AERMEC NRB 0282 Series User Manual

45
TOTAL INPUT
Size NRB Ver. 0282 0302 0332 0352 0502 0552 0602 0652 0682 0702 0752 0604 0654 0704 0754
Version 00 data
Maximum current (F.L.A.)
° A - - - - 80 86 94 102 123 140 158 124 130 146 158
L A 58 62 65 72 80 86 94 102 123 140 158 124 130 146 158
A A - - - - 80 86 94 102 123 140 158 124 134 146 158
E A 59 62 66 72 80 86 94 102 123 140 158 124 134 146 158
U A - - - 74 80 86 98 106 123 144 161 128 134 149 161
N A 59 63 66 74 80 86 98 106 123 144 161 128 134 149 161
Peak current (L.R.A.)
° A - - - - 265 271 318 326 368 385 483 233 239 286 343
L A 155 171 174 212 265 271 318 326 368 385 483 233 239 286 343
A A - - - - 265 271 318 326 368 385 483 233 243 286 343
E A 156 171 175 212 265 271 318 326 368 385 483 233 243 286 343
U A - - - 214 265 271 322 330 368 388 486 237 243 289 346
N A 156 172 175 214 265 271 322 330 368 388 486 237 243 289 346
Size NRB 0282 0302 0332 0352 0502 0552 0602 0652 0682 0702 0752 0604 0654 0704 0754
Single Hydronic kits’ data
Low head
P1-P2-01-02-05-06-I1-I2-K1-K2
Max.
power
kW 1,40 1,40 1,40 1,40 1,40 1,40 1,91 1,91 3,43 3,43 4,29 1,91 1,91 3,43 4,29
Max.
current
A 2,51 2,51 2,51 2,51 2,51 2,51 3,41 3,41 6,33 6,33 7,62 3,41 3,41 6,33 7,62
High head
P3-P4-03-04-07-08-I3-I4-K3-K4
Max.
power
kW 2,56 2,56 2,56 2,56 2,56 2,56 3,40 3,40 5,93 5,93 5,93 3,40 3,40 5,93 5,93
Max.
current
A 4,53 4,53 4,53 4,53 4,53 4,53 5,86 5,86 10,50 10,50 10,50 5,86 5,86 10,50 10,50
Size
NRB
Power supply Compressors Fans
RECOMMENDED CABLE CROSS SECTION
Power cables
Control and safeties
connection
Earth
IL
Phases
Cables per
phases
Cross section
Neutral
section
Total cables Cross section Cross section
(n°) (n°) (n°) (n°) (mm
2
) (mm
2
) (n°) (mm
2
) (mm
2
) (A)
0282
400V-3+N-50Hz
2 6 3+N 1 25 16 4 1,5 16 100
0302 2 8 3+N 1 25 16 4 1,5 16 100
0332 2 8 3+N 1 25 16 4 1,5 16 100
0352 2 8 3+N 1 35 16 4 1,5 16 100
0502 2 2 3+N 1 35 16 4 1,5 16 125
0552 2 2 3+N 1 35 16 4 1,5 16 125
0602 2 3 3+N 1 50 25 4 1,5 25 125
0652 2 3 3+N 1 50 25 4 1,5 25 125
0682 2 3 3+N 1 70 35 4 1,5 35 160
0702 2 4 3+N 1 70 35 4 1,5 35 200
0752 2 4 3+N 1 70 35 4 1,5 35 200
0604 4 3 3+N 1 50 25 4 1,5 25 160
0654 4 3 3+N 1 50 25 4 1,5 25 160
0704 4 4 3+N 1 70 35 4 1,5 35 200
0754 4 4 3+N 1 70 35 4 1,5 35 200
Earth Earth connection to the unit
3+N: 3 phase + neutral
IL Master switch
F.L.A. Maximum current
L.R.A. Peak current
The hydronic kit P2-P4-02-04-06-08-I2-14-K2-K4 have two twin pumps including 1-up and 1 spare
ELECTRICAL DATA UNIT WITH AND WITHOUT HYDRONIC KIT
