27
INXWPY. 1610. 4438880_01
MODEL
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0800HL
without pump 1240 407 1228 24% 25% 25% 26% 314
1 pump 1409 402 1291 28% 29% 21% 22%
665
2 pumps 1470 400 1331 28% 28% 22% 22%
3 pumps 1530 399 1368 27% 27% 23% 23%
4 pumps 1591 397 1403 27% 27% 23% 23%
NXW0900HL
without pump 1473 408 1239 24% 25% 25% 26% 315
1 pump 1680 402 1406 29% 30% 21% 21%
653
2 pumps 1740 401 1446 29% 29% 21% 21%
3 pumps 1801 400 1484 28% 28% 22% 22%
4 pumps 1861 399 1519 28% 28% 22% 22%
NXW1000HL
without pump 1743 408 1322 22% 23% 27% 28% 317
1 pump 1975 402 1471 28% 29% 22% 22%
659
2 pumps 2061 401 1516 28% 28% 22% 22%
3 pumps 2147 399 1558 27% 27% 23% 23%
4 pumps 2182 399 1575 27% 27% 23% 23%
NXW1250
without pump 1775 408 1313 22% 23% 27% 28% 317
1 pump 2007 403 1460 28% 29% 21% 22%
659
2 pumps 2093 402 1506 28% 28% 22% 22%
3 pumps 2178 400 1548 27% 27% 23% 23%
4 pumps 2214 399 1564 27% 27% 23% 23%
NXW1400HL
without pump 1855 408 1331 22% 23% 27% 28% 318
1 pump 2087 403 1471 28% 29% 21% 22%
659
2 pumps 2173 401 1514 28% 28% 22% 22%
3 pumps 2258 400 1554 27% 27% 23% 23%
4 pumps 2294 399 1570 27% 27% 23% 23%
NXW1500HL
without pump 1855 408 1331 22% 23% 27% 28% 318
1 pump 2087 403 1471 28% 29% 21% 22%
659
2 pumps 2173 401 1514 28% 28% 22% 22%
3 pumps 2258 400 1554 27% 27% 23% 23%
4 pumps 2294 399 1570 27% 27% 23% 23%
NXW1650HL
without pump 1855 408 1331 22% 23% 27% 28% 318
1 pump 2087 403 1471 28% 29% 21% 22%
659
2 pumps 2173 401 1514 28% 28% 22% 22%
3 pumps 2258 400 1554 27% 27% 23% 23%
4 pumps 2294 399 1570 27% 27% 23% 23%
9.8. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION HL  SIZES FROM 0800 TO 1650
NOTE
- The number of pumps refers to the quantity physically present on the machine.
- The weight difference between the types of configurator pumps (low head and high head) is negligible.
NOTE
Version with desuperheater (D)
- use the same positions for antivibration pad xing as for the AVX of the standard version
- desuperheater additional weight : 23 kg for all models from 500 to 800 size / 29 kg. for all models from 900 to 1400 size
