25
INXWPY. 1610. 4438880_01
9.6. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION L  SIZES FROM 0800 TO 1650
MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0800L
without pump 1187 411 1226 24% 25% 25% 26% 314
1 pump 1357 405 1292 28% 29% 21% 22%
652
2 pumps 1417 403 1334 28% 28% 22% 22%
3 pumps 1478 402 1373 27% 27% 23% 23%
4 pumps 1538 400 1408 27% 27% 23% 23%
NXW0900L
without pump 1378 418 1220 24% 26% 24% 26% 314
1 pump 1585 411 1399 29% 30% 20% 21%
653
2 pumps 1646 409 1442 28% 29% 21% 22%
3 pumps 1706 407 1482 28% 29% 21% 22%
4 pumps 1767 406 1519 27% 28% 22% 23%
NXW1000L
without pump 1615 420 1300 22% 24% 26% 28% 315
1 pump 1847 413 1462 28% 29% 21% 22%
654
2 pumps 1933 411 1511 27% 29% 22% 23%
3 pumps 2019 409 1556 27% 28% 22% 23%
4 pumps 2054 408 1573 26% 27% 23% 24%
NXW1250L
without pump 1659 419 1296 22% 24% 26% 28% 315
1 pump 1891 412 1455 28% 29% 21% 22%
659
2 pumps 1977 410 1503 27% 29% 22% 23%
3 pumps 2063 408 1547 27% 28% 22% 23%
4 pumps 2098 407 1564 27% 27% 23% 23%
NXW1400L
without pump 1737 418 1316 22% 24% 26% 28% 317
1 pump 1969 411 1466 28% 29% 21% 22%
659
2 pumps 2055 409 1512 27% 28% 22% 23%
3 pumps 2140 407 1555 27% 28% 22% 23%
4 pumps 2176 407 1571 26% 27% 23% 24%
NXW1500L
without pump 1737 418 1316 22% 24% 26% 28% 317
1 pump 1969 411 1466 28% 29% 21% 22%
659
2 pumps 2055 409 1512 27% 28% 22% 23%
3 pumps 2140 407 1555 27% 28% 22% 23%
4 pumps 2176 407 1571 26% 27% 23% 24%
NXW1650L
without pump 1737 418 1316 22% 24% 26% 28% 317
1 pump 1969 411 1466 28% 29% 21% 22%
659
2 pumps 2055 409 1512 27% 28% 22% 23%
3 pumps 2140 407 1555 27% 28% 22% 23%
4 pumps 2176 407 1571 26% 27% 23% 24%
NOTE
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head) is negligible.
NOTE
Version with desuperheater (D)
- use the same positions for antivibration pad xing as for the AVX of the standard version
- desuperheater additional weight : 23 kg for all models from 500 to 800 size / 29 kg. for all models from 900 to 1400 size
