AERMEC NRB 0282 Series User Manual

23
Size
NRB
Version Hydronic kit Weight Layout
*
Weight
Centre of mass Percentage distribution of weights on supports
VTX Y 1 2 3 4 5 6 7 8
Kg mm mm % % % % % % % %
0604 °/L
00 Empty weight + package Layout 3 1160 1435 577 28,3% 31,2% - - 19,2% 21,2% - - -
0604 °/L
P1, P3 Empty weight + package Layout 3 1201 1497 548 28,3% 28,1% - - 21,9% 21,7% - - -
0604 °/L
P2, P4 Empty weight + package Layout 3 1241 1533 546 27,5% 27,1% - - 22,9% 22,6% - - -
0604 °/L
01, 03, 05, 07 Empty weight + package Layout 3 1235 1475 547 28,9% 28,6% - - 21,4% 21,1% - - -
0604 °/L
02, 04, 06, 08 Empty weight + package Layout 3 1273 1497 545 28,5% 28,0% - - 22,0% 21,6% - - -
0604 °/L
00 Operation weight Layout 3 1155 1472 562 23,0% 24,0% 10,8% 11,2% 15,1% 15,8% - - VT 11
0604 °/L
P1, P3 Operation weight Layout 3 1196 1534 533 23,7% 22,3% 9,2% 8,7% 18,7% 17,5% - - VT 11
0604 °/L
P2, P4 Operation weight Layout 3 1244 1575 532 22,8% 21,3% 8,9% 8,3% 20,0% 18,7% - - VT 11
0604 °/L
01, 03, 05, 07 Operation weight Layout 3 1607 1596 524 16,5% 15,0% 21,6% 19,7% 14,2% 12,9% - - VT 11
0604 °/L
02, 04, 06, 08 Operation weight Layout 3 1653 1612 524 15,9% 14,5% 22,0% 20,0% 14,5% 13,2% - - VT 11
0654 °/L
00 Empty weight + package Layout 3 1210 1442 577 28,2% 31,1% - - 19,4% 21,4% - - -
0654 °/L
P1, P3 Empty weight + package Layout 3 1251 1501 549 28,1% 28,1% - - 21,9% 21,9% - - -
0654 °/L
P2, P4 Empty weight + package Layout 3 1291 1535 548 27,3% 27,1% - - 22,9% 22,7% - - -
0654 °/L
01, 03, 05, 07 Empty weight + package Layout 3 1285 1480 548 28,8% 28,5% - - 21,4% 21,3% - - -
0654 °/L
02, 04, 06, 08 Empty weight + package Layout 3 1323 1500 546 28,3% 27,9% - - 22,0% 21,7% - - -
0654 °/L
00 Operation weight Layout 3 1212 1481 559 22,6% 23,3% 11,6% 12,0% 15,0% 15,5% - - VT 11
0654 °/L
P1, P3 Operation weight Layout 3 1253 1539 532 23,2% 21,7% 10,1% 9,5% 18,4% 17,2% - - VT 11
0654 °/L
P2, P4 Operation weight Layout 3 1301 1578 531 22,3% 20,8% 9,7% 9,1% 19,6% 18,3% - - VT 11
0654 °/L
01, 03, 05, 07 Operation weight Layout 3 1664 1598 524 16,3% 14,8% 21,9% 19,9% 14,1% 12,9% - - VT 11
0654 °/L
02, 04, 06, 08 Operation weight Layout 3 1710 1613 524 15,8% 14,3% 22,2% 20,2% 14,4% 13,1% - - VT 11
0704 °/L
00 Empty weight + package Layout 4 1331 1754 568 27,9% 29,8% - - 20,5% 21,8% - - -
0704 °/L
P1, P3 Empty weight + package Layout 4 1411 1871 540 27,5% 26,5% - - 23,4% 22,6% - - -
0704 °/L
P2, P4 Empty weight + package Layout 4 1490 1941 538 26,5% 25,3% - - 24,6% 23,5% - - -
0704 °/L
01, 03, 05, 07 Empty weight + package Layout 4 1443 1844 539 28,0% 26,9% - - 23,0% 22,1% - - -
0704 °/L
02, 04, 06, 08 Empty weight + package Layout 4 1520 1892 537 27,3% 26,1% - - 23,9% 22,8% - - -
0704 °/L
00 Operation weight Layout 4 1330 1797 552 12,7% 12,8% 25,1% 25,2% 12,1% 12,1% - - VT 22
0704 °/L
P1, P3 Operation weight Layout 4 1410 1912 525 12,6% 11,5% 24,5% 22,3% 15,2% 13,9% - - VT 22
0704 °/L
P2, P4 Operation weight Layout 4 1497 1987 523 11,6% 10,5% 24,2% 21,9% 16,6% 15,1% - - VT 22
0704 °/L
01, 03, 05, 07 Operation weight Layout 4 1818 2005 519 7,3% 6,5% 31,1% 27,8% 14,4% 12,9% - - VT 22
0704 °/L
02, 04, 06, 08 Operation weight Layout 4 1903 2039 518 6,6% 5,8% 31,4% 28,0% 14,9% 13,3% - - VT 22
0754 °/L
00 Empty weight + package Layout 4 1392 1699 566 28,8% 30,6% - - 19,7% 20,9% - - -
0754 °/L
P1, P3 Empty weight + package Layout 4 1472 1814 540 28,4% 27,4% - - 22,5% 21,7% - - -
0754 °/L
P2, P4 Empty weight + package Layout 4 1551 1885 538 27,4% 26,2% - - 23,7% 22,7% - - -
0754 °/L
01, 03, 05, 07 Empty weight + package Layout 4 1504 1789 539 28,9% 27,7% - - 22,2% 21,3% - - -
0754 °/L
02, 04, 06, 08 Empty weight + package Layout 4 1581 1839 537 28,2% 26,9% - - 23,0% 21,9% - - -
0754 °/L
00 Operation weight Layout 4 1403 1747 547 14,1% 14,0% 24,5% 24,2% 11,7% 11,5% - - VT 22
0754 °/L
P1, P3 Operation weight Layout 4 1483 1858 521 14,0% 12,6% 23,9% 21,5% 14,7% 13,3% - - VT 22
0754 °/L
P2, P4 Operation weight Layout 4 1570 1933 520 13,0% 11,6% 23,7% 21,2% 16,1% 14,4% - - VT 22
0754 °/L
01, 03, 05, 07 Operation weight Layout 4 1891 1959 517 8,5% 7,6% 30,4% 27,0% 14,0% 12,4% - - VT 22
0754 °/L
02, 04, 06, 08 Operation weight Layout 4 1976 1994 516 7,8% 6,9% 30,8% 27,2% 14,5% 12,8% - - VT 22
* For specic measurements of every layout please refer to the “Weight distribution” chapter.
