Installation
17
4.3.2.1 BAT-CAN/RS485
CAN/RS485
Lithium
CAN-485
4
1-3
5
6-8
PIN
Assignment
CANH_BAT1
/
T568B
12345678
CANL_BAT1
/
Pin123454678
Pin87654321
CAN/RS485
Lithium
Pin123454678
Pin87654321
BAT-485
7
1-6
8
PIN
Assignment
BAT-485-A
/
T568B
12345678
BAT-485-B
