14
“0601 - 1802” REFRIGERA
“0601 - 1802” REFRIGERA
T
T
ORI •
ORI •
CHILLERS
CHILLERS
R407C
R407C
RAFFREDDAMENTO • COOLING
0601 0701 0901 1101 1401 1601 1202 1402 1602 1802
L 131 153 205 270 338 388 262 306 358 410
Potenzialità frigorifera • Cooling capacity [kW] A 133 169 224 280 349 400 267 338 392 448
E 118 144 199 260 314 376 235 287 342 398
L 51 61 80 105 128 161 102 122 141 160
Potenza assorbita totale • Total input power [kW] A 50 55 77 103 123 153 99 110 132 153
E 55 70 93 119 145 178 109 140 163 186
L 2,57 2,51 2,56 2,57 2,64 2,41 2,57 2,51 2,54 2,56
E.E.R. [W/W] A 2,66 3,07 2,91 2,72 2,84 2,61 2,70 3,07 2,97 2,93
E 2,15 2,06 2,14 2,18 2,17 2,11 2,16 2,05 2,10 2,14
L 22.532 26.316 35.260 46.440 58.136 66.736 45.064 52.632 61.576 70.520
Portata acqua • Water flow rate [l/h] A 22.876 29.068 38.528 48.160 60.028 68.800 45.924 58.136 67.424 77.056
E 20.296 24.768 34.228 44.720 54.008 64.672 40.420 49.364 58.824 68.456
L 29 29 37 36 34 29 43 41 36 43
Perdite di carico • Water flow rate [kPa] A 30 35 45 38 36 31 44 50 44 49
E 23 25 35 34 29 27 34 36 33 38
DATI TECNICI GENERALI • MAIN TECHNICAL DATA
0601 0701 0901 1101 1401 1601 1202 1402 1602 1802
Evaporatori • Evaporators n° 11 1 111 1111
L 39.000 39.000 82.000 80.000 110.000 107.000 80.000 112.000 111.000 162.000
Portata aria totale • Total air flow [m
3
/h] A 36.000 79.000 75.300 72.000 108.000 158.000 73.800 118.500 154.300 148.000
E 25.000 34.000 44.000 57.000 68.000 83.000 50.000 62.000 78.000 88.000
L 2x1,3 2x1,3 4x1,3 4x1,3 6x1,4 6x1,4 4x1,3 6x1,4 6x1,4 8x1,3
Potenza ventilatori • Fan motor power n°x[kW] A 2x1,4 4x1,3 4x1,4 4x1,4 6x1,4 8x1,3 4x1,4 6x1,3 8x1,3 8x1,4
E 2x0,6 4x0,3 4x0,4 4x0,8 6x0,5 8x0,5 4x0,5 6x0,3 8x037 8x0,4
Compressori • Compressors n° 11 1 111 2222
Potenza assorbita resistenza carter
n° x [W]
1 x 150 1 x 150 1 x 150 1 x 150 1 x 150 1 x 150 2 x 150 2 x 150 2 x 150 2 x 150
Crankcase heater power
Circuiti frigoriferi / Circuiti idraulici
n°
1 / 1 1 / 1 1 / 1 1 / 1 1 / 1 1 / 1 2 / 1 2 / 1 2 / 1 2 / 1
Refrigerant / Hydraulic circuits
Versioni : L = Silenziata A = Alta temperatura silenziata E = Super Silenziata Versions: L = Low noise A = High temperature low noise E = Extra Low noise
Scambiatori a piastre.
Avvio stella triangolo
V = attacco tipo Victaulic (solo per evaporatore).
Le prestazioni sono riferite alle seguenti condizioni:
❄ temperatura acqua prodotta = 7 °C; ∆t = 5 °C; temperatura aria esterna = 35 °C.
Plate heat exchangers
Start - Delta start
V = Victaulic type connection (only for evaporator).
Performances refer to following conditions:
❄ temperature of processed water = 7 °C; ∆t = 5 °C; ambient air temperature = 35 °C.
