9.4. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION H  SIZES FROM 0800 TO 1650
NOTE
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head) is negligible.
NOTE
Version with desuperheater (D)
- use the same positions for antivibration pad xing as for the AVX of the standard version
- desuperheater additional weight : 23 kg for all models from 500 to 800 size / 29 kg. for all models from 900 to 1400 size
MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0800H
without pump 1042 415 1227 24% 26% 24% 26% 310
1 pump 1157 410 1244 29% 30% 20% 21%
651
2 pumps 1218 408 1295 28% 29% 21% 22%
3 pumps 1278 406 1341 27% 28% 22% 23%
4 pumps 1339 404 1384 27% 27% 23% 23%
NXW0900H
without pump 1275 415 1240 23% 25% 25% 27% 314
1 pump 1391 411 1348 29% 31% 19% 20%
665
2 pumps 1451 409 1399 29% 30% 20% 21%
3 pumps 1512 407 1446 28% 29% 21% 22%
4 pumps 1572 405 1489 28% 28% 22% 22%
NXW1000H
without pump 1545 413 1333 22% 23% 27% 28% 316
1 pump 1686 409 1435 28% 30% 21% 22%
654
2 pumps 1771 407 1489 28% 29% 22% 22%
3 pumps 1857 405 1539 27% 28% 22% 23%
4 pumps 1892 404 1558 27% 27% 23% 23%
NXW1250H
without pump 1577 414 1322 22% 23% 26% 28% 315
1 pump 1718 410 1423 28% 30% 20% 21%
654
2 pumps 1803 408 1477 28% 29% 21% 22%
3 pumps 1889 406 1527 27% 28% 22% 23%
4 pumps 1924 405 1546 27% 28% 22% 23%
NXW1400H
without pump 1657 413 1342 22% 23% 27% 29% 317
1 pump 1797 409 1437 28% 30% 21% 22%
654
2 pumps 1883 407 1488 28% 29% 21% 22%
3 pumps 1969 405 1535 27% 28% 22% 23%
4 pumps 2004 404 1554 27% 27% 23% 23%
NXW1500H
without pump 1657 413 1342 22% 23% 27% 29% 317
1 pump 1797 409 1437 28% 30% 21% 22%
654
2 pumps 1883 407 1488 28% 29% 21% 22%
3 pumps 1969 405 1535 27% 28% 22% 23%
4 pumps 2004 404 1554 27% 27% 23% 23%
NXW1650H
without pump 1657 413 1342 22% 23% 27% 29% 317
1 pump 1797 409 1437 28% 30% 21% 22%
654
2 pumps 1883 407 1488 28% 29% 21% 22%
3 pumps 1969 405 1535 27% 28% 22% 23%
4 pumps 2004 404 1554 27% 27% 23% 23%
