AERMEC NRB 0282 Series User Manual

26
Size
NRB
Version Hydronic kit Weight Layout
*
Weight
Centre of mass Percentage distribution of weights on supports
VTX Y 1 2 3 4 5 6 7 8
Kg mm mm % % % % % % % %
0604 A/E 00 Empty weight + package Layout 3 1200 1447 577 28,0% 30,9% - - 19,5% 21,6% - - -
0604 A/E
P1, P3 Empty weight + package Layout 3 1241 1507 549 28,0% 27,9% - - 22,1% 22,0% - - -
0604 A/E
P2, P4 Empty weight + package Layout 3 1281 1541 548 27,2% 27,0% - - 23,0% 22,8% - - -
0604 A/E
01, 03, 05, 07 Empty weight + package Layout 3 1275 1485 548 28,6% 28,4% - - 21,6% 21,4% - - -
0604 A/E
02, 04, 06, 08 Empty weight + package Layout 3 1313 1506 547 28,1% 27,8% - - 22,2% 21,9% - - -
0604 A/E
00 Operation weight Layout 3 1202 1487 560 22,4% 23,2% 11,6% 12,0% 15,1% 15,7% - - VT 11
0604 A/E
P1, P3 Operation weight Layout 3 1243 1545 532 23,0% 21,5% 10,1% 9,5% 18,5% 17,4% - - VT 11
0604 A/E
P2, P4 Operation weight Layout 3 1291 1584 531 22,2% 20,7% 9,8% 9,1% 19,8% 18,5% - - VT 11
0604 A/E
01, 03, 05, 07 Operation weight Layout 3 1654 1603 524 16,1% 14,7% 22,0% 20,0% 14,2% 13,0% - - VT 11
0604 A/E
02, 04, 06, 08 Operation weight Layout 3 1700 1618 523 15,6% 14,2% 22,3% 20,3% 14,5% 13,1% - - VT 11
0654 A/E
00 Empty weight + package Layout 4 1325 1757 568 27,9% 29,7% - - 20,5% 21,9% - - -
0654 A/E
P1, P3 Empty weight + package Layout 4 1366 1836 541 28,0% 27,1% - - 22,8% 22,1% - - -
0654 A/E
P2, P4 Empty weight + package Layout 4 1406 1875 540 27,5% 26,5% - - 23,5% 22,6% - - -
0654 A/E
01, 03, 05, 07 Empty weight + package Layout 4 1398 1820 540 28,3% 27,3% - - 22,6% 21,8% - - -
0654 A/E
02, 04, 06, 08 Empty weight + package Layout 4 1436 1846 539 28,0% 26,9% - - 23,0% 22,1% - - -
0654 A/E
00 Operation weight Layout 4 1325 1800 552 12,7% 12,8% 25,1% 25,2% 12,1% 12,2% - - VT 22
0654 A/E
P1, P3 Operation weight Layout 4 1366 1878 525 13,0% 11,9% 24,6% 22,5% 14,6% 13,3% - - VT 22
0654 A/E
P2, P4 Operation weight Layout 4 1414 1923 524 12,4% 11,3% 24,4% 22,3% 15,4% 14,1% - - VT 22
0654 A/E
01, 03, 05, 07 Operation weight Layout 4 1774 1990 519 7,5% 6,7% 31,0% 27,8% 14,2% 12,7% - - VT 22
0654 A/E
02, 04, 06, 08 Operation weight Layout 4 1820 2009 519 7,1% 6,4% 31,2% 27,9% 14,5% 12,9% - - VT 22
0704 A/E
00 Empty weight + package Layout 4 1410 1784 566 27,5% 29,2% - - 21,0% 22,3% - - -
0704 A/E
P1, P3 Empty weight + package Layout 4 1490 1893 540 27,2% 26,2% - - 23,7% 22,9% - - -
0704 A/E
P2, P4 Empty weight + package Layout 4 1569 1958 538 26,2% 25,1% - - 24,9% 23,8% - - -
0704 A/E
01, 03, 05, 07 Empty weight + package Layout 4 1522 1867 539 27,6% 26,6% - - 23,4% 22,5% - - -
0704 A/E
02, 04, 06, 08 Empty weight + package Layout 4 1599 1911 537 27,0% 25,8% - - 24,2% 23,1% - - -
0704 A/E
00 Operation weight Layout 4 1421 1830 547 11,7% 11,6% 26,3% 26,0% 12,3% 12,1% - - VT 22
0704 A/E
P1, P3 Operation weight Layout 4 1501 1936 522 11,6% 10,5% 25,7% 23,2% 15,3% 13,8% - - VT 22
0704 A/E
P2, P4 Operation weight Layout 4 1588 2005 521 10,7% 9,6% 25,4% 22,8% 16,6% 14,9% - - VT 22
0704 A/E
01, 03, 05, 07 Operation weight Layout 4 1909 2019 517 6,7% 5,9% 31,8% 28,3% 14,5% 12,9% - - VT 22
0704 A/E
02, 04, 06, 08 Operation weight Layout 4 1994 2051 517 6,0% 5,3% 32,1% 28,4% 14,9% 13,2% - - VT 22
0754 A/E
00 Empty weight + package Layout 4 1471 1731 565 28,4% 30,0% - - 20,2% 21,4% - - -
0754 A/E
P1, P3 Empty weight + package Layout 4 1551 1839 540 28,0% 27,0% - - 22,9% 22,1% - - -
0754 A/E
P2, P4 Empty weight + package Layout 4 1630 1905 538 27,1% 25,9% - - 24,0% 23,0% - - -
0754 A/E
01, 03, 05, 07 Empty weight + package Layout 4 1582 1815 539 28,4% 27,3% - - 22,5% 21,7% - - -
0754 A/E
02, 04, 06, 08 Empty weight + package Layout 4 1659 1860 537 27,8% 26,6% - - 23,3% 22,3% - - -
0754 A/E
00 Operation weight Layout 4 1490 1781 544 13,1% 12,8% 25,6% 25,0% 11,9% 11,6% - - VT 22
0754 A/E
P1, P3 Operation weight Layout 4 1570 1884 520 12,9% 11,6% 25,0% 22,4% 14,8% 13,2% - - VT 22
0754 A/E
P2, P4 Operation weight Layout 4 1657 1954 519 12,0% 10,7% 24,8% 22,1% 16,1% 14,3% - - VT 22
0754 A/E
01, 03, 05, 07 Operation weight Layout 4 1979 1975 516 7,9% 7,0% 31,1% 27,4% 14,1% 12,4% - - VT 22
0754 A/E
02, 04, 06, 08 Operation weight Layout 4 2064 2008 515 7,2% 6,4% 31,4% 27,6% 14,6% 12,8% - - VT 22
* For specic measurements of every layout please refer to the “Weight distribution” chapter.
