AERMEC NXW0500 - Page 31

31
INXWPY. 1610. 4438880_01
KEY
Sec. A: Power supply
Sec. B: Controls and safety connection
Earth
IL: Main switch
KEY
Sec. A: Power supply
Sec. B: Controls and safety connection
Earth
IL: Main switch
MODEL
MAX RECOMMENDED
LENGTH
(metres)
SEZ A
(400V-3)
SEZ B
EARTH
(400V-3)
IL
(400V-3)
U.M. U.M. U.M. U.M.
mm
2
mm
2
mm
2
A
NXW 0500
50
16
1,5
16 80
NXW 0550 16 16 100
NXW 0600 25 16 100
NXW 0650 25 16 125
NXW 0700 35 16 160
NXW 0750 50 25 160
NXW 0800 70 35 200
NXW 0900 70 35 200
NXW 1000 70 35 250
NXW 1250 95 50 250
NXW 1400 95 50 250
NXW 1500 120 70 315
NXW 1650 150 70 400
MODEL
MAX RECOMMENDED LENGTH
(metres)
SEZ A
(400V-3)
SEZ B
EARTH
(400V-3)
IL
(400V-3)
U.M. U.M. U.M. U.M.
mm
2
mm
2
mm
2
A
NXW 0500
50
16
1,5
16 100
NXW 0550 25 16 100
NXW 0600 25 16 125
NXW 0650 35 16 125
NXW 0700 50 25 160
NXW 0750 50 25 160
NXW 0800 70 35 200
NXW 0900 70 35 200
NXW 1000 95 50 250
NXW 1250 95 50 250
NXW 1400 95 50 250
NXW 1500 120 70 315
NXW 1650 150 70 400
ELECTRICAL DATA VERSION ° WITHOUT PUMPING GROUP
ALL VERSIONS
ELECTRICAL DATA VERSION WITH PUMPING GROUP
ALL VERSIONS
