Afore AF4K-SLP - Electrical Connection

Installation
12
4.3 Electrical Connection
Communication Adapter pin assignment
Grid
Smart meter


TV
12345678
No.
COM2
1
2
3
4
5
6
7
8
COM3
SGND
TEP
485-A2
CANH_BAT1
CANL_BAT1
485-B2
CT_U
CT_N
485-A
485-B
+5VS
BAT-485-A
BAT-485-B
CTW
CTN
GEN
COM1
SELV12
RPSD
+3_3V
DRM1/5
DRM2/6
DRM3/7
DRM4/8
DRM0
Note:
For diesel generators or multi-machine parallel use, please contact the
manufacturer, and provide installation and operation instructions
separately.
PV Array
PV Array
