AERMEC NXP 0700 - Unit Lifting Procedures; Minimum Technical Spaces for Installation

921.05 - 6068956_00
NXP 0500 - 1650 2-PIPE SYSTEM / 4-PIPE SYSTEM
EN
3750
NXP 1000 ÷ 1650[L]
410
3750 mm
135.83 in
1250 mm
49.21 in
2120 mm
83.46 mm
1975 mm
77.76 in
350 mm 1320 mm 1320 mm
13.78 in
350 mm
13.78 in 16.14 in
410 mm
51.97 in
51.97 in
35 mm 1.38 in
35 mm 1.38 in
1320 mm
51.97 in
1320 mm
51.97 in
760 mm
29.92 in
1180 mm 46.46 in
35 mm 1.38 in
Model
DIMENSIONS (mm)
ANTIVIBRANT POSITION MOUNTS (mm)
Boom View
LIFTING POINTS (mm)
WITH PUMPS
