22
INXWPY. 1610. 4438880_01
9.3.
PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS (VERSION H
SIZES FROM 0500 TO 0750
NOTE
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head) is negligible.
NOTE
Version with desuperheater (D)
- use the same positions for antivibration pad xing as for the AVX of the standard version
- desuperheater additional weight : 23 kg for all models from 500 to 800 size / 29 kg. for all models from 900 to 1400 size
MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500H
without pump 628 401 849 27% 27% 23% 23% 319
1 pump 730 396 923 33% 33% 17% 17%
320
2 pumps 778 394 989 32% 31% 19% 18%
3 pumps 825 392 1047 31% 30% 20% 19%
309
4 pumps 872 390 1098 30% 29% 21% 20%
NXW0550H
without pump 633 401 846 27% 27% 23% 23% 319
1 pump 735 396 920 33% 33% 17% 17%
320
2 pumps 782 394 985 32% 31% 19% 18%
3 pumps 829 392 1043 31% 30% 20% 19%
309
4 pumps 877 391 1095 30% 29% 21% 20%
NXW0600H
without pump 734 406 911 25% 26% 24% 25% 301
1 pump 836 401 968 32% 32% 18% 18% 320
2 pumps 884 399 1023 31% 31% 19% 19%
309
3 pumps 931 397 1073 30% 30% 20% 20%
4 pumps 978 395 1118 30% 29% 21% 20% 312
NXW0650H
without pump 743 407 910 25% 26% 24% 25% 301
1 pump 848 401 970 32% 32% 18% 18%
309
2 pumps 899 399 1028 31% 31% 19% 19%
3 pumps 950 397 1080 30% 30% 20% 20% 311
4 pumps 1000 396 1127 29% 29% 21% 21% 312
NXW0700H
without pump 791 406 932 24% 25% 25% 26% 302
1 pump 896 401 1048 31% 31% 19% 19% 309
2 pumps 947 399 1099 30% 30% 20% 20% 311
3 pumps 997 397 1145 29% 29% 21% 21%
312
4 pumps 1048 395 1186 28% 28% 22% 22%
NXW0750H
without pump 948 410 1103 24% 25% 25% 26% 310
1 pump 1064 405 1223 27% 28% 22% 23%
651
2 pumps 1124 403 1279 26% 26% 24% 24%
3 pumps 1185 401 1330 25% 25% 25% 25%
4 pumps 1225 399 1361 27% 27% 23% 23%
