16 22.11 5806712_07
DURING OPERATION
Version
Integrated
hydronic kit user
side
Integrated
hydronic kit,
recovery side
0800 0900 1000 1250 1400 1500 1650 1800
Weight
functioning
A 00 00 lbs 7,209 7,584 7,584 10,097 10,185 10,296 10,737 11,045
A 00 R1/R3 lbs 7,562 7,915 7,915 10,494 10,582 10,692 11,133 11,442
A 00 R2/R4 lbs 7,848 8,201 8,201 10,803 10,913 11,001 11,442 11,751
A P1/P3 00 lbs 7,584 7,959 7,959 10,516 10,626 10,737 11,177 11,486
A P1/P3 R1/R3 lbs 7,937 8,289 8,289 10,913 11,023 11,111 11,552 11,861
A P1/P3 R2/R4 lbs 8,223 8,576 8,576 11,244 11,332 11,442 11,883 12,192
A P2/P4 00 lbs 7,738 8,113 8,113 10,759 10,847 10,957 11,398 11,707
A P2/P4 R1/R3 lbs 8,091 8,444 8,444 11,133 11,244 11,354 11,773 12,103
A P2/P4 R2/R4 lbs 8,356 8,730 8,730 11,464 11,552 11,662 12,103 12,412
X
A 00 00 in 68.7 70.9 69.8 93.6 93.8 93.5 99.4 98.0
A 00 R1/R3 in 69.8 72.0 70.8 94.8 95.1 94.7 100.3 99.0
A 00 R2/R4 in 70.7 72.8 71.7 95.8 96.0 95.6 101.1 99.7
A P1/P3 00 in 67.6 69.8 68.7 92.7 92.9 92.6 98.3 97.0
A P1/P3 R1/R3 in 68.7 70.9 69.8 93.9 94.1 93.8 99.3 98.0
A P1/P3 R2/R4 in 69.6 71.7 70.6 94.9 95.1 94.7 100.0 98.7
A P2/P4 00 in 67.2 69.4 68.3 92.3 92.5 92.2 97.8 96.5
A P2/P4 R1/R3 in 68.3 70.4 69.3 93.5 93.7 93.4 98.8 97.5
A P2/P4 R2/R4 in 69.3 71.3 70.2 94.4 94.6 94.3 99.5 98.2
Y
A 00 00 in 46.9 47.9 49.4 48.3 48.5 48.6 43.9 44.8
A 00 R1/R3 in 46.2 47.2 48.6 47.7 47.8 48.0 43.5 44.4
A 00 R2/R4 in 45.7 46.7 48.1 47.2 47.4 47.5 43.1 44.0
A P1/P3 00 in 45.2 46.2 47.6 47.0 47.3 47.4 42.9 43.9
A P1/P3 R1/R3 in 44.6 45.6 47.0 46.6 46.7 46.8 42.6 43.5
A P1/P3 R2/R4 in 44.2 45.2 46.5 46.1 46.3 46.5 42.3 43.1
A P2/P4 00 in 44.4 45.6 47.0 46.5 46.7 46.8 42.5 43.4
A P2/P4 R1/R3 in 44.0 45.0 46.3 46.0 46.2 46.3 42.1 43.0
A P2/P4 R2/R4 in 43.6 44.6 45.9 45.6 45.7 45.9 41.8 42.7
1
A 00 00 % 10.0% 9.0% 9.4% 10.0% 9.8% 9.9% 8.7% 9.0%
A 00 R1/R3 % 9.4% 8.4% 8.8% 9.7% 9.5% 9.6% 8.4% 8.7%
A 00 R2/R4 % 8.9% 8.0% 8.4% 9.4% 9.3% 9.3% 8.2% 8.5%
A P1/P3 00 % 10.7% 9.7% 10.1% 10.1% 9.9%
9.9% 8.8% 9.1%
A P1/P3 R1/R3 % 10.0% 9.1% 9.5% 9.8% 9.6% 9.6% 8.5% 8.8%
A P1/P3 R2/R4 % 9.5% 8.6% 9.0% 9.5% 9.4% 9.4% 8.3% 8.6%
A P2/P4 00 % 11.0% 9.9% 10.3% 10.1% 9.9% 10.0% 8.8% 9.1%
A P2/P4 R1/R3 % 10.3% 9.3% 9.7% 9.8% 9.6% 9.7% 8.6% 8.8%
A P2/P4 R2/R4 % 9.8% 8.9% 9.3% 9.5% 9.4% 9.4% 8.3% 8.6%
2
A 00 00 % 11.8% 11.1% 12.4% 12.6% 12.5% 12.6% 9.0% 9.6%
A 00 R1/R3 % 10.7% 10.1% 11.3% 11.8% 11.7% 11.8% 8.5% 9.1%
A 00 R2/R4 % 9.9% 9.3% 10.5% 11.3% 11.2% 11.3% 8.1% 8.8%
A P1/P3 00 % 11.7% 11.0% 12.3% 12.0% 11.9% 12.0% 8.6% 9.3%
A P1/P3 R1/R3 % 10.6% 10.1% 11.2% 11.3% 11.2% 11.3% 8.2% 8.8%
A P1/P3 R2/R4 % 9.9% 9.4% 10.5% 10.8% 10.7% 10.9% 7.9% 8.5%
A P2/P4 00 % 11.6% 11.0% 12.2% 11.7% 11.6% 11.7% 8.5% 9.1%
A P2/P4 R1/R3 % 10.6% 10.1% 11.2% 11.1% 11.0% 11.1% 8.1% 8.7%
A P2/P4 R2/R4 % 9.9% 9.4% 10.4% 10.6% 10.5% 10.6% 7.8% 8.4%
3
A 00 00 % 31.9% 30.7% 29.0% 17.5% 17.3% 17.4% 17.8% 18.4%
A 00 R1/R3 % 33.0% 31.7% 30.1% 16.5% 16.3% 16.4% 16.7% 17.4%
A 00 R2/R4 % 33.9% 32.6% 31.0% 15.7% 15.5% 15.7% 15.9% 16.6%
A P1/P3 00 % 33.6% 32.3% 30.7% 20.1% 19.9% 20.0% 20.4% 20.9%
A P1/P3 R1/R3 % 34.6% 33.3% 31.7% 19.0% 18.8% 18.9% 19.3% 19.8%
A P1/P3 R2/R4 % 35.4% 34.0% 32.5% 18.2% 18.0% 18.1% 18.4% 19.0%
A P2/P4 00 % 34.3% 32.9% 31.3% 21.4% 21.2% 21.3% 21.7% 22.1%
A P2/P4 R1/R3 % 35.2% 33.9% 32.3% 20.3% 20.0% 20.2% 20.5% 21.0%
A P2/P4 R2/R4 % 35.9% 34.6% 33.1% 19.4% 19.2% 19.3% 19.6% 20.1%
4
A 00 00 % 37.6% 37.9% 38.3% 22.0% 21.9% 22.2% 18.3% 19.8%
A 00 R1/R3 % 37.7% 38.0% 38.5% 20.1% 20.0% 20.4% 16.8% 18.3%
A 00 R2/R4 % 37.8% 38.1% 38.5% 18.8% 18.7% 19.0% 15.8% 17.2%
A P1/P3 00 % 36.6% 36.9% 37.4% 24.0% 23.8% 24.2% 20.1% 21.5%
A P1/P3 R1/R3 % 36.7% 37.0% 37.5% 22.1% 22.0% 22.3% 18.6% 19.9%
A P1/P3 R2/R4 % 36.7% 37.1% 37.6% 20.7% 20.6% 20.9% 17.5% 18.8%
A P2/P4 00 % 36.2% 36.5% 37.0% 24.9% 24.7% 25.0% 20.9% 22.2%
A P2/P4 R1/R3 % 36.3% 36.6% 37.1% 23.0% 22.8% 23.1% 19.4% 20.7%
A P2/P4 R2/R4 % 36.3% 36.7% 37.2% 21.6% 21.5% 21.8% 18.3% 19.6%
5
A 00 00 % 3.9% 5.1% 4.7% 13.9% 14.2%
13.9% 18.5% 16.7%
A 00 R1/R3 % 4.3% 5.3% 5.0% 16.0% 16.3% 15.9% 20.4% 18.6%
A 00 R2/R4 % 4.5% 5.6% 5.2% 17.6% 17.8% 17.5% 21.9% 20.1%
A P1/P3 00 % 3.6% 4.7% 4.3% 12.6% 12.9% 12.6% 16.9% 15.3%
A P1/P3 R1/R3 % 3.9% 5.0% 4.6% 14.7% 15.0% 14.7% 18.9% 17.2%
A P1/P3 R2/R4 % 4.2% 5.2% 4.8% 16.3% 16.5% 16.2% 20.4% 18.7%
A P2/P4 00 % 3.4% 4.6% 4.2% 12.0% 12.3% 12.0% 16.2% 14.7%
A P2/P4 R1/R3 % 3.8% 4.8% 4.5% 14.1% 14.3% 14.0% 18.2% 16.6%
A P2/P4 R2/R4 % 4.0% 5.1% 4.7% 15.6% 15.9% 15.5% 19.6% 18.0%
