AFG 3.5AE - ECB MOTOR REPLACEMENT

30
CHAPTER 5: Parts Replacement Guide
5.1.7 ECB Motor Replacement
1. Loose the 2 different screws as shown below (Figure A).
Figure A
2. Loosen the screws on the opposite side. Remove the belt and then take off the ECB (Figure B).
Figure B
