AERMEC NXW0500 - Page 28

28
INXWPY. 1610. 4438880_01
9.9. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION TOTAL RECOVERY T ALL SIZE
MODEL VERS.
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500
T
728 419 1200 26% 29% 21% 23% 303
NXW0550 733 419 1195 27% 29% 21% 23% 303
NXW0600 852 424 1269 25% 28% 22% 25% 310
NXW0650 860 4045 1235 27% 27% 23% 23% 310
NXW0700 914 428 1303 24% 28% 22% 26% 310
NXW0750 1060 431 1477 23% 27% 23% 26% 314
NXW0800 1190 430 1487 23% 27% 23% 27% 652
NXW0900 1443 437 1658 23% 28% 22% 27% 315
NXW1000 1756 442 1801 21% 26% 24% 29% 322
NXW1250 1805 440 1790 21% 26% 24% 29% 322
NXW1400 1912 440 1824 21% 25% 24% 29% 322
NXW1500 1912 440 1824 21% 25% 24% 29% 322
NXW1650 1912 440 1824 21% 25% 24% 29% 322
9.10. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION SILENCED MODE WITH TOTAL RECOVERY T ALL SIZE
MODEL VERS.
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500
LT
980 404 1207 27% 28% 22% 23% 312
NXW0550 985 405 1204 27% 28% 22% 23% 312
NXW0600 1104 410 1259 26% 27% 23% 24% 651
NXW0650 1112 395 1233 27% 27% 23% 23% 651
NXW0700 1166 414 1287 25% 27% 23% 25% 652
NXW0750 1312 418 1482 24% 27% 23% 26% 652
NXW0800 1441 418 1490 24% 26% 24% 26% 652
NXW0900 1732 425 1662 24% 27% 23% 26% 323
NXW1000 2045 431 1784 22% 26% 24% 28% 324
NXW1250 2094 430 1775 22% 26% 24% 28% 324
NXW1400 2202 430 1805 22% 25% 25% 29% 324
NXW1500 2202 430 1805 22% 25% 25% 29% 324
NXW1650 2202 430 1805 22% 25% 25% 29% 324
9.11. PERCENTAGE DISTRIBUTION OF WEIGHTS ON SUPPORTS VERSION CONDESERLESS EALL SIZE
MODEL VERS.
EMPTY
PERCENTAGE WEIGHT DISTRIBUTION ON
SUPPORTS (%)
AVX
Weight
CENTRE OF GRAVITY
Xg Yg A B C D
NXW0500
E
525 396 771 29% 29% 21% 21% 319
NXW0550 530 397 768 29% 29% 21% 21% 319
NXW0600 610 399 835 28% 27% 23% 22% 301
NXW0650 619 400 834 27% 27% 23% 23% 301
NXW0700 638 400 840 27% 27% 23% 23% 301
NXW0750 796 406 1013 26% 27% 23% 24% 303
NXW0800 904 409 1161 25% 27% 23% 25% 310
NXW0900 1044 411 1130 26% 27% 23% 24% 314
NXW1000 1260 413 1237 24% 25% 25% 26% 316
NXW1250 1304 412 1234 24% 25% 25% 26% 316
NXW1400 1358 409 1252 24% 25% 25% 26% 315
NXW1500 1358 409 1252 24% 25% 25% 26% 315
NXW1650 1358 409 1252 24% 25% 25% 26% 315
