AERMEC NRB 0282 Series User Manual

25
Size
NRB
Version Hydronic kit Weight Layout
*
Weight
Centre of mass Percentage distribution of weights on supports
VTX Y 1 2 3 4 5 6 7 8
Kg mm mm % % % % % % % %
0552 A/E 00 Operation weight Layout 3 1070 1551 541 20,9% 20,2% 13,3% 12,8% 16,7% 16,1% - - VT 11
0552 A/E
P1, P3 Operation weight Layout 3 1111 1614 511 21,5% 18,6% 11,5% 10,0% 20,6% 17,8% - - VT 11
0552 A/E
P2, P4 Operation weight Layout 3 1159 1655 510 20,6% 17,8% 11,0% 9,6% 22,0% 19,0% - - VT 11
0552 A/E
01, 03, 05, 07 Operation weight Layout 3 1522 1658 508 14,2% 12,2% 24,4% 20,9% 15,2% 13,0% - - VT 11
0552 A/E
02, 04, 06, 08 Operation weight Layout 3 1568 1673 508 13,7% 11,7% 24,7% 21,2% 15,5% 13,3% - - VT 11
0602 A/E
00 Empty weight + package Layout 3 1116 1517 561 27,1% 28,2% - - 21,9% 22,8% - - -
0602 A/E
P1, P3 Empty weight + package Layout 3 1157 1579 532 27,0% 25,2% - - 24,7% 23,1% - - -
0602 A/E
P2, P4 Empty weight + package Layout 3 1197 1613 531 26,1% 24,3% - - 25,6% 23,9% - - -
0602 A/E
01, 03, 05, 07 Empty weight + package Layout 3 1190 1553 531 27,7% 25,8% - - 24,1% 22,4% - - -
0602 A/E
02, 04, 06, 08 Empty weight + package Layout 3 1228 1573 530 27,2% 25,3% - - 24,6% 22,9% - - -
0602 A/E
00 Operation weight Layout 3 1121 1561 541 20,3% 19,6% 14,1% 13,6% 16,5% 16,0% - - VT 11
0602 A/E
P1, P3 Operation weight Layout 3 1162 1621 512 20,8% 18,1% 12,4% 10,8% 20,3% 17,6% - - VT 11
0602 A/E
P2, P4 Operation weight Layout 3 1210 1660 511 20,0% 17,4% 11,9% 10,4% 21,6% 18,8% - - VT 11
0602 A/E
01, 03, 05, 07 Operation weight Layout 3 1573 1662 509 14,0% 12,0% 24,6% 21,2% 15,2% 13,0% - - VT 11
0602 A/E
02, 04, 06, 08 Operation weight Layout 3 1619 1676 509 13,5% 11,6% 24,9% 21,4% 15,4% 13,2% - - VT 11
0652 A/E
00 Empty weight + package Layout 3 1116 1517 561 27,1% 28,2% - - 21,9% 22,8% - - -
0652 A/E
P1, P3 Empty weight + package Layout 3 1157 1579 532 27,0% 25,2% - - 24,7% 23,1% - - -
0652 A/E
P2, P4 Empty weight + package Layout 3 1197 1613 531 26,1% 24,3% - - 25,6% 23,9% - - -
0652 A/E
01, 03, 05, 07 Empty weight + package Layout 3 1190 1553 531 27,7% 25,8% - - 24,1% 22,4% - - -
0652 A/E
02, 04, 06, 08 Empty weight + package Layout 3 1228 1573 530 27,2% 25,3% - - 24,6% 22,9% - - -
0652 A/E
00 Operation weight Layout 3 1121 1561 541 20,3% 19,6% 14,1% 13,6% 16,5% 16,0% - - VT 11
0652 A/E
P1, P3 Operation weight Layout 3 1162 1621 512 20,8% 18,1% 12,4% 10,8% 20,3% 17,6% - - VT 11
0652 A/E
P2, P4 Operation weight Layout 3 1210 1660 511 20,0% 17,4% 11,9% 10,4% 21,6% 18,8% - - VT 11
0652 A/E
01, 03, 05, 07 Operation weight Layout 3 1573 1662 509 14,0% 12,0% 24,6% 21,2% 15,2% 13,0% - - VT 11
0652 A/E
02, 04, 06, 08 Operation weight Layout 3 1619 1676 509 13,5% 11,6% 24,9% 21,4% 15,4% 13,2% - - VT 11
0682 A/E
00 Empty weight + package Layout 4 1347 1722 561 28,7% 29,9% - - 20,2% 21,1% - - -
0682 A/E
P1, P3 Empty weight + package Layout 4 1427 1838 534 28,3% 26,7% - - 23,1% 21,8% - - -
0682 A/E
P2, P4 Empty weight + package Layout 4 1506 1909 532 27,3% 25,6% - - 24,3% 22,8% - - -
0682 A/E
01, 03, 05, 07 Empty weight + package Layout 4 1459 1812 533 28,8% 27,1% - - 22,7% 21,4% - - -
0682 A/E
02, 04, 06, 08 Empty weight + package Layout 4 1536 1861 532 28,1% 26,3% - - 23,6% 22,1% - - -
0682 A/E
00 Operation weight Layout 4 1361 1773 540 14,1% 13,6% 24,5% 23,6% 12,3% 11,9% - - VT 22
0682 A/E
P1, P3 Operation weight Layout 4 1441 1885 514 13,9% 12,2% 23,9% 21,0% 15,4% 13,6% - - VT 22
0682 A/E
P2, P4 Operation weight Layout 4 1528 1959 513 12,8% 11,2% 23,7% 20,7% 16,8% 14,7% - - VT 22
0682 A/E
01, 03, 05, 07 Operation weight Layout 4 1849 1982 511 8,3% 7,2% 30,7% 26,6% 14,6% 12,7% - - VT 22
0682 A/E
02, 04, 06, 08 Operation weight Layout 4 1934 2017 511 7,5% 6,5% 31,0% 26,8% 15,1% 13,1% - - VT 22
0702 A/E
00 Empty weight + package Layout 4 1507 1675 570 29,0% 31,2% - - 19,2% 20,7% - - -
0702 A/E
P1, P3 Empty weight + package Layout 4 1587 1782 545 28,7% 28,2% - - 21,8% 21,4% - - -
0702 A/E
P2, P4 Empty weight + package Layout 4 1666 1849 543 27,7% 27,0% - - 22,9% 22,4% - - -
0702 A/E
01, 03, 05, 07 Empty weight + package Layout 4 1619 1759 544 29,1% 28,5% - - 21,5% 21,0% - - -
0702 A/E
02, 04, 06, 08 Empty weight + package Layout 4 1696 1807 542 28,4% 27,6% - - 22,3% 21,7% - - -
0702 A/E
00 Operation weight Layout 4 1520 1721 551 15,0% 15,1% 23,3% 23,4% 11,6% 11,6% - - VT 22
0702 A/E
P1, P3 Operation weight Layout 4 1600 1824 527 14,9% 13,7% 22,8% 21,0% 14,3% 13,2% - - VT 22
0702 A/E
P2, P4 Operation weight Layout 4 1687 1895 526 13,9% 12,8% 22,7% 20,8% 15,6% 14,3% - - VT 22
0702 A/E
01, 03, 05, 07 Operation weight Layout 4 2008 1926 522 9,6% 8,7% 29,2% 26,3% 13,8% 12,4% - - VT 22
0702 A/E
02, 04, 06, 08 Operation weight Layout 4 2093 1960 521 8,9% 8,0% 29,5% 26,5% 14,2% 12,8% - - VT 22
0752 A/E
00 Empty weight + package Layout 4 1531 1662 570 29,2% 31,4% - - 19,0% 20,4% - - -
0752 A/E
P1, P3 Empty weight + package Layout 4 1611 1768 545 28,9% 28,4% - - 21,6% 21,2% - - -
0752 A/E
P2, P4 Empty weight + package Layout 4 1690 1835 543 27,9% 27,2% - - 22,7% 22,1% - - -
0752 A/E
01, 03, 05, 07 Empty weight + package Layout 4 1643 1746 544 29,3% 28,7% - - 21,2% 20,8% - - -
0752 A/E
02, 04, 06, 08 Empty weight + package Layout 4 1720 1793 542 28,6% 27,8% - - 22,1% 21,5% - - -
0752 A/E
00 Operation weight Layout 4 1555 1712 548 15,2% 15,1% 23,5% 23,3% 11,5% 11,4% - - VT 22
0752 A/E
P1, P3 Operation weight Layout 4 1635 1814 524 15,1% 13,8% 23,0% 21,0% 14,2% 12,9% - - VT 22
0752 A/E
P2, P4 Operation weight Layout 4 1722 1884 523 14,1% 12,8% 22,8% 20,7% 15,5% 14,0% - - VT 22
0752 A/E
01, 03, 05, 07 Operation weight Layout 4 2043 1916 520 9,9% 8,8% 29,2% 26,2% 13,7% 12,2% - - VT 22
0752 A/E
02, 04, 06, 08 Operation weight Layout 4 2128 1950 519 9,1% 8,2% 29,6% 26,4% 14,1% 12,6% - - VT 22
