AERMEC NXP 0700 Installation Manual

8 21.05 - 6068956_00
NXP 0500 - 1650 2-PIPE SYSTEM / 4-PIPE SYSTEM
EN
2120 mm
83.46 mm
1250 mm
49.21 in
3450 mm
135.83 in
135.83 in
NXP 0500 ÷ 900[L]
300 mm
11.81 in 11.81 in 15.94 in
48.11 in 48.11 in
35 mm 1.38 in 1.38 in
1.38 in
35 mm
35 mm 1164 mm
1222 mm 1222 mm
300 mm 405 mm
1202 mm
320 mm
1202 mm
3450 mm
320 mm 405mm
1975 mm
12.60 in 12.60 in
47.32 in 47.32 in
15.94 in
77.76 in
45.83 in
WITH PUMPS
Model
DIMENSIONS (mm)
ANTIVIBRANT POSITION MOUNTS (mm)
Bottom View
LIFTING POINTS (mm)
3750
NXP 1000 ÷ 1650[L]
410
3750 mm
135.83 in
1250 mm
49.21 in
2120 mm
83.46 mm
1975 mm
77.76 in
350 mm 1320 mm 1320 mm
13.78 in
350 mm
13.78 in 16.14 in
410 mm
51.97 in
51.97 in
35 mm 1.38 in
35 mm 1.38 in
1320 mm
51.97 in
1320 mm
51.97 in
760 mm
29.92 in
1180 mm 46.46 in
35 mm 1.38 in
Model
DIMENSIONS (mm)
ANTIVIBRANT POSITION MOUNTS (mm)
Boom View
LIFTING POINTS (mm)
WITH PUMPS
