AERMEC NRB 0282 Series User Manual

24
CENTRE OF GRAVITY AND ANTIVIBRATION POSITIONS
Versions a/e
Size
NRB
Version Hydronic kit Weight Layout
*
Weight
Centre of mass Percentage distribution of weights on supports
VTX Y 1 2 3 4 5 6 7 8
Kg mm mm % % % % % % % %
0282 E 00 Empty weight + package Layout 1 828 1084 570 28,2% 30,3% 20,0% 21,5% - - - - -
0282 E
P1, P3 Empty weight + package Layout 1 869 1153 530 28,2% 26,2% 23,7% 22,0% - - - - -
0282 E
P2, P4 Empty weight + package Layout 1 917 1197 528 26,9% 24,8% 25,1% 23,2% - - - - -
0282 E
01, 03, 05, 07 Empty weight + package Layout 1 893 1112 529 29,5% 27,3% 22,4% 20,7% - - - - -
0282 E
02, 04, 06, 08 Empty weight + package Layout 1 931 1132 528 28,9% 26,7% 23,1% 21,3% - - - - -
0282 E
00 Operation weight Layout 1 812 1109 558 28,1% 28,9% 21,2% 21,8% - - - - VT 17
0282 E
P1, P3 Operation weight Layout 1 853 1178 517 28,0% 24,8% 25,0% 22,2% - - - - VT 17
0282 E
P2, P4 Operation weight Layout 1 912 1231 516 26,3% 23,3% 26,7% 23,6% - - - - VT 17
0282 E
01, 03, 05, 07 Operation weight Layout 1 1156 1153 513 29,0% 25,3% 24,4% 21,3% - - - - VT 17
0282 E
02, 04, 06, 08 Operation weight Layout 1 1202 1168 512 28,5% 24,9% 24,9% 21,7% - - - - VT 17
0302 E
00 Empty weight + package Layout 2 889 1290 568 28,3% 30,3% 20,0% 21,4% - - - - -
0302 E
P1, P3 Empty weight + package Layout 2 930 1325 529 29,6% 27,4% 22,3% 20,7% - - - - -
0302 E
P2, P4 Empty weight + package Layout 2 978 1358 528 28,8% 26,6% 23,2% 21,4% - - - - -
0302 E
01, 03, 05, 07 Empty weight + package Layout 2 953 1280 528 30,7% 28,4% 21,3% 19,7% - - - - -
0302 E
02, 04, 06, 08 Empty weight + package Layout 2 991 1292 527 30,5% 28,1% 21,6% 19,9% - - - - -
0302 E
00 Operation weight Layout 2 871 1307 557 28,6% 29,3% 20,8% 21,3% - - - - VT 17
0302 E
P1, P3 Operation weight Layout 2 912 1341 517 29,8% 26,4% 23,2% 20,6% - - - - VT 17
0302 E
P2, P4 Operation weight Layout 2 972 1382 516 28,8% 25,5% 24,2% 21,4% - - - - VT 17
0302 E
01, 03, 05, 07 Operation weight Layout 2 1213 1274 513 31,7% 27,7% 21,7% 18,9% - - - - VT 17
0302 E
02, 04, 06, 08 Operation weight Layout 2 1259 1284 512 31,5% 27,4% 22,0% 19,1% - - - - VT 17
0332 E
00 Empty weight + package Layout 2 912 1289 570 28,3% 30,4% 19,9% 21,4% - - - - -
0332 E
P1, P3 Empty weight + package Layout 2 953 1323 531 29,5% 27,6% 22,2% 20,7% - - - - -
0332 E
P2, P4 Empty weight + package Layout 2 1001 1355 530 28,8% 26,8% 23,0% 21,4% - - - - -
0332 E
01, 03, 05, 07 Empty weight + package Layout 2 976 1278 530 30,6% 28,5% 21,2% 19,7% - - - - -
0332 E
02, 04, 06, 08 Empty weight + package Layout 2 1014 1290 529 30,4% 28,2% 21,5% 19,9% - - - - -
0332 E
00 Operation weight Layout 2 899 1307 555 28,6% 29,2% 20,9% 21,3% - - - - VT 17
0332 E
P1, P3 Operation weight Layout 2 940 1340 517 29,8% 26,4% 23,2% 20,6% - - - - VT 17
0332 E
P2, P4 Operation weight Layout 2 1000 1380 516 28,9% 25,5% 24,2% 21,4% - - - - VT 17
0332 E
01, 03, 05, 07 Operation weight Layout 2 1241 1274 513 31,7% 27,7% 21,7% 19,0% - - - - VT 17
0332 E
02, 04, 06, 08 Operation weight Layout 2 1287 1284 513 31,4% 27,4% 22,0% 19,2% - - - - VT 17
0352 E
00 Empty weight + package Layout 2 962 1301 570 28,0% 30,1% 20,2% 21,7% - - - - -
0352 E
P1, P3 Empty weight + package Layout 2 1003 1332 533 29,2% 27,5% 22,3% 21,0% - - - - -
0352 E
P2, P4 Empty weight + package Layout 2 1051 1363 532 28,5% 26,7% 23,1% 21,7% - - - - -
0352 E
01, 03, 05, 07 Empty weight + package Layout 2 1026 1290 533 30,2% 28,4% 21,3% 20,0% - - - - -
0352 E
02, 04, 06, 08 Empty weight + package Layout 2 1064 1301 532 30,0% 28,1% 21,7% 20,2% - - - - -
0352 E
00 Operation weight Layout 2 949 1318 557 28,3% 29,0% 21,1% 21,6% - - - - VT 17
0352 E
P1, P3 Operation weight Layout 2 990 1349 520 29,4% 26,4% 23,3% 20,9% - - - - VT 17
0352 E
P2, P4 Operation weight Layout 2 1050 1386 519 28,6% 25,5% 24,2% 21,6% - - - - VT 17
0352 E
01, 03, 05, 07 Operation weight Layout 2 1291 1284 515 31,3% 27,6% 21,8% 19,3% - - - - VT 17
0352 E
02, 04, 06, 08 Operation weight Layout 2 1337 1293 515 31,1% 27,4% 22,1% 19,4% - - - - VT 17
0502 A/E
00 Empty weight + package Layout 3 1046 1535 563 26,6% 27,9% - - 22,2% 23,3% - - -
0502 A/E
P1, P3 Empty weight + package Layout 3 1087 1600 532 26,4% 24,7% - - 25,3% 23,6% - - -
0502 A/E
P2, P4 Empty weight + package Layout 3 1127 1635 531 25,5% 23,8% - - 26,2% 24,4% - - -
0502 A/E
01, 03, 05, 07 Empty weight + package Layout 3 1121 1573 531 27,2% 25,3% - - 24,6% 22,9% - - -
0502 A/E
02, 04, 06, 08 Empty weight + package Layout 3 1159 1593 530 26,7% 24,8% - - 25,2% 23,4% - - -
0502 A/E
00 Operation weight Layout 3 1045 1579 545 19,6% 19,2% 14,1% 13,8% 16,8% 16,5% - - VT 11
0502 A/E
P1, P3 Operation weight Layout 3 1086 1642 514 20,2% 17,7% 12,3% 10,8% 20,8% 18,2% - - VT 11
0502 A/E
P2, P4 Operation weight Layout 3 1134 1683 513 19,4% 16,9% 11,8% 10,3% 22,2% 19,4% - - VT 11
0502 A/E
01, 03, 05, 07 Operation weight Layout 3 1497 1680 510 13,2% 11,4% 25,1% 21,7% 15,3% 13,2% - - VT 11
0502 A/E
02, 04, 06, 08 Operation weight Layout 3 1543 1694 510 12,7% 10,9% 25,4% 21,9% 15,6% 13,4% - - VT 11
0552 A/E
00 Empty weight + package Layout 3 1072 1508 559 27,4% 28,4% - - 21,7% 22,5% - - -
0552 A/E
P1, P3 Empty weight + package Layout 3 1113 1573 528 27,3% 25,2% - - 24,7% 22,8% - - -
0552 A/E
P2, P4 Empty weight + package Layout 3 1153 1608 527 26,4% 24,3% - - 25,7% 23,6% - - -
0552 A/E
01, 03, 05, 07 Empty weight + package Layout 3 1146 1547 527 28,0% 25,8% - - 24,0% 22,1% - - -
0552 A/E
02, 04, 06, 08 Empty weight + package Layout 3 1184 1567 527 27,5% 25,3% - - 24,6% 22,6% - - -
