Afore AF4K-SLP - CT or Meter Connection

Installation
21
4.3.5 CT or Meter Connec�on
Meter and a current sensor(CT for short below) are used to detect current
power direction of the local load and the grid. The output control function
of the inverters will be activated based on the detected data.
Meter
CT
Install the CT
Grid
CT
Main
Breaker
Load
TV
4 5 6 7 8
PIN Assignment
1PIN 2 3
8
1-6
7 CTU
/
CTN
CT1
