AERMEC NXW0500 - Page 24

24
INXWPY. 1610. 4438880_01
MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500L
without pump 750 399 834 28% 27% 23% 22% 309
1 pump 932 392 895 34% 33% 17% 16% 321
2 pumps 979 391 948 33% 32% 18% 17%
311
3 pumps 1026 389 996 32% 31% 19% 18%
4 pumps 1074 388 1183 29% 27% 23% 21% 312
NXW0550L
without pump 755 399 832 28% 27% 23% 22% 309
1 pump 936 392 892 34% 33% 17% 16% 321
2 pumps 983 391 946 33% 32% 18% 17%
311
3 pumps 1031 390 994 32% 31% 19% 18%
4 pumps 1078 389 1180 29% 27% 22% 21% 312
NXW0600L
without pump 854 404 888 26% 26% 24% 24% 310
1 pump 1036 397 933 33% 32% 17% 17%
311
2 pumps 1083 395 979 32% 32% 18% 18%
3 pumps 1130 394 1022 32% 31% 19% 19% 312
4 pumps 1178 393 1191 28% 27% 22% 22%
NXW0650L
without pump 863 405 887 26% 26% 24% 24% 303
1 pump 1048 397 935 33% 32% 17% 17%
311
2 pumps 1098 396 984 32% 31% 18% 18%
3 pumps 1149 394 1029 31% 31% 19% 19% 312
4 pumps 1200 393 1197 28% 27% 23% 22% 310
NXW0700L
without pump 900 407 901 25% 26% 24% 25% 303
1 pump 1084 400 1085 30% 30% 20% 20%
651
2 pumps 1135 398 1126 29% 29% 21% 21%
3 pumps 1186 396 1164 29% 28% 22% 21%
4 pumps 1236 395 1198 28% 27% 22% 22%
NXW0750L
without pump 1054 410 1087 24% 25% 25% 26% 310
1 pump 1249 403 1271 29% 29% 21% 21%
651
2 pumps 1310 401 1318 28% 28% 22% 22%
3 pumps 1370 399 1360 27% 27% 23% 23%
4 pumps 1411 398 1386 27% 27% 23% 23%
NOTE
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head) is negligible.
NOTE
Version with desuperheater (D)
- use the same positions for antivibration pad xing as for the AVX of the standard version
- desuperheater additional weight : 23 kg for all models from 500 to 800 size / 29 kg. for all models from 900 to 1400 size
9.5. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION L  SIZES FROM 0500 TO 0750
