AERMEC NRB 0282 Series User Manual

22
Size
NRB
Version Hydronic kit Weight Layout
*
Weight
Centre of mass Percentage distribution of weights on supports
VTX Y 1 2 3 4 5 6 7 8
Kg mm mm % % % % % % % %
0552 °/L
00 Operation weight Layout 3 1009 1526 542 22,1% 21,5% 12,0% 11,6% 16,7% 16,2% - - VT 11
0552 °/L
P1, P3 Operation weight Layout 3 1050 1594 510 22,8% 19,7% 10,1% 8,7% 20,8% 18,0% - - VT 11
0552 °/L
P2, P4 Operation weight Layout 3 1098 1638 510 21,8% 18,8% 9,6% 8,3% 22,2% 19,2% - - VT 11
0552 °/L
01, 03, 05, 07 Operation weight Layout 3 1461 1645 507 14,8% 12,7% 23,9% 20,5% 15,1% 13,0% - - VT 11
0552 °/L
02, 04, 06, 08 Operation weight Layout 3 1507 1661 507 14,3% 12,2% 24,2% 20,7% 15,4% 13,2% - - VT 11
0602 °/L
00 Empty weight + package Layout 3 1075 1507 560 27,5% 28,4% - - 21,7% 22,4% - - -
0602 °/L
P1, P3 Empty weight + package Layout 3 1116 1571 529 27,3% 25,3% - - 24,6% 22,8% - - -
0602 °/L
P2, P4 Empty weight + package Layout 3 1156 1606 528 26,4% 24,4% - - 25,6% 23,6% - - -
0602 °/L
01, 03, 05, 07 Empty weight + package Layout 3 1150 1545 528 28,1% 25,9% - - 24,0% 22,1% - - -
0602 °/L
02, 04, 06, 08 Empty weight + package Layout 3 1188 1566 527 27,5% 25,3% - - 24,5% 22,6% - - -
0602 °/L
00 Operation weight Layout 3 1074 1549 541 20,9% 20,3% 13,2% 12,8% 16,6% 16,1% - - VT 11
0602 °/L
P1, P3 Operation weight Layout 3 1115 1612 511 21,5% 18,7% 11,5% 10,0% 20,5% 17,8% - - VT 11
0602 °/L
P2, P4 Operation weight Layout 3 1163 1653 511 20,7% 17,9% 11,0% 9,6% 21,9% 19,0% - - VT 11
0602 °/L
01, 03, 05, 07 Operation weight Layout 3 1526 1657 508 14,3% 12,3% 24,3% 20,9% 15,2% 13,0% - - VT 11
0602 °/L
02, 04, 06, 08 Operation weight Layout 3 1572 1671 508 13,7% 11,8% 24,6% 21,1% 15,4% 13,2% - - VT 11
0652 °/L
00 Empty weight + package Layout 3 1075 1507 560 27,5% 28,4% - - 21,7% 22,4% - - -
0652 °/L
P1, P3 Empty weight + package Layout 3 1116 1571 529 27,3% 25,3% - - 24,6% 22,8% - - -
0652 °/L
P2, P4 Empty weight + package Layout 3 1156 1606 528 26,4% 24,4% - - 25,6% 23,6% - - -
0652 °/L
01, 03, 05, 07 Empty weight + package Layout 3 1150 1545 528 28,1% 25,9% - - 23,9% 22,1% - - -
0652 °/L
02, 04, 06, 08 Empty weight + package Layout 3 1188 1566 527 27,5% 25,3% - - 24,5% 22,6% - - -
0652 °/L
00 Operation weight Layout 3 1074 1549 541 20,9% 20,3% 13,2% 12,8% 16,6% 16,1% - - VT 11
0652 °/L
P1, P3 Operation weight Layout 3 1115 1612 511 21,5% 18,7% 11,5% 10,0% 20,5% 17,8% - - VT 11
0652 °/L
P2, P4 Operation weight Layout 3 1163 1653 511 20,7% 17,9% 11,0% 9,6% 21,9% 19,0% - - VT 11
0652 °/L
01, 03, 05, 07 Operation weight Layout 3 1526 1657 508 14,3% 12,3% 24,3% 20,9% 15,2% 13,0% - - VT 11
0652 °/L
02, 04, 06, 08 Operation weight Layout 3 1572 1671 508 13,7% 11,8% 24,6% 21,1% 15,4% 13,2% - - VT 11
0682 °/L
00 Empty weight + package Layout 4 1267 1686 560 29,4% 30,4% - - 19,7% 20,5% - - -
0682 °/L
P1, P3 Empty weight + package Layout 4 1347 1811 531 28,9% 27,0% - - 22,8% 21,3% - - -
0682 °/L
P2, P4 Empty weight + package Layout 4 1426 1888 529 27,8% 25,7% - - 24,1% 22,4% - - -
0682 °/L
01, 03, 05, 07 Empty weight + package Layout 4 1379 1784 530 29,4% 27,4% - - 22,4% 20,9% - - -
0682 °/L
02, 04, 06, 08 Empty weight + package Layout 4 1456 1838 529 28,6% 26,5% - - 23,3% 21,6% - - -
0682 °/L
00 Operation weight Layout 4 1270 1734 541 15,4% 14,9% 23,2% 22,5% 12,2% 11,8% - - VT 22
0682 °/L
P1, P3 Operation weight Layout 4 1350 1856 514 15,2% 13,3% 22,6% 19,8% 15,5% 13,6% - - VT 22
0682 °/L
P2, P4 Operation weight Layout 4 1437 1937 513 14,0% 12,2% 22,4% 19,6% 17,0% 14,8% - - VT 22
0682 °/L
01, 03, 05, 07 Operation weight Layout 4 1758 1965 511 9,0% 7,8% 30,0% 26,0% 14,6% 12,6% - - VT 22
0682 °/L
02, 04, 06, 08 Operation weight Layout 4 1843 2002 510 8,2% 7,1% 30,4% 26,3% 15,1% 13,0% - - VT 22
0702 °/L
00 Empty weight + package Layout 4 1427 1641 569 29,5% 31,7% - - 18,7% 20,1% - - -
0702 °/L
P1, P3 Empty weight + package Layout 4 1507 1755 543 29,2% 28,5% - - 21,4% 20,9% - - -
0702 °/L
P2, P4 Empty weight + package Layout 4 1586 1827 541 28,2% 27,3% - - 22,7% 21,9% - - -
0702 °/L
01, 03, 05, 07 Empty weight + package Layout 4 1539 1732 542 29,6% 28,8% - - 21,1% 20,5% - - -
0702 °/L
02, 04, 06, 08 Empty weight + package Layout 4 1616 1783 540 28,9% 27,9% - - 22,0% 21,2% - - -
0702 °/L
00 Operation weight Layout 4 1430 1683 553 16,3% 16,5% 22,1% 22,3% 11,4% 11,5% - - VT 22
0702 °/L
P1, P3 Operation weight Layout 4 1510 1795 528 16,1% 14,9% 21,6% 19,9% 14,3% 13,2% - - VT 22
0702 °/L
P2, P4 Operation weight Layout 4 1597 1872 526 15,0% 13,8% 21,5% 19,7% 15,7% 14,4% - - VT 22
0702 °/L
01, 03, 05, 07 Operation weight Layout 4 1919 1908 522 10,4% 9,3% 28,5% 25,7% 13,7% 12,4% - - VT 22
0702 °/L
02, 04, 06, 08 Operation weight Layout 4 2004 1945 521 9,6% 8,6% 28,9% 26,0% 14,2% 12,8% - - VT 22
0752 °/L
00 Empty weight + package Layout 4 1440 1630 567 29,8% 31,7% - - 18,6% 19,8% - - -
0752 °/L
P1, P3 Empty weight + package Layout 4 1520 1744 541 29,5% 28,5% - - 21,3% 20,7% - - -
0752 °/L
P2, P4 Empty weight + package Layout 4 1599 1816 539 28,4% 27,3% - - 22,6% 21,7% - - -
0752 °/L
01, 03, 05, 07 Empty weight + package Layout 4 1552 1721 540 29,9% 28,8% - - 21,0% 20,3% - - -
0752 °/L
02, 04, 06, 08 Empty weight + package Layout 4 1629 1772 539 29,2% 28,0% - - 21,9% 21,0% - - -
0752 °/L
00 Operation weight Layout 4 1443 1672 551 16,6% 16,7% 21,9% 22,0% 11,3% 11,4% - - VT 22
0752 °/L
P1, P3 Operation weight Layout 4 1523 1784 526 16,5% 15,1% 21,5% 19,7% 14,2% 13,1% - - VT 22
0752 °/L
P2, P4 Operation weight Layout 4 1610 1860 525 15,3% 14,0% 21,4% 19,5% 15,6% 14,2% - - VT 22
0752 °/L
01, 03, 05, 07 Operation weight Layout 4 1932 1898 521 10,7% 9,6% 28,3% 25,5% 13,7% 12,3% - - VT 22
0752 °/L
02, 04, 06, 08 Operation weight Layout 4 2017 1935 520 9,9% 8,8% 28,7% 25,7% 14,2% 12,7% - - VT 22
