30 11_14. 5641200_01
NRL 0280-0750 60Hz
EN
1
2
capable of, for the correct use of the unit, are:
(1) Moving from one menu to the next.
Moving between menus
(a) To move between the menus, the order in which they are dis-
played is shown in the previous page, enter the menu selection
mode by pressing the key (
).
between menus using the arrow keys: the key (
) to move to the
previous menu, and the key (
) to move to the next menu.
(c) When the desired menu is seen press the key (
)to enter the
menu. Press the key(
) to return to the menu selection mode.
Selecting and modifying a menu
1
), it
is possible to move between the screens using the arrow keys: the
key (
) to move to the previous parameter, and the key (
) to
move to the next parameter.
(c) When the desired parameter is seen press the key (
) to enter
the parameter. To exit the parameter and return to the parameter
selection mode press the key (
).
),
the parameter selection mode is automatically accessed and in this
mode the desired parameter values can be set with the following
procedure:
(1) Pressing the key (
) causes a flashing cursor to appear on the
first modifiable field of the parameter. If no modifiable fields are
displayed then the cursor will not appear.
(2) Pressing the key (
) or the key (
), the value of the field can
be increased or decreased.
(3) Pressing the key (
) confirms the modification of the field
selected the number of modifiable fields can change.
previous menu
next
menu
exiting a menu
entering a
menu
previous para-
meter
next
parameter
exiting a
parameter
entering a para-
meter
16. USER OPERATING PROCEDURES
