AERMEC NXW0500 - Page 26

26
INXWPY. 1610. 4438880_01
MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS %
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500HL
without pump
801 393 847 28% 27% 23% 22% 309
1 pump 982 387 902 34% 32% 17% 16%
311
2 pumps 1030 386 952 33% 31% 18% 17%
3 pumps 1077 385 998 33% 30% 19% 18%
312
4 pumps 1124 384 1041 32% 30% 20% 19%
NXW0550HL
without pump 805 393 845 28% 27% 23% 22% 309
1 pump 987 388 900 34% 32% 17% 16%
311
2 pumps 1034 387 950 33% 31% 18% 17%
3 pumps 1081 386 996 33% 30% 19% 18%
312
4 pumps 1129 385 1038 32% 30% 20% 18%
NXW0600HL
without pump 907 398 897 26% 26% 24% 24% 310
1 pump 1088 392 938 33% 32% 18% 17% 311
2 pumps 1135 391 983 33% 31% 19% 18%
3123 pumps 1183 390 1023 32% 30% 19% 18%
4 pumps 1230 389 1061 31% 30% 20% 19%
NXW0650HL
without pump 915 399 897 26% 26% 24% 24% 303
1 pump 1100 393 941 33% 32% 18% 17% 311
2 pumps 1151 391 987 32% 31% 19% 18%
3133 pumps 1201 390 1030 32% 30% 20% 19%
4 pumps 1252 389 1069 31% 29% 20% 19%
NXW0700HL
without pump 963 398 916 25% 25% 25% 25% 304
1 pump 1148 393 1088 30% 29% 21% 20%
651
2 pumps 1199 392 1126 30% 29% 21% 20%
3 pumps 1249 390 1162 29% 28% 22% 21%
4 pumps 1300 389 1194 29% 27% 23% 22%
NXW0750HL
without pump 1121 403 1105 24% 24% 26% 26% 314
1 pump 1316 397 1277 27% 26% 24% 23%
652
2 pumps 1376 395 1321 26% 25% 25% 24%
3 pumps 1437 394 1361 25% 24% 26% 25%
4 pumps 1477 393 1386 27% 27% 23% 23%
9.7. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION HL  SIZES FROM 0500 TO 750
NOTE
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head) is negligible.
NOTE
Version with desuperheater (D)
- use the same positions for antivibration pad xing as for the AVX of the standard version
- desuperheater additional weight : 23 kg for all models from 500 to 800 size / 29 kg. for all models from 900 to 1400 size
