32
CHAPTER 5: Parts Replacement Guide
5.2.2 Console Mast Replacement
1. Remove the console mast cover.
2. Loosen the 4 nuts shown below, and then off the console mast.
5.2.3 Arm Set Replacement
1. Loose the screw and take off the washers as shown on the following page（Figure A）
2. Loose the screw and remove the washers to take off the whole arm set ( Figure B)
3. Take off the arm set (Figure C).
