56
IVEDITI 1707 - 4880981_01
KFV is an intake/flow circular flange kit with variable section, in plastic. This
accessory allows to connect an additional circular duct, making use of the
set-ups present on the sides of the intake/flow plenum of the VED unit.
ACCESSORIES
DUCTING ACCESSORIES:
RPM_V is a flow plenum with rectangular flange made of
galvanised sheet steel and fully insulated. This accessory allows
a channel with a rectangular section to be connected to the flow
vent of the VED unit.
According to requirements, the RPM_V accessory allows for
delivery both longitudinal and perpendicular to the air flow
passing through the VED unit.
The sides of the RPM_V flow plenum are set for the connection of
a circular section channel by means of the KFV accessory.
KFV
KFV
PM_V is a flow plenum made of galvanised sheet metal , fully
insulated with plastic circular flanges having variable section.
This accessory allows connecting channels with circular section
to the flow vent of the VED unit.
According to requirements, the PM_V accessory allows for
delivery both longitudinal and perpendicular to the air flow
passing through the VED unit.
The sides of the PM_V flow plenum are set for the connection of
an additional circular section channel by means of the KFV
accessory.
KFV
KFV
Ø 180
Ø 150
Ø 200
