AERMEC NRB 0282 Series User Manual

27
CENTRE OF GRAVITY AND ANTIVIBRATION POSITIONS
Versions u/n
Size
NRB
Version Hydronic kit Weight Layout
*
Weight
Centre of mass Percentage distribution of weights on supports
VTX Y 1 2 3 4 5 6 7 8
Kg mm mm % % % % % % % %
0282 N 00 Empty weight + package Layout 2 884 1296 570 28,1% 30,2% 20,1% 21,6% - - - - -
0282 N
P1, P3 Empty weight + package Layout 2 925 1330 531 29,3% 27,4% 22,4% 20,9% - - - - -
0282 N
P2, P4 Empty weight + package Layout 2 973 1364 529 28,6% 26,6% 23,3% 21,6% - - - - -
0282 N
01, 03, 05, 07 Empty weight + package Layout 2 948 1285 530 30,5% 28,4% 21,3% 19,8% - - - - -
0282 N
02, 04, 06, 08 Empty weight + package Layout 2 986 1297 529 30,3% 28,0% 21,7% 20,1% - - - - -
0282 N
00 Operation weight Layout 2 866 1313 559 28,3% 29,2% 20,9% 21,6% - - - - VT 17
0282 N
P1, P3 Operation weight Layout 2 907 1347 519 29,6% 26,4% 23,3% 20,8% - - - - VT 17
0282 N
P2, P4 Operation weight Layout 2 967 1388 518 28,6% 25,4% 24,3% 21,6% - - - - VT 17
0282 N
01, 03, 05, 07 Operation weight Layout 2 1208 1278 514 31,5% 27,7% 21,8% 19,1% - - - - VT 17
0282 N
02, 04, 06, 08 Operation weight Layout 2 1254 1288 514 31,3% 27,4% 22,0% 19,3% - - - - VT 17
0302 N
00 Empty weight + package Layout 2 907 1294 570 28,1% 30,2% 20,1% 21,5% - - - - -
0302 N
P1, P3 Empty weight + package Layout 2 948 1328 531 29,4% 27,4% 22,3% 20,8% - - - - -
0302 N
P2, P4 Empty weight + package Layout 2 996 1361 530 28,7% 26,6% 23,2% 21,5% - - - - -
0302 N
01, 03, 05, 07 Empty weight + package Layout 2 971 1284 530 30,5% 28,4% 21,3% 19,8% - - - - -
0302 N
02, 04, 06, 08 Empty weight + package Layout 2 1009 1296 529 30,3% 28,1% 21,6% 20,0% - - - - -
0302 N
00 Operation weight Layout 2 894 1313 556 28,5% 29,1% 21,0% 21,4% - - - - VT 17
0302 N
P1, P3 Operation weight Layout 2 935 1346 517 29,7% 26,3% 23,3% 20,7% - - - - VT 17
0302 N
P2, P4 Operation weight Layout 2 995 1385 516 28,8% 25,4% 24,3% 21,5% - - - - VT 17
0302 N
01, 03, 05, 07 Operation weight Layout 2 1236 1279 513 31,6% 27,6% 21,8% 19,1% - - - - VT 17
0302 N
02, 04, 06, 08 Operation weight Layout 2 1282 1288 512 31,4% 27,3% 22,1% 19,2% - - - - VT 17
0332 N
00 Empty weight + package Layout 2 957 1305 569 28,0% 29,9% 20,3% 21,8% - - - - -
0332 N
P1, P3 Empty weight + package Layout 2 998 1337 532 29,1% 27,3% 22,5% 21,1% - - - - -
0332 N
P2, P4 Empty weight + package Layout 2 1046 1367 531 28,5% 26,5% 23,3% 21,7% - - - - -
0332 N
01, 03, 05, 07 Empty weight + package Layout 2 1021 1294 531 30,2% 28,2% 21,5% 20,1% - - - - -
0332 N
02, 04, 06, 08 Empty weight + package Layout 2 1059 1305 530 30,0% 27,9% 21,8% 20,3% - - - - -
0332 N
00 Operation weight Layout 2 944 1323 555 28,3% 28,8% 21,3% 21,7% - - - - VT 17
0332 N
P1, P3 Operation weight Layout 2 985 1354 519 29,4% 26,2% 23,4% 20,9% - - - - VT 17
0332 N
P2, P4 Operation weight Layout 2 1045 1391 518 28,5% 25,4% 24,4% 21,7% - - - - VT 17
0332 N
01, 03, 05, 07 Operation weight Layout 2 1286 1287 514 31,3% 27,5% 22,0% 19,3% - - - - VT 17
0332 N
02, 04, 06, 08 Operation weight Layout 2 1332 1296 514 31,1% 27,2% 22,2% 19,5% - - - - VT 17
0352 U/N
00 Empty weight + package Layout 3 1020 1554 568 25,9% 27,6% - - 22,5% 24,0% - - -
0352 U/N
P1, P3 Empty weight + package Layout 3 1061 1620 535 25,7% 24,4% - - 25,6% 24,3% - - -
0352 U/N
P2, P4 Empty weight + package Layout 3 1101 1655 534 24,9% 23,4% - - 26,6% 25,1% - - -
0352 U/N
01, 03, 05, 07 Empty weight + package Layout 3 1095 1591 534 26,5% 25,0% - - 24,9% 23,5% - - -
0352 U/N
02, 04, 06, 08 Empty weight + package Layout 3 1133 1611 533 26,1% 24,5% - - 25,5% 24,0% - - -
0352 U/N
00 Operation weight Layout 3 1019 1599 548 18,9% 18,8% 14,1% 14,0% 17,2% 17,1% - - VT 11
0352 U/N
P1, P3 Operation weight Layout 3 1060 1663 516 19,5% 17,3% 12,3% 10,9% 21,2% 18,8% - - VT 11
0352 U/N
P2, P4 Operation weight Layout 3 1108 1704 516 18,7% 16,5% 11,8% 10,4% 22,7% 20,0% - - VT 11
0352 U/N
01, 03, 05, 07 Operation weight Layout 3 1471 1695 512 12,6% 11,0% 25,3% 22,0% 15,6% 13,5% - - VT 11
0352 U/N
02, 04, 06, 08 Operation weight Layout 3 1517 1709 512 12,1% 10,5% 25,6% 22,2% 15,8% 13,7% - - VT 11
0502 U/N
00 Empty weight + package Layout 3 1076 1549 563 26,2% 27,5% - - 22,6% 23,7% - - -
0502 U/N
P1, P3 Empty weight + package Layout 3 1117 1612 532 26,1% 24,4% - - 25,5% 23,9% - - -
0502 U/N
P2, P4 Empty weight + package Layout 3 1157 1646 531 25,2% 23,6% - - 26,5% 24,7% - - -
0502 U/N
01, 03, 05, 07 Empty weight + package Layout 3 1151 1585 531 26,8% 25,1% - - 24,9% 23,2% - - -
0502 U/N
02, 04, 06, 08 Empty weight + package Layout 3 1189 1604 530 26,4% 24,5% - - 25,4% 23,7% - - -
0502 U/N
00 Operation weight Layout 3 1075 1592 545 19,0% 18,7% 14,6% 14,3% 16,9% 16,6% - - VT 11
0502 U/N
P1, P3 Operation weight Layout 3 1116 1653 515 19,6% 17,2% 12,9% 11,3% 20,8% 18,2% - - VT 11
0502 U/N
P2, P4 Operation weight Layout 3 1164 1692 514 18,8% 16,5% 12,3% 10,8% 22,1% 19,4% - - VT 11
0502 U/N
01, 03, 05, 07 Operation weight Layout 3 1527 1687 511 12,9% 11,2% 25,3% 21,9% 15,4% 13,3% - - VT 11
0502 U/N
02, 04, 06, 08 Operation weight Layout 3 1573 1700 510 12,4% 10,7% 25,6% 22,1% 15,6% 13,5% - - VT 11
0552 U/N
00 Empty weight + package Layout 3 1109 1521 560 27,1% 28,1% - - 22,0% 22,8% - - -
0552 U/N
P1, P3 Empty weight + package Layout 3 1150 1583 531 26,9% 25,1% - - 24,8% 23,1% - - -
0552 U/N
P2, P4 Empty weight + package Layout 3 1190 1617 530 26,1% 24,2% - - 25,8% 23,9% - - -
0552 U/N
01, 03, 05, 07 Empty weight + package Layout 3 1183 1557 530 27,6% 25,7% - - 24,2% 22,5% - - -
0552 U/N
02, 04, 06, 08 Empty weight + package Layout 3 1221 1577 529 27,2% 25,1% - - 24,8% 22,9% - - -
