 03, 05, 07 Empty weight + package Layout 4 1538 1836 536 28,3% 26,8% - - 23,0% 21,9% - - -
0682 U/N
02, 04, 06, 08 Empty weight + package Layout 4 1615 1882 534 27,6% 26,1% - - 23,8% 22,5% - - -
0682 U/N
00 Operation weight Layout 4 1450 1806 539 12,9% 12,4% 25,6% 24,6% 12,5% 12,0% - - VT 22
0682 U/N
P1, P3 Operation weight Layout 4 1530 1910 515 12,7% 11,2% 25,1% 22,0% 15,4% 13,5% - - VT 22
0682 U/N
P2, P4 Operation weight Layout 4 1617 1979 514 11,8% 10,4% 24,8% 21,7% 16,7% 14,6% - - VT 22
0682 U/N
01, 03, 05, 07 Operation weight Layout 4 1938 1997 512 7,6% 6,6% 31,3% 27,2% 14,6% 12,7% - - VT 22
0682 U/N
02, 04, 06, 08 Operation weight Layout 4 2023 2030 511 6,9% 6,0% 31,6% 27,4% 15,0% 13,1% - - VT 22
0702 U/N
00 Empty weight + package Layout 5 1647 2132 564 18,2% 19,2% 6,3% 6,6% 19,5% 18,6% 5,6% 5,9% -
0702 U/N
P1, P3 Empty weight + package Layout 5 1727 2173 540 18,2% 17,5% 6,1% 5,9% 20,3% 21,0% 5,6% 5,4% -
0702 U/N
P2, P4 Empty weight + package Layout 5 1806 2218 538 17,5% 16,7% 5,5% 5,2% 21,7% 22,7% 5,5% 5,2% -
0702 U/N
01, 03, 05, 07 Empty weight + package Layout 5 1757 2143 539 17,8% 17,1% 8,5% 8,1% 18,9% 19,6% 5,1% 4,9% -
0702 U/N
02, 04, 06, 08 Empty weight + package Layout 5 1834 2171 537 17,0% 16,3% 8,7% 8,3% 19,6% 20,5% 4,9% 4,7% -
0702 U/N
00 Operation weight Layout 5 1672 2171 543 17,5% 17,1% 8,3% 8,1% 20,0% 20,5% 4,3% 4,2% VT 23
0702 U/N
P1, P3 Operation weight Layout 5 1752 2210 520 17,4% 15,6% 8,5% 7,6% 20,3% 22,6% 4,2% 3,8% VT 23
0702 U/N
P2, P4 Operation weight Layout 5 1839 2257 519 16,6% 14,8% 8,1% 7,2% 21,6% 24,1% 4,0% 3,6% VT 23
0702 U/N
01, 03, 05, 07 Operation weight Layout 5 2157 2228 517 13,5% 11,9% 15,0% 13,3% 19,3% 21,8% 2,7% 2,4% VT 23
0702 U/N
02, 04, 06, 08 Operation weight Layout 5 2242 2249 516 12,9% 11,4% 15,3% 13,5% 19,8% 22,4% 2,5% 2,2% VT 23
0752 U/N
00 Empty weight + package Layout 5 1660 2119 561 18,5% 19,3% 6,3% 6,6% 19,3% 18,5% 5,6% 5,9% -
0752 U/N
P1, P3 Empty weight + package Layout 5 1740 2161 537 18,5% 17,7% 6,1% 5,8% 20,0% 21,0% 5,6% 5,3% -
0752 U/N
P2, P4 Empty weight + package Layout 5 1819 2206 536 17,8% 16,9% 5,5% 5,2% 21,5% 22,6% 5,4% 5,2% -
0752 U/N
01, 03, 05, 07 Empty weight + package Layout 5 1769 2131 537 18,1% 17,2% 8,4% 8,1% 18,6% 19,6% 5,1% 4,9% -
0752 U/N
02, 04, 06, 08 Empty weight + package Layout 5 1846 2159 535 17,3% 16,4% 8,6% 8,2% 19,4% 20,5% 4,9% 4,6% -
0752 U/N
00 Operation weight Layout 5 1685 2158 541 17,8% 17,3% 8,3% 8,0% 19,7% 20,4% 4,3% 4,2% VT 23
0752 U/N
P1, P3 Operation weight Layout 5 1765 2198 518 17,7% 15,8% 8,5% 7,5% 20,1% 22,6% 4,2% 3,7% VT 23
0752 U/N
P2, P4 Operation weight Layout 5 1852 2245 518 16,9% 15,0% 8,1% 7,2% 21,3% 24,0% 4,0% 3,5% VT 23
0752 U/N
01, 03, 05, 07 Operation weight Layout 5 2170 2218 515 13,8% 12,1% 15,0% 13,2% 19,1% 21,7% 2,7% 2,4% VT 23
0752 U/N
02, 04, 06, 08 Operation weight Layout 5 2255 2239 514 13,2% 11,6% 15,2% 13,4% 19,6% 22,4% 2,5% 2,2% VT 23
